- Page 1 MCN AUDIO U4410 HEADPHONES AMPLIFIER USER’S MANUAL OPTIONS Option 96 Service Manual. Option 80 FRB Mains Connector Option 81 CEI Mains Connector ACCESSORIES W1101-80 Power cord 2.5m length / FRB connector W1101-81 Power cord 2.5m length / CEI connector SERIAL NUMBER...
-
Page 2: Table Of Contents
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER CONTENT GENERALITIES WARRANTY SPECIFICATIONS PRECAUTIONS HEADPHONES - Safety Warning SYNOPTIC FRONT PANEL REAR PANEL - Option 81 INPUT AND OUTPUT LEVELS BANDWIDTH INDEX Due to permanent technical improvements, specifications listed here can change... -
Page 3: Generalities
An internal switch adjusts the impedance (50 ohms or 600 ohms) to match the headphone specification. A specific amplifier design provides a large power headroom and a high signal to noise ratio. The U4410 can handle all the dynamics of today’s digital recordings without distortion. -
Page 4: Warranty
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER WARRANTY This equipment is warranted against defects in material and workmanship for a period of five (5) years from date of delivery. The warranty will be voided if the unit is tampered with or serviced by unauthorized personnel. -
Page 5: Specifications
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER SPECIFICATIONS INPUTS Balanced: Two channels transformerless left and right inputs. Nominal level +4 dBm, 1.2 Vrms Maximum level +28 dBm, 19.4 Vrms. Balanced impedance 10 kOhms. Common mode impedance 5 kOhms. Protection Against phantom power. -
Page 6: Precautions
The mains voltage is preset to the value indicated on the rear panel. Please check that the voltage value indicated on the rear panel matches the main network voltage. Main voltage is set internally. To change this setting, please contact your local dealer or MCN AUDIO technical support. -
Page 7: Synoptic
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER SYNOPTIC Left and Right channels are identical. INPUTS IN RIGHT PHONES LEVEL AMPLIFIERS OUTPUTS STEREO IN LEFT TO LEFT CHANNEL MAINS POWER -6dB TO CLIP LEVEL DETECTION SUPPLY POWER ON OVER LEFT/RIGHT LED LAMPS... -
Page 8: Front Panel
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER FRONT PANEL POWER ON The blue ON pilot light is lit when the unit is ON. When the rear power switch is set to OFF, the unit is disconnected from the power. The power cable can stay plugged in without risk. -
Page 9: Rear Panel - Option 81
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER REAR PANEL - Option 81 Male XLR or 6.35 mm JACK connectors can be plugged in the input sockets. STEREO A Stereophonic 6.35 mm JACK connector for unbalanced stereophonic input A. STEREO B Stereophonic 6.35 mm JACK connecfor for unbalanced stereophonic input B. -
Page 10: Input And Output Levels
In case the OVER pilot lamps light up as soon as the amplifier is connected to a source, even if no audio signal is present, check for DC residual voltage at the source output. Using the U4410 on such source can cause damage to your headphones. -
Page 11: Index
MCN AUDIO - U4410 - HEADPHONES AMPLIFIER INDEX Balanced, 9 Nominal input level, 10 BALANCED INPUTS, 10 Bandwidth, 10 Bias point, 10 ON pilot light, 8 Outputs, 10 OVER LEFT, 8 Combo, 3 Overload pilot light, 8 Clipping, 8 OVER RIGHT, 8... - Page 12 MCN AUDIO - U4410 - HEADPHONES AMPLIFIER MCN AUDIO On line: www.mcn-audio.com Document Code : UM-EV-U4410D-V4...
