Summary of Contents for TotalFlow µFLO

  • Page 1 2100890-001 (AB) ® TOTALFLOW µ FLO Computer User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice ©2003 by ABB ,Inc., Totalflow Products, Bartlesville, Oklahoma 74006, U.S.A. All rights reserved. This publication is for information only. The contents are subject to change without notice and should not be construed as a commitment, representation, warranty, or guarantee of any method, product, or device by Totalflow.

  • Page 3: Table Of Contents

    Table of Contents Introduction ......................... ix About the Manual ......................... ix Key Symbols ..........................ix Getting Help ..........................x Safety Practices and Precautions ....................x Chapter 1 System Description .................1-1 Overview ............................1-1 µ FLO Computer Hardware ......................1-6 µ FLO General Specifications ....................1-9 µ...
  • Page 4 µ Setting up the FLO......................3-3 Overview ............................ 3-3 Station ID ........................... 3-3 Location ............................. 3-3 Date/Time ..........................3-3 Security System ......................... 3-4 µ Configuring the FLO ......................3-5 Contract Hour ..........................3-5 Volume Calculation Period ......................3-5 Log Period ..........................3-5 Calculation Type ........................
  • Page 5 Zero Transducer........................4-16 Troubleshooting........................4-17 Reset Procedures ........................4-17 Visual Alarm Codes........................4-21 Troubleshooting Alarms ......................4-22 Communications Overview ......................4-24 RS-232 Communications ......................4-24 RS-485 Communications ......................4-26 RS-422 Communications ......................4-28 Wake-Up ..........................4-30 ® Chapter 5 Totalflow Definitions and Acronyms............5-1 Chapter 6 Drawing & Diagrams ................6-1...

  • Page 7: Table Of Figures

    Table of Figures Figure 1–1 µFLO 6213 Dimensions ...................1-2 Figure 1–2 µFLO 6210 Dimensions ...................1-3 Figure 1–3 Bottom View µFLO 6213..................1-4 Figure 1–4 Bottom View µFLO 6210..................1-4 Figure 1–5 Integral Multivariable Transducer (IMV)..............1-5 Figure 1–6 µFLO 2100767 Board, Complete Overview .............1-7 µ...

  • Page 9: List Of Tables

    List of Tables µ Table 1–1 FLO 2100767 Board Identifications, Complete Overview........1-7 µ Table 1–2 Typical FLO Display Options ................1-14 µ Table 1–3 FLO Status and Alarm Description ...............1-15 µ Table 2–1 FLO 2100767 Board Identifications, Installation...........2-15 Table 3–1 Configurable Calculation Factors ................3-6 Table 3–2 Gas Orifice Constants ....................3-7 Table 3–3 Fpv Analysis Data .....................3-8 Table 3–4 Alarm Limits ......................3-9...
  • Page 10 viii...

  • Page 11: Introduction

    About the Manual This manual is written to provide an experienced flow meter technician with the requirements necessary to install, setup and operate a Totalflow Flow Computer System. Organization & Each of the chapters in this manual presents information in an organized and concise manner.

  • Page 12: Getting Help

    Getting Help At Totalflow, we take pride in the on going support we provide our customers. When you purchase a product, you receive documentation which should answer your questions; however, your Totalflow technical support provides you an 800 number as an added source of information.
  • Page 13 Safety Practices and Precautions, Continued Danger A grounding conductor may or may not be required depending on the hazardous Arising classification. If required, any interruption of the grounding conductor inside or outside the equipment or loose connection of the grounding conductor can result in a From Loss of dangerous unit.

  • Page 15: Chapter 1 System Description

    Flow Computers. Based on ABB Totalflow XSeries technology, it is designed to provide a cost effective alternative to the multi-feature, multi-tube XSeries Flow Computer.
  • Page 17 3.141 4.355 4.186 13.206...

  • Page 18: Figure 1-3 Bottom View Μflo 6213

    Figure 1–3 Bottom View µFLO 6213 9.992 8.647 9.367 Figure 1–4 Bottom View µFLO 6210...

  • Page 19: Figure 1-5 Integral Multivariable Transducer (Imv)

    Figure 1–5 Integral Multivariable Transducer (IMV) Overview, Continued The µFLO defaults to retention of daily and log period records for 40 days and Capabilities retention of 200 events. These defaults can be extended, limited only by the file space on the device. This model may be used in conjunction with the handheld FS/2 and/or a laptop computer running PCCU32 software.

