Ruhe Systems RDVR-HQ04 User Manual

Hdsdi digital video recorder series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDSDI Digital Video Recorder Series
RDVR-HQ04

User Manual

About this user guide
Before installing and using this unit, please read this user guide carefully.
.
Be sure to keep it handy for later reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RDVR-HQ04 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ruhe Systems RDVR-HQ04

  • Page 1: User Manual

    HDSDI Digital Video Recorder Series RDVR-HQ04 User Manual About this user guide Before installing and using this unit, please read this user guide carefully. Be sure to keep it handy for later reference...

  • Page 2: Safety Precautions

    Safety Precautions Explanation of Graphical Symbols This symbol indicates the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. This symbol indicates the presence of Uninsulated ”dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 These precautions must be followed for safety reasons. Warning  Do not uses if the unit emits smoke, strange sounds are heard, or odor is emitted.  Make sure the power cable is not damaged.  Make sure there is no dust accumulation on the power plug or the outlet. ...

  • Page 4: Product Components

    Product Components The package contains the main unit and its components as specified below. When you purchase the unit, Please check to ensure the components specified below are included. DVR Set(E Front Type) DVR Set(L Front Type) Client Software CD Remote Control Battery1.5V (AAA x 2EA) Quick Guide...

  • Page 5: Mounting The Hard Disk

    Mounting the HARD DISK 1. Remove the screws and the top cover as specified below. 2. Mount the HDD into the mounting bracket as specified below. 3. Insert the HDD bracket and mounting screw as specified below. 4. Connect the HDD SATA and HDD power cable as specified below. NOTE) Please mount all HDDs which you want to use when installing at the first time.

  • Page 6: Compatible Hdd Models

    Compatible HDD Models Company Models Size SATA Type BUFFER Seagate ST3000VX000-1CU166 3 TB SATA 3 7200 RPM 64 MB ST3000DM001(CC43) 3 TB SATA 3 7200 RPM 64 MB ST3000DM001(CC24) 3 TB SATA 3 7200 RPM 64 MB ST2000VM003 2 TB SATA 3 5900 RPM 64 MB...
  • Page 7 HDS721050DLE630 500GB SATA 3 7200 RPM 32 MB HDS721050CLA362 500 GB SATA 2 7200 RPM 16 MB HDP725050GLA360 500 GB SATA 2 7200 RPM 16 MB HDS721032CLA362 320 GB SATA 2 7200 RPM 16 MB HDS721025CLA382 250 GB SATA 2 7200 RPM 8 MB HDT721025SLA380...

  • Page 8: Specifications

    Specifications Please note that specifications and unit exterior design are subject to change without notification MODEL HD-0413L/E Video Input Number of Channels Format HD-SDI (720p25/30/50/60, 1080p25/30, 1080i50/60) Output Main Monitor HDMI and VGA Sub Monitor HDMI SPOT or VGA SPOT Audio Input &...

  • Page 9: Table Of Contents

    Dynamic DNS Yes (Free DDNS) Dual Encoding for Network Features Digital Zoom DLS (Day Light Saving) NTP (Network Time Protocol) S.M.A.R.T Internal Beep Multi-Language e-mail Notification Network 3G Mobile iPad / iPhone / Android Access Web Viewer Windows (IE, Chrome, Firefox, Safari) PC Client Single / Multi Client and CMS (64 channels) Remote Setup and Upgrade...
  • Page 10 3-8. Setup – Network Mode ......................... 36 3-8-1. Port, Network Audio Port and Web Port ..................37 3-8-2. Network Types .......................... 38 3-8-2-1. DHCP ............................. 38 3-8-2-2. STATIC ........................... 38 3-8-3. DDNS ............................38 3-8-4. Network Stream ......................... 39 3-9. Setup - CONFIG Mode ......................... 40 3-10.
  • Page 11 9-3. Installing the program ........................74 9-4. Live Window ..........................75 9-4-1. Main user interface ................... 75 9-4-2. Control buttons ....................75 9-5. Search and Playback Window ...................... 77 9-5-1. Main user interface ................... 77 9-5-2. Main control panel .................... 77 9-6.
  • Page 12 B. How to access DVR from Remote PC? ..................105 C. How to access DVR with iPhone? ....................108 D. How to access DVR with Android? ..................... 111...

