AIRAVE™ User Guide
Get Set Up
You'll need to connect your AIRAVE to a router or a broadband (cable or DSL) modem.
Have a router? Please use the setup instructions on this page. Just have a modem? Please see page 2.
If you have a router or all-In-one router/modem:
1.
Place your AIRAVE in a central location close to a window. An elevated location, such as the top of a bookshelf
or tall cabinet, works best.
2.
Connect the external GPS antenna to the AIRAVE and place the antenna on a flat surface as close to a window
as possible.
3.
Connect one end of the included yellow Ethernet cable to your AIRAVE's yellow WAN port.
4.
Connect the other end of the yellow Ethernet cable to an open Internet/Ethernet/LAN port on your router.
5.
Plug the power supply connector into the black power port on your AIRAVE.
Please note: To prevent damage to your AIRAVE, do not plug the power cord into an electrical outlet yet.
6.
Connect the power cord into the power supply and then plug it into an available outlet.
External GPS antenna
Power supply
7.
The AIRAVE will turn on and go through an automated setup sequence that may take up to two hours. During
this time, the LEDs will change color.
8.
Once the Broadband, GPS and Mobile LEDs are solid green, your AIRAVE is ready to use. Your phone(s) will
automatically connect to the AIRAVE when in range.
Please note: When you're connected to the AIRAVE, you'll hear three short beeps at the start of each call. You may
not hear the beeps the first few times after your AIRAVE is activated.
GPS
PHONE
LAN2
LAN1
WAN
AIRAVE
1
Router
Advertisement
Table of Contents
Summary of Contents for Credo mobile AIRAVE
- Page 1 Have a router? Please use the setup instructions on this page. Just have a modem? Please see page 2. If you have a router or all-In-one router/modem: Place your AIRAVE in a central location close to a window. An elevated location, such as the top of a bookshelf or tall cabinet, works best.
- Page 2 If you have a modem only: Unplug the power cord on your modem. Place your AIRAVE in a central location close to a window. An elevated location, such as the top of a bookshelf or tall cabinet, works best. Connect the external GPS antenna to the AIRAVE and place the antenna on a flat surface as close to a window as possible.
-
Page 3: Troubleshooting
If your aIrave Isn’t workIng after setup Please keep in mind that it can take up to two hours for the AIRAVE to begin working after installation. If it’s been two hours and the Broadband, GPS and Mobile LEDs haven’t turned solid green: Verify that your AIRAVE has been set up correctly by following the setup instructions in the Get Set Up section above. - Page 4 The Mobile, GPS and Broadband lights can help you troubleshoot problems. The voicemail and VoIP lights will always be off as these features of the AIRAVE aren’t available. (You’ll still get voicemail on your phone.) Display pattern...
-
Page 5: Safety Information
Although your AIRAVE is quite sturdy, it is a complex piece of equipment and can be broken. Avoid dropping, hitting, bending, or sitting on it. Do not immerse the AIRAVE in water or get it wet. If it does get wet, unplug it immediately and leave it unplugged until it dries. -
Page 6: Fcc Information
The AIRAVE will be covered under our limited warranty for the full duration of time the device is used through CREDO. If the device is physically damaged, the warranty is void and replacement will cost $279.00.
