Optional Enhancement Products
for the 4102 USB AuxBox
1825P Duet Plus
Multi-application loud ringer and paging
amplifier for business telephone systems
in an office or industrial environment.
1185 Horn Speaker
Weatherproof, 8 Ohm horn
speaker can be used to
significantly increase the
volume of the 1825P Duet
Plus Ringer above.
1127P Visual Indicator
A desktop or mountable visual indicator
for message waiting, in-use, or ring.
Designed to be visible from all angles.
Available in red, green, or blue.
1126P Strobe Light
A highly visible indicator available
with clear, red, amber, or blue lens.
Ordering Information
tel: (604) 454-3790
fax: (604) 437-5726
email: sales@algosolutions.com
Nortel Networks, Nortel, Meridian 1, Norstar are trademarks of Nortel Networks Ltd.
DirectX, Windows Media Encoder, Window 98 SE, Windows 2000, Windows ME and
Windows XP are trademarks of Microsoft Corporation.
USB AuxBox, Algo, Duet Plus, and AuxBox are trademarks of Algo Communication Products Ltd.
USB
AuxBox
4102
User Guide
Ordering Information
Tel: (604) 454-3790
Fax: (604) 437-5726
Email: sales@algosolutions.com
Customer Support
Toll free: (877) 884-2546
Email: support@algosolutions.com
Advertisement
Table of Contents
Related Manuals for Algo 4102 AuxBox USB
Summary of Contents for Algo 4102 AuxBox USB
- Page 1 Nortel Networks, Nortel, Meridian 1, Norstar are trademarks of Nortel Networks Ltd. DirectX, Windows Media Encoder, Window 98 SE, Windows 2000, Windows ME and Windows XP are trademarks of Microsoft Corporation. USB AuxBox, Algo, Duet Plus, and AuxBox are trademarks of Algo Communication Products Ltd.
- Page 2 Relay cord Tel (604) 454-3790 Fax (604) 437-5726 Power supply Outside of Canada, please contact Algo for the name of the Note: nearest repair center. The legality of recording conversations varies by location. It is the responsibility of the user to ensure compliance with local regulations concerning the recording of telephone conversations.
-
Page 3: Table Of Contents
Playback Recorded Calls North America 117V 60Hz to 24Vdc 200mA adapter ced Setting the File Directory 230V 50Hz to 24 Vdc 200mA adapter ded Call Management Europe/Australia Contact Algo or your distributor Specifications ANALOG AUDIO OUTPUT Service Connection 3.5mm audio jack Level... -
Page 4: Components
Components Call Management Front Panel Power /USB Indication Winking indicates USB connection Norstar /M1/BCM Status Note: It is important to prevent the possible deletion of files due Winking once indicates connection to M1; to Automatic limits. Select the disable feature to prevent deletion winking twice indicates connection to when moving from folder to folder. - Page 5 Software Features Setting the File Directory Back Panel The AuxBox Recorder Software can read audio files from different locations on your hard drive eg. multiple projects, customers. To move to a different location to view recorded calls, click on Browse. Note: The directory you select will determine which calls are listed and USB Output where new calls will be saved.
-
Page 6: Switch Settings
Switch Settings (North America) Playback Recorded Calls 1 Select the file to play back. Position 1 2 To begin the playback, double click on the file or press the play Position 5 & 6 off = Audio level high button on the playback toolbar shown above. You can also press unused on = Audio level low <enter>... -
Page 7: Installation
Software Features Installation To Save by No Limit Hardware Installation Connecting the 4102 USB AuxBox to your Meridian Telephone 1 Disconnect your telephone line cord from the wall jack and connect to either one of the RJ12 telephone jacks on the rear of the 4102 USB AuxBox. -
Page 8: Connecting To Your Pc
Installation Connecting to your PC USB Port To Save by Number of Calls 1 Connect the USB cable to your PC and to the 4102 USB AuxBox. Connect the power supply to the 4102 USB AuxBox. The first time you connect the 4102 USB AuxBox, Windows should advise “New Hardware Found”... -
Page 9: Minimum Pc Requirements
Software Features Phone HotKeys Minimum PC Requirements Applies only to the AuxBox The software gives you the ability to record a key on the Recorder Software. phone, and use this phone key to trigger recording in the software. Two keys may be configured - the first to Pentium 133 MHz function like the Toggle feature, and the second to function as the Manual Record HotKey. -
Page 10: Software Installation
Installation Recording Calls Software Installation Calls can be recorded automatically or manually. 1 After Windows has completed loading the drivers, ensure that all open programs and windows are closed. If you have already Click on Setup>Options. installed a version of the AuxBox Recorder Software, remove the program before you install the new version. -
Page 11: Configuring Your Pc
Software Features Toolbar Configuring Your PC Note: Close the Auxbox Recorder Software before you configure your PC Will delete selected audio files. The DEL key on the Delete or your selection will not take effect. keyboard can be used as well. After Windows has successfully Keep Selected files marked as Keep will not be deleted in... -
Page 12: Software Features
Software Features Application Window This window will log all calls recorded, keep Sorting Audio Files status, duration of call, ending time, and comments. All the columns in the Application Window can be sorted by ascending or descending order by clicking on the column header. The comments section shows call related LCD display information and user added comments.