  • Page 13: Main Features

    1. Main Features  H.264 Video compression  Reliable File system  HDMI Output  4 channel audio recording  Individual channel operation  Motion detection  Automatic video input and video loss detection  Covert camera operation provides enhanced security ...

  • Page 14: Name, Function And Connection

    2. Name, Function and Connection 2-1. Front Panel The following information will help you to operate the front panel controls. Figure 2.1.1. Front panel ① SEQ: To start auto sequencing of the screen in full screen mode. (Toggle) ② PTZ: To control PTZ operation ③...

  • Page 15: Rear Panel

    2-2. Rear Panel Figure 2.2.1. Rear Panel Table 2.2.1. Rear panel connections Connection Purpose VIDEO IN connectors for video input. (NTSC/PAL) AUDIO IN 4 connectors for audio input. AUDIO OUT 1 connector for audio output. HD VIDEO connectors for main video output. HDMI VGA OUT Connector for VGA monitor.

  • Page 16: Remote Control

    2-3. Remote control Figure 2.3.1. Remote Controller Button ① ID: To set the remote control ID. ② REC: To start and stop manual recording ③ SEARCH: To go to SEARCH menu. ④ F/ADV:  During playback – To move the playback position 60 seconds forward . ...

  • Page 17: Setting Up The Dvr

    3. Setting up the DVR The following sections detail the initial setup of a DVR. 3-1. Setup – Main Screen When booting a system at first, the following messages display. After initializing, select a language and set the time. To enter the setup menu, select a right button of the mouse or press the SETUP button on the remote control.

  • Page 18: Setup - Menu Tree

    SYSTEM INFORMATION: Display a software version, storage size, network type, IP address, MAC address, DDNS status, DVR ID and remote controller ID of the system. SYSTEM LOCK: To lock the system, user input a password. To unlock the system, please press ESC button for 5 seconds on a front panel or a remote control.
  • Page 19 SPOTOUT ON EVENT SPOT EVENT DWELL TIME SEQUENCE SEQUENCE DWELL TIME SPOT CHANNEL – CHANNEL MOTION ZONE MOTION SENSITIVITY – KEY TONE – REMOTE CONTROLLER ID – SENSOR TYPE  STORAGE – OVERWRITE – DISK FORMAT – DISK INFO – RECORDING LIMIT RECORDING LIMIT DAYS ...
  • Page 20 – WEB PORT – NETWORK TYPE (DHCP, STATIC) SUBNET MASK GATEWAY DNS(PRIMARY) DNS(SECONDARY) – DDNS DDNS SERVER 1 DDNS SERVER 2 DDNS SERVER 3 – NETWORK STREAM RESOLUTION FRAME RATE QUALITY – WIRELESS LAN  CONFIG – SAVE SETUP TO A USB –...

  • Page 21: Setup - Display Mode

    3-2. Setup – Display Mode In the SETUP menu, select the DISPLAY tab. Then, the DISPLAY menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. To return to the previous setup menu screen, press the ESC button.

  • Page 22: Setup - Recording Mode

    DWELL TIME mode (3~60seconds) CHANNEL Select a channel to apply the name and covert settings change using the mouse or the remote control. Select a channel to apply the following settings using the mouse NAME Set the channel name. Press the right square button and set the channel name and select OK using the mouse.

  • Page 23: Recording Schedules

    (RESOLUTION, FRAME RATE, QUALITY, RECORDING, PRE RECORD, POST EVENT RECORD and AUDIO) RESOLUTION Select 1920x1080, 1920x540, 1280x720 or 640x360 using the mouse or the remote control. FRAME RATE Set the frame rate for the specified channel. The sum of the frame rate values from each channel cannot exceed the maximum frame rates for a specific recording resolution.

  • Page 24: Setup - Device Mode

    Figure 3.3.1.1. Schedule recording setup screen 3-4. Setup – Device Mode In the SETUP menu, select the DEVICE tab. Then, the device menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. Figure 3.4.1.
  • Page 25 Table 3.4.1. Menu items in Device Setup screen Item Description ALARM OUT Only one Alarm-out is available. /ALARM DURATION Set alarm dwell time from 5 to 60 seconds or infinite. CONTROLLER & PTZ Set the controller and PTZ camera speed, number, type and ID. SPOT OUT Set the all details for spot monitoring.

