- Page 1 INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE ELECTRIC TILTING COOKER “BM7E050/BM7E050C”...
- Page 2 Modify instruction Veränderfe Modifiè manuel Budel manual Handbuch d’iinstallation 25.06.2004 Tutti Modificato libretto Modify instruction Veränderfe Modifiè manuel Budel manual Handbuch d’iinstallation Instruction manual for installation, maintenance and use - GB - 2 di 23 Page Electric tilting cooker BM7E050...
-
Page 3: Table Of Contents
Wiring diagram 3/N/PE AC 400V 4.2.1. Wiring diagram 3/PE AC 230 V 4.2.2. Wiring diagram motor-version 4.3. Knob for water inlet 4.4. Control knob Instruction manual for installation, maintenance and use - GB - 3 di 23 Page Electric tilting cooker BM7E050... -
Page 4: General Reminders
− Gloves should be worn to protect the hands during installation and maintenance operations. Warning! : Follow the fire prevention regulations very carefully. WARNING! : NOT USED ABSOLUTLY AS FRYING MODE. Instruction manual for installation, maintenance and use - GB - 4 di 23 Page Electric tilting cooker BM7E050... - Page 5 Minimum widith Model (max. level) of the pan of the outlet litres BM7E050 46,5 x 72 x 20 80° 12,5 BM7E050I BM7E050C Instruction manual for installation, maintenance and use - GB - 5 di 23 Page Electric tilting cooker BM7E050...
-
Page 6: Construction
Robust steel structure on 4 adjustable feet. Exterior and top finish entirely made of stainless steel 18/10. Stainless steel vat lid, with bottom in steel in model BM7E050. Stainless steel vat with “bimetal COMPUND 12+3” bottom in model BM7E050C. Stainless steel vat lid, INOX (AISI 304) in model BM7E050I. - Page 7 Warning! : The electrical isolating switch and the water shutoff valves must both be located near to the appliance, within easy reach for the user. Instruction manual for installation, maintenance and use - GB - 7 di 23 Page Electric tilting cooker BM7E050...
-
Page 8: Technical Data
Instruction manual for installation, maintenance and use - GB - 8 di 23 Page Electric tilting cooker BM7E050... -
Page 9: Connection To Waterworks
− Install a cut-off valve for each supply on the line before the appliance. − Make connections according to regulations currently in force. Instruction manual for installation, maintenance and use - GB - 9 di 23 Page Electric tilting cooker BM7E050... -
Page 10: Commissioning And Testing
− It is also advisable to apply for a maintenance contract with the customer. Instruction manual for installation, maintenance and use - GB - 10 di 23 Page Electric tilting cooker BM7E050... -
Page 11: Possible Failures And Their Elimination
THE BRATT PAN WORKS WITH DISCONNECTED THEMOSTAT - Electromagnetic switch contacts are cut off. OW EFFICIENTY OF THE PAN - Check the heating elements. Instruction manual for installation, maintenance and use - GB - 11 di 23 Page Electric tilting cooker BM7E050... -
Page 12: Warnings And Hints For User
− In case of failures concerning the appliance, all outputs (electrical power supply and water) must be cut off instantly. − In case of recurrent failures contact a service technician. Instruction manual for installation, maintenance and use - GB - 12 di 23 Page Electric tilting cooker BM7E050... -
Page 13: Instructions For Use
The tilting of the pan is made by means of an handwheel placed on the RH side of the front panel. Turning the handwheel anti-clockwise the pan goes up, turning it clockwise the pan goes down. Instruction manual for installation, maintenance and use - GB - 13 di 23 Page Electric tilting cooker BM7E050... -
Page 14: Cleaning And Care Of The Appliance
− External surfaces should be washed down using a sponge, and hot water with a suitable proprietary cleaner addend. − Rinse always thoroughly and dry with a soft cloth. Instruction manual for installation, maintenance and use - GB - 14 di 23 Page Electric tilting cooker BM7E050... -
Page 15: Special Procedures In Case Of Failures
The same applies in case of improper use or different application by the operator. Instruction manual for installation, maintenance and use - GB - 15 di 23 Page Electric tilting cooker BM7E050... -
Page 16: How To Proceed, If
Remove the signal lamp, unscrewing the fixed to the control pane . Fit the new signal lamp in the reverse order of operation. Instruction manual for installation, maintenance and use - GB - 16 di 23 Page Electric tilting cooker BM7E050... - Page 17 Replace the switch uloosing the fixing screws to the support , after having taken off the coaxial working thermostat. Fit the new switch in the reverse order of operation. Instruction manual for installation, maintenance and use - GB - 17 di 23 Page Electric tilting cooker BM7E050...
- Page 18 4.1. SIZE OF APPLIANCE AND POSITION OF CONNECTIONS LEGEND: Technical data plate Water connection D.12mm Electrical connection 1100 Instruction manual for installation, maintenance and use - GB - 18 di 23 Page Electric tilting cooker BM7E050...
-
Page 19: Wiring Diagram 3/N/Pe Ac 400V
Safety thermostat General switch Heating element Electromagnetic switch Microswitch Green signal lamp Fuse 3,15 A Orange signal lamp Fuse 16 A Thermostat Instruction manual for installation, maintenance and use - GB - 19 di 23 Page Electric tilting cooker BM7E050... -
Page 20: Wiring Diagram 3/Pe Ac 230 V
Green signal lamp Fuse 3,15 A Orange signal lamp Fuse 25 A Thermostat P3 P4 L2 L3 3/ PE A C 230 V Instruction manual for installation, maintenance and use - GB - 20 di 23 Page Electric tilting cooker BM7E050... -
Page 21: Wiring Diagram Motor-Version
SE2 Selector tilting of pan Mm Tilting single-phase ratiomotor Lowering limit switch Capacitor Thermostat ONLY FO R ELECTRIC M O DELS 230V Instruction manual for installation, maintenance and use - GB - 21 di 23 Page Electric tilting cooker BM7E050... -
Page 22: Knob For Water Inlet
4.3. KNOB FOR WATER INLET Way for water inlet Stop water inlet Instruction manual for installation, maintenance and use - GB - 22 di 23 Page Electric tilting cooker BM7E050... -
Page 23: Control Knob
MOTOR TILTING PAN LEGEND: Control knob Position for vat tilting OFF position Position for vat return POSITION “B” POSITION “C” POSITION “ Instruction manual for installation, maintenance and use - GB - 23 di 23 Page Electric tilting cooker BM7E050...