  • Page 20: Flo Computer Hardware

    µ FLO Computer Hardware The Totalflow® µFLO 6200 Computers are housed in a lightweight single compartment aluminum case. It’s components are: • Aluminum enclosure • µFLO 2100767 Board • Integral Multivariable Transducer • Liquid Crystal Display (LCD) • Resistive Temperature Detector (RTD) •...

  • Page 21: Figure 1-6 Μflo 2100767 Board, Complete Overview

    Figure 1–6 µFLO 2100767 Board, Complete Overview µ Table 1–1 FLO 2100767 Board Identifications, Complete Overview Number Description Number Description Remote Communication Connector Flash Program Memory Security Switch E Prom Loader and Utilities Memory Battery Connection 195 Mhz Processor External Charger Lithium Battery S Drive (Serial E2 Prom) Battery Cover...
  • Page 22 µFLO, must be purchased Options from Totalflow. Optionally you may purchase a COMM+IO Board (µFLO Comm Board) designed for field wiring by knowledgeable technicians. See Figure 1–7. In addition to the field terminations for wiring, this board contains one DI and one DO.

  • Page 23: Flo General Specifications

    µ FLO General Specifications Certification Designed to meet CSA/NRTL Class 1, Div. 2, Groups C & D hazardous area classification. Dimensions Model Width Height Depth 6213 12.76” (324.00mm) 17.81” (452.40mm) 10.27” (260.83mm) 6210 9.99” (253.80mm) 13.21” (335.43mm) 9.37” (237.92mm) Installed Model Pipe Mounted Wall Mounted...

  • Page 24: Flo 2100767 Board

    µ FLO 2100767 Board Power Nominal Batery 12 VDC Charger Solar or 16–18 VDC • 512K SRAM (Data Storage). RAM memory has lithium backup battery. Memory • 512K Flash (Program Application Storage). • 512K PROM (Flash Loader) • 32K E PROM (Registry Configuration files) •...

  • Page 25: Functions Of The Μ Flo

    µ Functions of the Functions of the µFLO reflect a design that is practical, straight-forward and efficient. The µFLO is simple to use and easy to learn - and it saves time usually spent on calculations and report preparation. The µFLO allows you to perform the following with minimum effort, maximum speed and greater accuracy.

  • Page 26: Functions Of The Flo

    µ Functions of the FLO, Continued Additional Additional features of the Totalflow System enabling its flexibility include the Features following: • Programmable differential pressure zero cutoff • Programmable bi-level security codes to prevent unauthorized communication and configuration of the µFLO .
  • Page 27 Log Period Records, Continued µ Changing µFLO clock could affect the time when next log period entry is made. To Changing protect integrity of accounting audit trail, µFLO handles these types of clock Clock changes as follows: Clock Change Not Crossing an Hour Boundary: When next log period entry is made, clock is not altered.

  • Page 28: Display Function

    Display Function During operation, the front panel LCD continuously scrolls through the operating parameters. Table 1–2 shows typical displayed parameters, however any parameter with a Register Address can be displayed. The duration that the parameter is displayed can vary from 1 to 255 seconds (default is 5 seconds); a setting of 0 seconds will set any display to off.

  • Page 29: Status And Alarm Conditions

    Status and Alarm Conditions Since a primary function of the µFLO is to provide complete volume and operational records; it is important to indicate unusual or “alarm” conditions as they occur. See Figure 1–8. This is supported on the LCD using indicators, these are listed in Table 1–2 µFLO Status and Alarm Description. Instructions for using the display as a troubleshooting aid can be found in Chapter 5.
  • Page 30 Communication Protocols, Cont ID Recognized. Recognized and receiving request. Listen Cycle. Flashes if this remote port is active and running Totalflow Remote Protocol. Flashes in sync with listening cycle that occurs at 1, 2 or 4 second intervals. MODBUS ASCII: Modbus ASCII protocol selected for the port assigned to this annunciator.

  • Page 31: Chapter 2 Installation

    Chapter 2 Installation Overview This Chapter provides you with the information for installation and setup. By the time you finish this Chapter you will have the µFLO unpacked, installed, field wired and ready for operation. For safe and trouble free installation follow all instructions and advisories. Read through this Chapter before you begin the installation, to plan your installation.

  • Page 32: Unpacking & Inspection

    Totalflow representative. Keep all shipping materials for the carrier's inspection. Components Totalflow will arrange for immediate repair or replacement; see 'Getting Help', page Meter Run Installation Overview The following procedures, unless otherwise stated, are applicable to all µFLO Computers. The µFLO can either be pipe, direct or wall mounted.