  • Page 26: Controller & Ptz Setup

    3-4-1 Controller & PTZ Setup To control the PTZ functions of the camera, connect the PTZ controller to the RS-485 port on the back of the chassis with CAT5 (or equivalent) cable. ① Connect the RS-485 cables of PTZ camera to the RS-485 port on the rear panel. ②...

  • Page 27: Spot Out

    3-4-2. SPOT OUT Figure 3.4.2.1. SPOT OUT setup Screen Table 3.4.2.1. Menu item in SPOT-OUT Setup screen Item Description SPOT OUT Spot Out 1: from 1 channel to 4 channel SPOT TYPE Select Full screen or Quad screen mode. SPOT ON EVENT Enable/Disable display of the channel when an event is active. SPOT EVENT Set the dwell time for the display of the event activated channel.

  • Page 28: Setup - Storage Mode

    Figure 3.4.3. Motion Zone selection screen 3-5. Setup – Storage Mode In the SETUP menu, select the STORAGE tab. Then, the STORAGE menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. Figure 3.5.1.
  • Page 29 DISK FORMAT You will have an option of YES or NO for formatting the Hard Drive. After formatting HDD, the DVR will reboot. Caution: It is recommended to archive any data that you may need in the future before formatting the hard drive. DISK INFO Hard drive information Displays the following information;...

  • Page 30: Setup - System Mode

    3-6. Setup – System Mode In the SETUP menu, select the SYSTEM tab. Then, the SYSTEM menu is displayed as pictured below. Navigate through the menu items using the mouse or the remote control and change the value of the menu Figure 3.6.1.
  • Page 31 press OK button to set the present date and time. DAY LIGHT SAVING Select DAYLIGHT SAVING using the mouse or the remote control and select the appropriate daylight saving time zone. If choosing EU or OTHERS, set the applicable conditions. The options are: OFF / USA / EU / OTHERS OFF: Daylight saving is turned off.
  • Page 32 TIME ZONE: NTP synchronizes with GMT (Greenwich Mean Time) regardless of Geography user must set their own time difference. CONNECTON MODE: Select the NTP time-server connection mode from TIME, INTERVAL, and ONCE. CONNECTION PERIOD TIME – Refresh the time at the designated time (e.g. 1AM) INTERVAL –...
  • Page 33 SYSTEM EVENT NOTIFICATION HEALTH CHECK – OFF, ON (Allows the user to set MAIL STATUS periodically) : DAILY or WEELY or MONTHLY EVENT AND NOTIFICATION – OFF, ON (Allows the user to set EVENT NOFICIATION ON or OFF) HEALTH CHECK / RESTART / SHUTDOWN / PANIC RECORD Enable Email Notification in the event a problem occurs with the DVR.

  • Page 34: Setup - Security Mode

    3-7. Setup – SECURITY Mode In the SETUP menu, select the SECURITY tab. Then, the SECURITY menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. Figure 3.7.1. SICURITY setup screen Table 3.7.1.
  • Page 35 ADMIN, NETOWRK, USER1, USER2, USER3: V check: It means the user can access to the function. Blank: It means the user cannot access to the function. USER NAME Change the name of USER1, USER2 and USER3. Click “ENTER” after naming. USER PASSWORD Options are ADMIN, USER1, USER2 and USER3.

  • Page 36: Setup - Network Mode

    When user set this function, they can see a user login window. Then, user can select one of user types ◀ ▲ ▶ ▼ (ADMIN, USER1, USER2, USER3) using the mouse or the control button ( ) on the remote control.

  • Page 37: Port, Network Audio Port And Web Port

    DDNS Dynamic Domain Name System (DDNS) allows a DNS name to be constantly synchronized with a dynamic IP address. In other words, it allows using a dynamic IP address to be associated with a static domain name so others can connect to it by the static name. Enable/disable using domain name address through DDNS server.

  • Page 38: Network Types

    3-8-2. Network Types 3-8-2-1. DHCP An IP address is automatically assigned by the DHCP server, which automatically assigns IP address and other parameters to new devices. When ADSL or other network being used adopts variable IP method, not fixed IP. This option is used as a way to automatically get IP address.

  • Page 39: Network Stream

    Figure 3.8.3.2. Network setup screen – DDNS Server 2 3-8-4. Network Stream User can set the resolution, the frame rate and the quality for a network stream classified by channel. It is recommended that user should adjust each item to proper level to get the network service smoothly. The maximum value for the network stream is VGA 15fps per channel but the recording resolution and frame rate are sending when only one user connects to the one channel mode via network.

