Wired 1000 DPI
& Wireless 1600 DPI
The new paradigm in Shape, Design and Use for computer
mice
User's Guide
The ORTHOMOUSE was nominated for the "ERGOCUP" Award
during the 7th Applied Ergonomic Conference, hosted by the
Institute of Industrial Engineers (IIE) in Orlando, Florida – USA.
The ORTHOMOUSE won the "Excellence in R&D" Award,
by Plano Editorial, São Paulo – Brazil.
Selected to "IDEABrasil" Award of the Associacao Objeto Brazil
Won the "FINEP 2010 Award of TECHNOLOGIC INNOVATION" Brazil.
V 05/2013
Advertisement
Table of Contents
Related Manuals for OrthoMouse Wire 1000 DPI
Summary of Contents for OrthoMouse Wire 1000 DPI
- Page 1 The new paradigm in Shape, Design and Use for computer mice User’s Guide The ORTHOMOUSE was nominated for the “ERGOCUP” Award during the 7th Applied Ergonomic Conference, hosted by the Institute of Industrial Engineers (IIE) in Orlando, Florida – USA.
-
Page 2: Table Of Contents
INDEX INTRODUCTION HEALTH PRECAUTIONS EXCLUSIVE CHARACTERISTICS WIRELESS ORTHOMOUSE VERSION CONECTING THE ORTHOMOUSE TO YOUR COMPUTER (WIRELESS) 05 SETTING UP/REPLACING THE BATTERIES CONECTING THE ORTHOMOUSE TO YOUR COMPUTER (WIRED) RECOMENDATIONS TO THE USER ACCESSORIES ADAPTERS FOR THE PALM OF THE HAND... -
Page 3: Introduction
Do not ignore unexplainable symptoms: see a doctor You should know that, all over the world, medical immobilization of the hand out of the “position of function” is considered “medical malpractice”. ORTHOMOUSE: Ask your Orthopaedic Practitioner... -
Page 4: Exclusive Characteristics
ORTHOMOUSE: The right shape for your hand Unique Characteristics that make the difference • Its form imitates the shape and proportions of the hand that uses it, while the hand and fingers copy the attitude of writing with the same natural configuration. -
Page 5: Wireless Orthomouse Version
Its functions will be reduced, however any touch in any button or movement of the mouse will reactivate them all. Even in “sleep” mode, the OrthoMouse still consumes energy and this is why it is recommended, after the end of use, that it is switched off. -
Page 6: Setting Up/Replacing The Batteries
SETTING UP/REPLACING THE BATTERIES (Turn the OrthoMouse over and turn it off: move the ON/OFF switch to OFF) 1 - Remove the adapter of the OrthoMouse. Now 2 – Remove the battery compartment cover with the you have access to the batteries compartment. -
Page 7: Conecting The Orthomouse To Your Computer (Wired)
When correctly positioned, the batteries should look as shown below. 7 – Replace the battery compartment cover. 8 – 9 - Replace the adapter of the OrthoMouse. 10 - Turn the OrthoMouse ON if you will use it. Connecting the ORTHOMOUSE WIRED to your computer USB Connection (Windows,... -
Page 8: Recomendations To The User
For optimum results, please pay attention to a few details: 1. The ORTHOMOUSE has been designed to comply with the concept of “passive adaptation” or total rest. Thus, during the use of ORTHOMOUSE your hand will remain at rest, assuming the so-called “position of function”. -
Page 9: Accessories
If the tendons of the fingers extensors are in evidence, there is still effort. Usually there will be an evolution leading to the relaxation, as the user continuously works with the Dr. Segalle ORTHOMOUSE. FULL ELIMINATION OF THE AFOREMENTIONED SIGNS OF EFFORT SHOULD BE ACHIEVED BEFORE EVALUATION OF THE COMFORT LEVEL AND USABILITY. -
Page 10: Upper Adapters
By supporting the hypothenar eminence on the OrthoMouse, the hand will tend to be placed more to the forward part of the OrthoMouse. This posture will allow the index and middle finger to fall closer to the bottom of the two main buttons, where the effort to click is minimal. This will also place the thumb closer to the thumb's buttons. -
Page 11: The Five Buttons
Fig 8. – Scrolling Buttons As any optical mouse, the ORTHOMOUSE needs a minimally reflective surface, in order to work. In other words, it will not function properly over a transparent surface. In this case, we recommend the use of a mouse pad. -
Page 12: Special Configurations - Windows
“Enhance pointer precision”, and then click “Apply” and “OK”. After a few days of practice with the ORTHOMOUSE, you may go back to this Control Panel and select an even higher speed, which will drastically reduce the sideways displacements of hand and forearm. -
Page 13: Care And Maintainance
To clean the ORTHOMOUSE you need to first to disconnect it from the computer (the wireless OrthoMouse should be turned off). Just swipe a damp cloth over its surface. The area around the sensor must be cleaned with a flexible cotton swab moistened with water and neutral soap. -
Page 14: Technical Data
Cable not included (40gr). Gross Weight Wired OrthoMouse: box, with all adapters, CD and leaflets: 280gr. Wireless OrthoMouse: box, with all adapters, CD and leaflets: 240gr (batteries not included). Product designed for use with the right hand OrthoMouse Wireless Laser 1600 DPI uses:... -
Page 15: Patents
Patents This product is innovative, and is protected by the following granted patents: USA: No. 6,300,941, No. 6,532,002 and 7,755,609. Canada: No. 2,347,082. Mexico: No. 226,639. Brazil: No. 5,901,042-8, No. 7,903,331 and No. 8,400,186-0 Argentina: No. 009,205 B4. Japan: 4,414,101. Patents pending in other countries.