  • Page 33: Figure 2-1 Bottom View Of Μ Flo 6213 With Imv

    (2.13) (10.27) (1.63) (.81) (3.74) µ Figure 2–1 Bottom View of FLO 6213 with IMV (2.13) (9.37) (1.63) (.81) (3.79) µ Figure 2–2 Bottom View of FLO 6210 with IMV...

  • Page 34: Pipe Mount Installation

    • One 2” x 40” pipe • Standard 3 or 5 valve manifold • Stainless steel tubing Optional equipment may be ordered from Totalflow. µFLO AC Battery Charger Low Input (L) High Input (H) To Customer Provided AC Power Source...

  • Page 35: Figure 2-4 Typical Pipe Saddle Installation

    Pipe Mount Installation, continued Instructions Step Procedure Position pipe saddle on meter run. Select a location that allows easy user access and is close to the orifice fittings. Lines should be as short as possible. Temporarily attach Saddle on meter run pipe using U-bolt and associated hardware.

  • Page 36: Figure 2-5 Μ Flo Pipe Mounted

    Pipe Mount Installation, continued Step Procedure, Continued Position µFLO in position on 2” mounting pipe and secure in place with two U-bolts, flat washers, lock washers and two bolts. See Figure 2–5. Flat and lock washers with nut Mounting Bracket U - Bolt 2 "...

  • Page 38: Wall Mount Installation

    Wall Mount Installation If you are installing to a wall near the meter run or inside a meter shed use this procedure. Before you begin, review the procedure and the materials required for installation. Refer to Figures 2–7for mounting dimensions requirements. •...

  • Page 40: Direct Mount Installation

    Direct Mount Installation If you are installing the µFLO directly to an instrument manifold use this procedure. Before you begin, review the procedure and the Direct Mount Drawing. See figure 2–8. All required hardware for mounting to the µFLO to the manifold is to be supplied by the customer.
  • Page 41 2-11...

  • Page 42: Manifold Input Lines

    Manifold Input Lines The following instructions will provide procedural steps to install the manifold. The meter run manifold high (H) and low (L) pressures terminate in µFLO H and L Differential Port cells. Differential Port cells are located on bottom of µFLO . See Figure 2–9. RIGHT LEFT DIFFERENTIAL...

  • Page 43: Rtd Probe Installation

    Manifold Input Lines, Continued Instructions Step Procedure Install isolation valves on meter run (if using 5 or 3 way manifolds). Install manifold and tubing to meter run and µFLO. (Note: Manifold to µFLO fittings not supplied with µFLO). Leak check all connections. Leaks in the tubing or manifold will introduce errors when calibrating IMVs.
  • Page 44 RTD Probe Installation, Continued Instructions Step Procedure Install thermowell into meter run. Thermowell RTD Assembly Meter Run To prevent moisture from entering µFLO after installing RTD cord connector, be certain associated connector, at µFLO, has a metal backed sealing “O” ring and metal locking nut attached.

  • Page 45: Figure 2-11 Μ Flo 2100767 Board Cutout, Installation

    µ Figure 2–11 FLO 2100767 Board Cutout, Installation µ Table 2–1 FLO 2100767 Board Identifications, Installation ID Number Description Remote Communication Connector Security Switch Battery Connection External Charger S Drive (Serial E Prom) RTD Connector 2-15...

  • Page 46: Battery Pack Installation

    Pack Installation. If installation procedures are required for mounting Solar Panel on top or side of meter house, customer should contact Totalflow’s Service Department; see page x, Getting Help. Our standard solar panel must be mounted within 12 feet of µFLO. For Solar Panel Procedure mounting, the following materials are required.

  • Page 47: Mounting Bracket

    Solar Panel Installation, Continued Exercise caution when installing Solar Panel, so as not to damage it. When mounted, Solar Panel will face up from horizon at 50° angle. Instructions Step Procedure Attach 2” pipe Coupling to top end of µFLO 40” mounting pipe. Securely tighten.

  • Page 48: Ac Charging Unit Installation

    Figure 2–12 Typical Solar Panel Installation Solar Panel Installation, Continued Instructions, Continued Step Procedure Install Solar Panel on mounting bracket, if required, with provided hardware. Install Solar Panel Cable if required. Attach Solar Panel mounting plate to top end of 2” extension pipe with U- bolts and associated mounting hardware.
  • Page 49 The AC Charging Unit is shipped separately. When unit is received, unpack and inspect all components for evidence of damage. Report damage to shipping carrier and to Totalflow’s Service Department. Remove one of the plugs from the side of µFLO so that AC charging unit can be mounted without obstruction;...