  • Page 40: Setup - Config Mode

    3-9. Setup - CONFIG Mode In the SETUP menu, select the CONFIG tab. Then, the configuration menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. Figure 3.9.1. Config setup screen Table 3.9.1.
  • Page 41 The following settings such as Language, DVR ID, Security User Authentication, Security User P/W, Date format, DLS settings, Network settings, HDD overwrite, Limit recording, HDD serial number, and HDD ERROR time will not be included. LOAD FACTORY Press the button to reset the system to the factory default settings. DEFAULT SOFTWARE Upgrade softeware to the latest version.

  • Page 42: Quick Setup

    3-10. Quick Setup In the SETUP menu, select the QUICK SETUP tab. Then, the configuration menu is displayed as pictured below. Navigate through the menu items or change the settings using the mouse or the remote control. The QUICK SETUP has high priority than other setting values on RECORDING menu. The QUICK SETUP also cannot set to classified according to channel.

  • Page 43: Live, Search And Playback

    4. Live, Search and Playback 4-1. Live Viewing Screen In the Live screen, video inputs from the cameras are displayed as they are configured in the Display Setup screen. Various on-screen display (OSD) symbols, which indicate the status of the DVR, are described in Table 4.1.1.
  • Page 44 Manual Record button. Click this button to record at once. Alarm-out function On/Off button. An alarm is stopped and an alarm setup lamp is right out when it clicks this button during the alarm is in progress. Click the split screen icon to change the current split screen mode using the mouse or SEL button.
  • Page 45 Right click the mouse, and the quick operation window will be displayed as below. Figure 4.1.2. Quick Operation Window Table 4.1.2. Menu Items in Quick Operation Window Icon Description SETUP Select this option to enter the Setup menu. AUDIO Select this option to mute audio on all channels. SEARCH Search button.

  • Page 46: Search Screen

    CHANNEL Press the button to view the record setting of a selected channel. INFORMATION SYSTEM Press the button to view the system information. INFORMATION SYSTEM LOCK Locks the DVR from unauthorized user access. SYSTEM Select this option to shutdown system. SHUTDOWN 4-2.

  • Page 47: Quick Search

    4-2-1. QUICK Search The Quick Search window is used to find stored video with ease using the thumb nail playback screen. Figure 4.2.1.1. Quick Search screen 1. When the Quick Search menu is selected, the user can see a calendar, which displays recorded dates with highlights.

  • Page 48: Time-Line Search

    4-2-2. TIME-LINE Search The TIME-LINE search window is used to find the stored video by using the time line bar. Figure 4.2.2. Time Line Search screen When it clicks a Timeline menu, user can see a calendar which has recording data. Select a specific date and time.

  • Page 49: Go To First Time

    Figure 4.2.3.1. Event Search screen When the Event menu is selected, the user can see a calendar, which has recorded data. Select a specific date and the event log will be displayed. Press the PLAY button to playback the data or the SAVE button to save the data after selecting the specific data.

  • Page 50: Archive Search

    4-2-7. Archive Search The ARCHIVE Search window is used to find previously stored video or images. Figure 4.2.7. Archive Search Screen When it clicks an Archive menu, user can see a calendar which has recording data. Select a specific date and then user can see all data.
  • Page 51 Figure 4.3.1. PLAY Mode Screen The following status bar hides automatically and appears again if a mouse pointer is positioned to the bottom of the screen. Table 4.3.1. Button functions in PLAY Mode Button Description Return to the previous menu screen, search window, or exit from the Menu 2x, 4x, 8x,16x, 32x speeds at 4 split screen ...

  • Page 52: Digital Zoom In Live And Playback Screen

    4-4. Digital Zoom in Live and Playback Screen DVR series supports Digital Zoom feature during live and playback mode. 1. Double click the target channel. 2. Click the left button of the mouse and drag to make rectangular shape.

  • Page 53: Ptz Control

    5. PTZ Control To control the PTZ functions of the camera, select PTZ menu on the screen using the mouse. Please refer to the table 5.1. for the control. Table 5.1. Button Functions in PTZ Control Item Description INITIALIZE Initialize the PTZ settings of the selected camera. ◀...

  • Page 54: Back Up

    6. Back up 6-1. Still Image backup onto USB flash Drive Still images can be captured and archived onto the USB flash drive or an USB external hard drive in live mode or while playing back recorded video. In live mode, press the BACKUP button to launch the archive function or select BACK UP menu on the screen using the mouse.

