Summary of Contents for RIGE DMX 300W
- Page 1 RIGE TECHNOLOGY CO., LIMITED DMX 300W BEAM MOVING HEAD User manual RG- - - - M10 - 1 -...
- Page 2 RIGE TECHNOLOGY CO., LIMITED Congratulations on purchasing this 300W BEAM moving head. Thank you for extending your trust in our technology! For reasons of safety and approval (CE) the personal reconstruction and/or modification of this product is prohibited. Please observe that damage caused by modifications performed manually to this device is not covered by the warranty.
- Page 3 RIGE TECHNOLOGY CO., LIMITED 2. Supply Voltage, Mains Cord and Connection to Mains ATTENTION: DANGER OF LIFE! RISK OF FIRE! RISK OF SHORT CIRCUIT! The handling of supply voltage, mains cords and connections to mains calls for particular care considering...
- Page 4 RIGE TECHNOLOGY CO., LIMITED Easily flammable materials, e.g. decoration material and other surfaces and objects, must maintain a minimum distance of 3m to the housing! Walls must maintain a minimum distance of 50cm to the housing! The device must be installed on a fireproof surface only (no carpet)! Always ensure a proper circulation of air.
- Page 5 RIGE TECHNOLOGY CO., LIMITED This product can be operated suspended or as a stand-alone system. Should your lighting effect show any signs of damage, do not install the device! In this case, have your lighting effect repaired by your specialized dealer. It does not accept responsibility or liability for damage to...
- Page 6 RIGE TECHNOLOGY CO., LIMITED dis/connecting the product repeatedly and quickly from/with mains! Always wait 15 minutes prior to the next dis/connection! The device starts until a self-testing and starting time. If the moving head is ready to start, push and roll the function wheel.
- Page 7 RIGE TECHNOLOGY CO., LIMITED Test running. If need to exit, press "ESC" exit 2. Ast (mainframe controls) This feature allows you to run the test when need be host DMX synchronized signal sent out to vice machine use. Press the "UP" or "DOWN" choose other mode, click "ENTER" , show "ON" as host send signals, DMX signal indicator emit light.
-
Page 8: Dmx Channels
RIGE TECHNOLOGY CO., LIMITED Size 400*380*650mm DMX Channels X (Pan 540°) 0-255 0-540 Y (Tilt 270°) 0-255 0-270 Pan/Tilt Speed 0-255 X,Y spead adjustable 0-255 Dimming On/Off, strobe 0-255 Slow to fast, strobe On/Off, strobe 0-23 White 24-47 48-71 Yellow... - Page 9 RIGE TECHNOLOGY CO., LIMITED 7. Lamps ATTENTION: DANGER OF LIFE! RISK OF BURNS! RISK OF FIRE! During operation, the lamps will reach temperatures of up to 200°C. Touching the lamps may cause serious burns! Objects coming into contact with the lamps during and shortly after operation may catch fire! Disconnect the product from mains prior to installing or before changing a lamp! Allow a lamp to cool for approx.
- Page 10 RIGE TECHNOLOGY CO., LIMITED Ensure that the product is completely dry before operating it again after cleaning! 10. Transport CAUTION: FRAGILE! To avoid damage caused during transport, wrap the product in its original packaging only and handle it with great care during transport! Please note: All information is subject to change without prior notice.