  • Page 50: Figure 2-13 Mounting Ac Charger

    Figure 2–13 Mounting AC Charger 2-20...

  • Page 51: Flo Startup

    Chapter 3 µ FLO Startup Overview This Chapter generally describes the steps required get a newly installed µFLO system up and running. Specific information required to complete each step (depending on your equipment choice) is discussed in the PCCU32 help files, or the Operations manual for the FS/2 Portable Calibration and Collection Unit. Highlights In this Chapter you will learn about: Topics...

  • Page 52: Laptop Computer Running Pccu32

    Overview, Continued Before you begin you should complete the tasks outlined in the Chapter 2.0, Installation. All references in older materials to AP, absolute pressure, have been converted to SP, Static Pressure. This reflects the difference of including barometric pressure during calibration.

  • Page 53: Setting Up The Μ Flo

    µ Setting up the Overview Once physically connected to the µFLO, you must then instruct the software of the programming device to connect. At this time, the software will actually read the device default values programmed at the factory. These preset values are based on the type of product you ordered and programmed for the most widely used configuration.

  • Page 54: Security System

    Security System The µFLO 2100767 Board has a bi-level security system built in. For the purpose of this manual, we will refer to this as the Hardware Security. When the µFLO is accessed through PCCU32 or WINCCU Host software packages, this will have a third level of security included. We will refer to this as the Software Security.

  • Page 55: Configuring The Flo

    µ Configuring the Contract Hour You can program the µFLO to begin the contract day based on your contract or company standards. When a µFLO first powers up the contract is preset to begin at midnight. Midnight is 00 o’clock. If any value entered is greater than 23, you will record an error message and the µFLO forces the value to 00 (midnight).

  • Page 56: Table 3-1 Configurable Calculation Factors

    Calculation Type, Continued Table 3–1 Configurable Calculation Factors Configurable Calculation Parameter AGA-3 1985 AGA-3 1992 Fpb (Pressure Base Factor) Ftb (Temperature Base Factor) Fg (Specific Gravity Factor) Fb (Orifice Factor) Ftf (Flowing Temperature Factor) Y (Expansion Factor) Fr (Reynolds Number) Fa (Orifice Thermal Expansion Factor) Fpv (Supercompressibility Factor) Fw (Water Vapor Factor)

  • Page 57: Constants

    Constants On a single tube gas orifice meter, there are certain constants or parameters that may need to be entered or changed from the default values. Depending upon the calculation type you have selected, only the applicable constants shown in Table 3–2 will be visible. Table 3–2 Gas Orifice Constants Configurable Default Value...

  • Page 58: Super Compressibility Calculation (Fpv)

    Super Compressibility Calculation (Fpv) When the µFLO is powered up, the calculation is preset to NX-19 GCN or GCNM. You have the option of changing the formula method to any of several other choices: NX19 Fixed, AGA8 Gross 92 or AGA8 Detail 92.

  • Page 59: Alarm Limits

    Alarm Limits You have the ability to set µFLO Alarm Limits for the parameters listed in table 3–4. There are many purposes for setting these limits. i.e. Controlling well output, or sending digital signals. Table 3–4 Alarm Limits Configurable Parameter Default Value Units AGA-3 1985...
  • Page 60 3-10...

  • Page 61: Startup Μ Flo

    µ Startup µ FLO On Line To avoid a calibration shift, carefully follow these instructions. Open both bypass valves and close the vent to atmosphere valve, this stabilizes the Instructions pressure on both sides of the cell. Then begin to SLOWLY open the high side orifice tap valve from the meter run.
  • Page 62 3-12...

  • Page 63: Flo Standard Displays

    µ FLO Standard Displays Program Display The single tube µFLO comes from the factory with a set default displays as shown below. By default, each display item remains on the display for 5 seconds. You have the ability to change this default to zero (item not displayed) or any value from 1 to 255 seconds.
  • Page 64 3-14...

  • Page 65: Overview

    Communications Overview 4-24 RS-232 Communications 4-24 RS-485 Communications 4-26 RS-422 Communications 4-28 Wake-Up 4-30 If installation, calibration and maintenance assistance is required, user can contact Maintenance the Totalflow Service Department. Support USA: (800) 442-3097 or International: 001-918-338-4888 Continued on Next Page...
  • Page 66 LCD display. µFLO alarm troubleshooting procedures are presented in the Troubleshooting Chapter. Returning If a TOTALFLOW component is to be returned to Totalflow for repair, securely wrap Part(s) for it in protective anti-static packaging. Before returning a component, call us for a Return for Authorization Number (RA).