  • Page 55: Transferring Still Images Or Video From The Archive List

    6-3. Transferring still images or video from the ARCHIVE list The stored data onto hard drive will be found in the ARCHIVE list in SEARCH window. User can back up still images or video into the storage device from the ARCHIVE list. 1.

  • Page 56: Playback Of Backup Video

    6-4. Playback of Backup Video  NSF format: NSF format video can be played back by the player (the HD player) that the DVR copies on USB flash drive with video. Two folders are copied on USB flash drive - BACKUP DATA: NSF format video file and INDEX file for a title file of date and time - HD PLAYER: Exclusive video viewer.

  • Page 57: Upgrading Firmware

    7. Upgrading Firmware In order to upgrade, the firmware upgrade file must first be downloaded and copied into the USB memory drive. Create a new folder in the USB memory drive and name it “upgrade”. Copy the firmware upgrade file “xxxxxx.bin”...
  • Page 58 4. You could see the following warning message if you don’t pull out the USB memory drive. NOTICE If selecting REBOOT LATER, the upgraded software will not be applied until the system reboots. If selecting REBOOT NOW when the USB flash drive is plugged, the following message will pop up.
  • Page 59 2. Press the password for admin. Just admin is possible to connect to the remote setup menu. 3. Go to the Remote Upgrade menu. Then, you can see the current F/W version as follows. To upgrade a new F/W, insert the F/W in your PC and press the UPGRADE button. 4.
  • Page 60 5. When finishing the upgrade, the network streaming would be connected again automatically and you can see the following screen. Please check the current F/W version if the upgrade is succeeded.

  • Page 61: Network Access Using The Exclusive Network Viewer, Ums Single

    8. Network access using the Exclusive network viewer, UMS single The DVR provides a live remote monitoring feature. Remote monitoring requires installation of the network viewer on your PC. NOTICE In a high bandwidth network, a maximum of four users can access one DVR simultaneously. In a low bandwidth network it is recommended that only one user access the DVR at a time.

  • Page 62: Live Monitoring Mode And Functions

    8-3. Live monitoring mode and functions. Button Function Description DATE & TIME Displays the current date and time. CONNECT/DISCONNECT Connect/disconnect network connection. SEARCH Switches the live mode to search mode. DISPLAY MODE Select a channel and screen display mode. PAN/TILT/ZOOM/ FOCUS Control the PAN / TILT / ZOOM / FOCUS features on the remote camera.
  • Page 63 NETWORK BANDWIDTH Shows the transferred frames and network bandwidth. AUDIO Adjust the volume. The audio can be turned on or off by clicking the audio icon. LOG WINDOW Display the connection status of DVR Operations of the display mode of the main screen ...

  • Page 64: Bi Directional Audio

    Image capture of live screen Still-image of live screen can be captured and saved as BMP or JPEG file. 1. Click the channel to be captured. Then the channel screen is surrounded with a red line. 2. Click the CAPTURE button. Then the IMAGE CAPTURE dialog is displayed. 3.
  • Page 65 Button Function Description DATE & TIME Displays the recording time of the data selected on the time bar at the bottom of the main user interface. DISCONNECT Disconnect network connection.. LIVE Switches the search mode to live mode. DISPLAY MODE Select a channel and screen display mode.
  • Page 66 GO BACK Time search settings TIME LINE To change a timeline scale from 24 hours to 60 minutes. The timeline shows recorded data in color on the bar. You can adjust the timeline scale and move it to the time you wish to playback. Then click the play icon to display the recorded video.
  • Page 67 Backup of video in the remote DVR Video recorded in the remote DVR cab be backed up on the PC HDD as AVI format. 1. Connect the network to the remote DVR and play the video recorded in the remote DVR. 2.

  • Page 68: Pc System Configuration

    8-6. PC System configuration Click the SETUP button. Then the Setup dialog is displayed. Setting General Set the Security Option, Save Path, and Miscellaneous.  Security Option: Set a password for security options. When you access any of the selected functions, you will need to enter the password.
  • Page 69 Setting Site The remote DVRs can be added, modified, and removed. Click ADDITION button. And then the following window will be displayed as below.  Site Name: Input a name that properly describes a site.  IP Address: Input IP address (Public IP address of a router that DVR is connected.) or Domain name ...
  • Page 70 Event Search: Event log can be searched from the selected time. Setting Record Record Setup: You can set the recording conditions as the following; Always, Event, or Auto record. And you can also select target DVR/DVRs and channel/channels When you set the recording condition to event, you can set event for motion or alarm with duration.
  • Page 71 Setting Secondary Monitor Used to calibrate the second monitor image. Setting Language English, French and Spanish is selectable. About “About” provides network client version information.

