- Page 1 6IN. CUTOFF SAW OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 338070 0911...
-
Page 2: Intended Use
Thank you very much for choosing a NORTHERN Industrial product! For future reference, please complete the owner's record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Important Safety Considerations
IMPORTANT SAFETY CONSIDERATIONS Make sure the cutoff wheel is securely mounted as described in the assembly instructions, • BEFORE connecting the tool to a power supply. Do not tighten wheel excessively, since this can cause cracks. Check wheel for fissures and cracks, and test for normal operation prior to use. •... - Page 4 CUTOFF WHEEL INSTALLATION WARNING! Use only reinforced, 6in. cutoff wheels, rated for 10,000 RPM or higher. Disconnect saw from the power source. Inspect the replacement wheel for defects such as cracks, chipping, and correct speed rating. If defects are found or the speed rating is not 10,000 RPM or higher, discard the wheel and choose another wheel that fits the proper specifications.
-
Page 5: Operation
2. Rotate the vise fence until the desired angle of cut is aligned with the indicator arrow in th saw base (14). 3. Check the angle of the vise fence to the cutoff wheel using a protractor, bevel square, or similar device. -
Page 6: Maintenance
Use a steady and even pressure to obtain a uniform cut. Never force the wheel into the material. When the cut is complete, release the trigger switch and allow the wheel to stop completely before raising it to the full open position. DANGER! Do not touch the cut material until it cools or you will be burned. -
Page 7: Diagram & Parts List
DIAGRAM & PARTS LIST Page of 9... - Page 8 Part # Description Q’ty Part # Description Q’ty Part # Description Q’ty Swivel arm lock Pan head screw Hex socket head bolt M8*20 handle M6*16 Hex socket head Flat washer D6 Ball bearing 627 nut M8 Adjust spindle Arbor Retaining ring D12 Flat washer D5 Flat washer D10 Gear plate...
- Page 9 For replacement parts and technical questions, please call 1-800-222-5381. WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •...
