Summary of Contents for Ultimax DS-7204HVI-SH

Page 1 Quick Operation Guide Ultimax 1200 Ultimax 1300 Ultimax 1400...
Page 2: Dvr Pre-Installation
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to DS-7204HVI-SH, DS-7208HVI-SH, DS-7216HVI-SH; DS-7204HFI-SH, DS- 7208HFI-SH, DS-7216HFI-SH; DS-7204HWI-SH, DS-7208HWI-SH, DS-7216HWI-SH; DS-7204HVI-SV, DS- 7208HVI-SV and DS-7216HVI-SV series DVR.
Page 3 Quick Operation Guide of DS-7200-SH/SV Series DVR 3. Connect the HDD to the motherboard of the DVR with the included data cable. 4. Connect the power cable to the HDD. 5. Re-install the cover of the DVR and fasten screws.
Page 4: Front Panel
Quick Operation Guide of DS-7200-SH/SV Series DVR Front Panel The front panel of DS-7200-SH/SV is shown below: Table 1 Description of Control Panel Buttons Name Function Description POWER POWER indicator turns green when DVR is powered up. STATUS STATUS indicator lights in red when data is being read from or written to HDD.
Page 5: Peripheral Connections
Quick Operation Guide of DS-7200-SH/SV Series DVR Alarm In/Out Connector for alarm input/output. AUDIO IN RCA connector for audio input. AUDIO OUT RCA connector for audio output. LAN Interface Connector for LAN (Local Area Network). RS-485 Interface Connector for RS-485 devices. Connect the D+ and D- terminals to T+ and T- of PTZ receiver respectively.
Page 6 Quick Operation Guide of DS-7200-SH/SV Series DVR 1. Disconnect pluggable block from the ALARM IN /ALARM OUT terminal block. 2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part. Ensure signal cables are in tight.
Page 7: Specifications
Quick Operation Guide of DS-7200-SH/SV Series DVR Specifications Table 3 Specifications for DS-7200HFI-SH...
Page 8 Quick Operation Guide of DS-7200-SH/SV Series DVR Model DS-7204HFI-SH DS-7208HFI-SH DS-7216HFI-SH Video/Audio Video compression H.264 input Video input 4-ch 8-ch 16-ch Video input interface BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive Audio compression G.711 Audio input 1-ch / 4-ch, RCA (2.0 Vp-p, 1 kΩ) Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) Video/Audio...
Page 9 Quick Operation Guide of DS-7200-SH/SV Series DVR Table 4 Specifications for DS-7200HVI-SH...
Page 10 Quick Operation Guide of DS-7200-SH/SV Series DVR Model DS-7204HVI-SH DS-7208HVI-SH DS-7216HVI-SH Video/Audio Video compression H.264 input Video input 4-ch 8-ch 16-ch Video input BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive interface Audio G.711 compression Audio input 1-ch / 4-ch, RCA (2.0 Vp-p, 1 kΩ) Two-way audio 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Page 11 Quick Operation Guide of DS-7200-SH/SV Series DVR Table 5 Specifications for DS-7200HVI-SV Model DS-7204HVI-SV DS-7208HVI-SV DS-7216HVI-SV Video/Audio Video compression H.264 input Video input 4-ch 8-ch 16-ch Video input BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive interface Audio compression G.711 Audio input 1-ch / 4-ch, RCA (2.0 Vp-p, 1 kΩ) Two-way audio...
Page 12 Quick Operation Guide of DS-7200-SH/SV Series DVR Table 6 Specifications for DS-7200HWI-SH...
Page 13 Quick Operation Guide of DS-7200-SH/SV Series DVR Model DS-7204HWI-SH DS-7208HWI-SH DS-7216HWI-SH Video/Audio Video compression H.264 input Video input 4-ch 8-ch 16-ch Video input BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive interface Audio compression G.711 Audio input 1-ch / 4-ch, RCA (2.0 Vp-p, 1 kΩ) Two-way audio 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) input...
Page 14 Quick Operation Guide of DS-7200-SH/SV Series DVR...
Page 15: Hdd Storage Calculation Chart
Quick Operation Guide of DS-7200-SH/SV Series DVR HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K...
Page 16: Menu Operation
Quick Operation Guide of DS-7200-SH/SV Series DVR Menu Operation Menu Structure The menu structure of the DVR is shown as below: Note: You can right click on the Shutdown button to exit the main menu. Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the DVR. Before you start: Check that the voltage of the extra power supply is the same with the device’s requirement, and the ground connection is working properly.
Page 17: Using The Setup Wizard
Quick Operation Guide of DS-7200-SH/SV Series DVR 2. Click the Shutdown button to enter the following dialog box: 3. Click the Yes button. The following message box pops up: 4. Turn off the power switch on the rear panel of DVR. Using the Setup Wizard The Setup Wizard can walk you through some important settings of the device.
Page 18 Quick Operation Guide of DS-7200-SH/SV Series DVR 2. Check the checkbox to enable Setup Wizard when device starts. Click Next to continue the setup wizard. You can also click Cancel to exit the Setup Wizard, or use the Setup Wizard next time by leaving the “Start wizard when device starts?”...
Page 19 Quick Operation Guide of DS-7200-SH/SV Series DVR 5. Click Next button which takes you back to the Network Setup Wizard window. Set the network parameters, including the NIC type, IPv4 address, IPv4 subnet mask, default gateway, etc. You can enable the DHCP to automatically obtain an IP address and other network settings from that server. 6.
Page 20: Using The Mouse In Live View
Quick Operation Guide of DS-7200-SH/SV Series DVR Click Copy to copy the record settings of the current camera to other camera (s) if needed. Click OK to return to the Record Settings window. 8. Click OK to complete the startup Setup Wizard. Live View Some icons are provided on screen in Live View mode to indicate different camera status.
Page 21: Main/Aux Output Switching
Quick Operation Guide of DS-7200-SH/SV Series DVR Table 7 Mouse Operation in Live View Icon Name Description Main Menu Enter the main menu of the system. Single Screen Switch to the single full screen live view mode. Multi-screen Switch to multi-screen live view mode. Note: The multi-screen icon varies according to the device models.
Page 22 Quick Operation Guide of DS-7200-SH/SV Series DVR Control icon to enter the PTZ toolbar. Table 8 Description of the PTZ toolbar icons Icon Description Icon Description Icon Description Direction button and the Zoom+, Focus+, Zoom-, Focus-, auto-cycle button Iris+ Iris- The speed of the PTZ Light on/off Wiper on/off...
Page 23: Instant Playback By Channel
Quick Operation Guide of DS-7200-SH/SV Series DVR 3. In the pop-up message box, click Yes to finish the quick recording settings for all channels. Note: The full-screen motion detection triggered recording is configured by default in this mode. Playback Play back the record files of a specific channel in the live view menu. Instant Playback by Channel Choose a channel under live view using the mouse and click the button in the quick settings toolbar.
Page 24 Quick Operation Guide of DS-7200-SH/SV Series DVR The channel and time selection menu will display by moving the mouse to the right of the playback interface. Tick the channel or channels if you want to switch playback to another channel or execute simultaneous playback of multiple channels.
Page 25 Quick Operation Guide of DS-7200-SH/SV Series DVR 2. Set search conditions and click Search button to enter the search result interface. 3. Select record files you want to back up. Click button to play the record file if you want to check it. Check the checkbox before the record files you want to back up.