  • Page 72: Ums Client Connection

    8-7. UMS Client Connection Click CONNECT button to appear on the site registered under the ”OK” button is pressed, the connection to the site. If you want to connect directly to an IP address or Domain address to “OK” button...

  • Page 73: Network Access Using The Exclusive Network Viewer, Ums Multi

    9. Network access using the Exclusive network viewer, UMS Multi 9-1. Overview The UMS Multi-Client is a multiple site monitoring client software with; video, audio, and alarm signals from the DVRs over networks. The UMS Multi-Client does not limit the number of DVR units to register. The program displays to up 256 live videos on one display and even playback videos window on the same or another display monitor.

  • Page 74: Installing The Program

    9-3. Installing the program 1. Insert the provided CD in the CD drive and double-click “UMSMultiClient (XXXX).exe” 2. Select a destination folder and click “Next”. 3. Select the program folder and click “Next”. 4. The setup status screen is displayed. 5.

  • Page 75: Live Window

    9-4. Live Window When installation is completed, double click the “UMS Multi Client” icon on your desktop to start the program. 9-4-1. Main user interface 9-4-2. Control buttons Button Description Click this icon to run a playback window to search and play videos that are recorded in local PC.
  • Page 76 Click this icon to setup configuration of UMS MULTI CLIENT. SETUP Click this icon to capture a still image CAPTURE Opens list of events logged by the UMS Multi Client. EVENT LIST Click this icon to play/pause live video. PAUSE Click this icon to turn on/off alarm outputs.

  • Page 77: Search And Playback Window

    9-5. Search and Playback Window 9-5-1. Main user interface You can access to search window by clicking the search icon (Local Playback / Remote Playback) on the upper left of Live Window. 9-5-2. Main control panel Button Description Click this icon to run a playback window to search and play videos that are recorded in local PC.
  • Page 78 Click this icon to set the beginning time for backup of the recorded MARK IN video in AVI format. Click this icon to set the ending time for backup of the recorded video MARK OUT in AVI format. Click this icon to backup the recorded video in AVI format. BACKUP Use the volume control bar to set the audio level.

  • Page 79: Setup Of Ums Multi Client

    9-6. Setup of UMS Multi Client Click the setup icon to setup the configuration of UMS Multi Client software. The Setup window displayed as below. 9-6-1. General Security Option: Set a password for security options. Select security options and set a password. Then when you access any of selected functions, you need to enter the password.

  • Page 80: Event

    9-6-2. Event Event log can be archived and searched. Event Log: Specify the location to save event logs and select event to archive. Event Search: Event log can be searched from the selected time.

  • Page 81: Record

    9-6-3. Record Record Setup: You can set the recording conditions as the following; Always, Event, or Auto record. And you can also select target DVR/DVRs and channel/channels. When you set the recording condition to event, you can set event for motion or alarm with duration. Record Local Storage Setup: You can select the local disk to record and the amount of disk space you want to allow the program to use for recording.

  • Page 82: Display

    9-6-4. DISPLAY You can select the OSD (On Screen Display) to be displayed. 9-6-5. Language You can select a language to be display.

  • Page 83: About

    9-6-6. About “About” provides network client version information. 9-7. Remote Setup The menu settings for the DVR unit can be set over network. Put the cursor of the mouse on the channel, which is connected to the site and right click on the mouse to open the submenu.

  • Page 84: Display

    NOTICE Web Setup is prohibited when DVR is in local Setup Menu. 9-7-1. Display Select the DISPLAY tab to set the DISPLAY conditions. These settings apply to all channels.  OSD: Sets whether to display or not date and time as well as channel number on the screen. OSD CONTRAST: Adjust the character contrast on the screen.

  • Page 85: Record

    9-7-2. Record Select RECORD tab to set the recording conditions. These settings apply to the specified channel only.  Recording Setup o RESOLUTION: Sets the resolution for the recordings. The set value applies to an individual channel. o FRAME RATE: Sets the recording rate. o QUALITY: Sets the image quality in 5 levels.

  • Page 86: Device

    9-7-3. Device Select Device to set Alarm Out, Controller and PTZ, Motion zone ALARM OUT: Set the sensor, motion, and video loss for triggering alarm relay.  HDD Error and Video Loss can be set for triggering a beeping sound The following settings can be changed to trigger an alarm output.

  • Page 87: Storage

    9-7-4. Storage Select Storage to configure continued recording settings by overwriting the hard disk and the storage period for the recording data.  OVERWRITE: Select on to continue recording by overwriting when the hard disk becomes full. DISK INFO: Hard drive information. ...

  • Page 88: System

    9-7-5. System Select System to set system and time settings.  DATE DISPLAY FORMAT: Select the date display format. CLIENT ACCCESS: Enable/Disable remote access through network client software.  NTP SETUP: Sets whether to synchronize the time using NTP server or not. ...
  • Page 89 o MAIL PORT: Mail port setting. o SEURE OPTION: Select a secure mail server connection. (SSL or TLS) o ID : Email User ID o PASSWORD : Email User Password o MAIL TO: Input the appropriate email address to enable sending e-mail reports o MAIL FROM (Return Mail Address): Set the source e-mail address to be notified to the destination.

  • Page 90: Security

    9-7-6. Security Select the Security tab to set the DISPLAY conditions.  USER AUTHORITY: Select which users have access to each function, password check can be implemented for each function accessed.  USER PASSWORD: Select Username to change Password CHANGE: Select whether to KEEP or CHANGE the current password. NEW PASSWORD: Input NEW Password if CHANGE was selected.

  • Page 91: Network

    9-7-7. Network PORT: When connecting multiple DVRs to the network, set a unique port number.  NETWORK AUDIO PORT: Display the network audio port (NETWORK PORT + 1).   WEB PORT: Set a web server port number. NETWORK TYPE ( Cannot be altered remotely ) ...

  • Page 92: Upgrade

    9-7-8. Upgrade Shows the current Firmware version installed on DVR.  Browse: Select BROWSE to locate the firmware file.  Upgrade: Select UPGRADE to upgrade the firmware of the DVR. Please refer to page 59 for the Remote Upgrade. 9-7-9. Information Display general information about the DVR.

  • Page 93: Delete Of Sites

    o Model: User has to select surely a suitable type. SDVR series, H series DVR N series DVR, HD DVR IP Camera o Site Name: Input a name that properly describes a site. o IP Address: Input IP address (Public IP address of a router that DVR is connected.) or Domain name that is registered at www.okddns.com (for Korea), www.ddnscenter.com (for USA) or www.bestddns.com (for other area including EU) o Port Number: Input port number of DVR(Default Port Number is “5445”)

  • Page 94: Connect And Disconnect

    2. Click NET FINDER button. And then the following window displays. 3. Click MODIFY button. And then the modified information is applied. 9-8-2. Connect and Disconnect 9-8-2-1. Connect 1. Select site/sites to connect from the directory window. 2. Click CONNECT button, and then site/sites displays/display as connected.

  • Page 95: Disconnect

    9-8-2-2. Disconnect 1. Select site/sites to disconnect from the directory window. 2. Click DISCONNECT button, and then selected site/sites disconnected. 9-8-3. Still-image capture during Live 1. Double-click a channel to capture from the display screen. (Otherwise all channels will be captured.). 2.

  • Page 96: Recording Video On Local Pc During Live

    3. Set Save path, File Name, and File Format. And then click OK button. 4. Still image is saved as set in Capture window. 9-8-4. Recording Video on local PC during Live 1. Click SETUP button. And then a setup window display. 2.

  • Page 97: Local Playback And Remote Playback

    4. Click RECORD ON button. And the color of button is changed. 5. Live video data is recorded as set in Record and Disk setup. These video data can be searched and play-backed with Local Playback. 9-8-5. Local Playback and Remote Playback 9-8-5-1.

  • Page 98: Playback Of Recorded Video On Remote Dvr

    5. Video data that is recorded on local PC will be play-backed. 9-8-5-1. Playback of recorded video on remote DVR 1. Click REMOTE PLAYBACK button. And then Playback Window display over Live Window. 2. Select site to connect from the directory window. 3.

  • Page 99: Avi Backup During Playback

    4. Move scroll bar on where there is video data and Play button. 5. Video data that is recorded on a remote DVR is play-backed. 9-8-6. AVI Backup during playback You can back up the recorded videos in AVI format during playback. 1.
  • Page 100 5. Click BACKUP. And then the window appears as below. 6. You can also set the beginning time and ending time on this window. After selecting a channel for backup, click the OK button. The backup will begin. 7. AVI video data is recorded as set in AVI Backup window. AVI format video can be played back by Window Media Player™...

  • Page 101: Network - By An Web-Browser Viewer

    10. Network – By an web-browser viewer The DVR provides a live remote monitoring feature by web-browser viewer. (NOTE: Web-Brower is only available for Internet Explorer) 1. Check the IP address of the DVR from SETUP>SYSTEM>DESCRIPTION>IP ADDRESS. 2. Input the IP address or Domain name address that you pre-registered on www.bestddns.com on the address field and press “Go”.
  • Page 102 5. Web Browser Viewer is displayed as bellow. 6. Click CONNECT button on the Left upper corner of web-viewer. Then “Connect” dialog is displayed. Enter IP address (or Domain name address that you pre-registered on www.bestddns.com, www.okddns.com or www.ddnscenter.com, Port number and Password and click “Connect” ...

  • Page 103: Appendix: How To Connect Network

    8. Use mouse scroll to digitally zoom in and out from a single channel display. APPENDIX: How to connect network A. How to set IP address of the DVR and open TCP port of the router? The port forwarding is dependent on the brand and model of the router. The port forwarding is required to allow access to the DVR beyond a router.
  • Page 104 3. But if IP is something else like 192.168.XXX.XXX., you should change IP address, Subnet, Gateway on the DVR. Go to SETUP>NETWORK>LAN of the DVR and change the IP settings to be like IP: 192.168.XXX.XXX and Gateway: 192.168.XXX.XXX. (Refer to the user’s manual of Router.) Open your web browser.
  • Page 105 7. Select the Save settings button located on the bottom of the window. Then Port forwarding is finished. Network access beyond a router In order to access the DVR remotely beyond a router (firewall), the user must open TCP port for command level, live channels and storage channels.
  • Page 106 Internet (ADSL) Connection using DDNS Dynamic Domain Name System (DDNS) allows a domain name to be constantly synchronized with a dynamic IP address. A current dynamic IP address is being associated with a static domain name. 1. Go to SETUP>NETWORK. Set NETWORK TYPE as DHCP and DDNS SERVER as ON. And select one type among bestddns.com, okddns.com and ddnscenter.com after setting to DDNS1.
  • Page 107 7. If you see the screen “You can use the Domain name you entered” then click RETURN and click REGISTER button to complete the registration. 8. Run the pre-install the network client software on the supplied CD. 9. Click button and add the DVR as necessary. ...
  • Page 108 C. How to access DVR with iPhone? Notice Data Usage applied without Wi-Fi connection. Please check with your Phone Carrier. App Viewer for iPhone 1. Enter the Apple App Store. 2. Search “iUMS” in the App Store. LIVE 1. Open the installed “iUMS” App and click button to add a remote device.
  • Page 109 5. To select the display mode(1, 4, 9, 10 or 16 split display), tap the arrow menus button 6. Drag and drop channels Touch and drag one channel to the other channel to swap the channel location. To swap the channel, drag a channel to another channel.
  • Page 110 Playback 1. Select Mode as ‘Playback’ and click ‘CONNECT’ button. Then select Date & Time and click PLAY button. 2. The app will display the selected channel(s). Double tap the channel screen to switch 1 channel display to 4, 8, 10, 16 channels split display depending on the DVR. 3.
  • Page 111 D. How to access DVR with Android? App Viewer for Android Phone 1. Enter Google Play Store. 2. Search “iUMS” in the Android Market and install the “iUMS” app. Live 1. Open the installed “iUMS” App and select the Live Preview. Then click the menu button of the phone to add a remote device.
  • Page 112 Playback 1. Select the registered device and select PLAYBACK and select up to 4 channels to search. Then click START button. 2. The app will display the selected channel(s). Double tap the channel screen to switch 1 channel display to 4 channels split display.
  • Page 113 PTZ Control To control the PTZ function of the camera, tap the channel screen, then the channel name will be highlighted in Yellow. Using the PTZ menu icons on the screen, control PTZF.