  • Page 67: Configuring The Μ Flo

    Maintenance Backing up Configuration Files Before you begin any maintenance on your µFLO, you should collect the data and back up all configuration files to your laptop's hard drive or a floppy disk. This safeguards your data and allows you to re-start the unit without the hassle of re-configuring the µFLO should any problem arise.

  • Page 68: Replacing Μflo Battery Pack

    µ Replacing FLO Battery Pack This section presents the procedures for removal and installation of µFLO battery pack. To access the battery pack, open µFLO door. Battery pack is located in the upper portion of the chamber, on top of the battery shelf.

  • Page 69: Figure 4-1 Μ Flo 2100767 Board Cutout, Maintenance

    µ Figure 4–1 FLO 2100767 Board Cutout, Maintenance µ Table 4–1 FLO 2100767 Board Identifications, Maintenance ID Number Description Remote Communication Connector Security Switch Battery Connection External Charger PCCU Interface Contrast Potentiometer LCD Display Interface Lithium Battery Battery Cover Battery Mounting Bracket Memory Backup Enable/Disable RTD Connector...

  • Page 72: Replacing Liquid Crystal Display (Lcd) Board

    Table 4–2 µFLO 6210/6213 Component Identifications ID Number Description 6213 Enclosure PCCU Internal Cable Door LCD Display External PCCU Connector Radio Mounting Bracket (6213 only) Battery Cover Lithium Battery IMV (Integral Multivariable Transducer) Door Latch Model & Serial Number Plate Field ID Tag Pipe Mounting Bracket Replacing Liquid Crystal Display (LCD) Board...

  • Page 73: Replacing Integral Multivariable Transducer (Imv)

    Using a 3/16” nut driver, remove four Display Board hexagonal mounting standoffs. Lift Board from door mounted standoffs. If Board is being returned to Totalflow for service, it is recommended that attached ribbon cable be left connected and returned with Display Board.

  • Page 74: Figure 4-4 Flow Computer With Discrete Manifold

    LOW SIDE HIGH SIDE LEFT RIGHT DIFFERENTIAL DIFFERENTIAL PORT PORT ALTERNATE BYPASS BYPASS PRESSURE HIGH SIDE LOW SIDE SOURCE VALVE VALVE VENT TO ATMOSPHERE ORIFICE VALVES TO PIPE RUN Figure 4–4 Flow Computer with Discrete Manifold 4-10...
  • Page 75 Replacing Integral Multivariable Transducer (IMV), Continued Instructions, Continued Step Procedure Disconnect the following associated connectors (if used) in this order. • External charger connected to J7 (Figure 4–1, Item 4) • Battery Pack connected to J6 (Figure 4–1, Item 3) •...

  • Page 76: Callibration Overview

    1. Exit Calibration mode 2. Unplug DATA cable at µFLO connector Totalflow recommends performing a five point check before and after calibration. During normal operation, either cell could be knocked out of calibration (typically due to a slug of liquid). WinCCU, the host software, is capable of recalculating the volume based on the differences between the previous five point check and the current five point check.

  • Page 77: Checking Static Pressure (Sp)

    Checking Static Pressure (SP) The µFLO allows you to check the Static Pressure Calibration and log the pressure marker check points. It is recommended that checks of the Static Pressure (SP) be done prior to and directly following the calibration. During normal operation of the µFLO, the display provides continuous SP readouts.

  • Page 78: Checking Differential Pressure (Dp)

    Checking Differential Pressure (DP) As discussed above under “Checking Static Pressure (SP) Calibration”, it is recommended that checks of the Differential Pressure (DP) be done prior to and directly following calibration. You can enter as many DP pressure markers as you desire. Recording too many markers may cause the µFLO to overwrite existing older events.

  • Page 79: How To Change Orifice Plate

    Volume command instead. While seemingly unnecessary, if the Volume Calculation Period is set to anything less than 60 minutes, Totalflow recommends performing either the Reset Log Period or the Reset Volume command to enhance the audit trail created by the event.

  • Page 80: Zero Transducer

    Zero Transducer During the process of setting pressure markers to determine the need for a calibration of either the Static Pressure (SP) or the Differential Pressure (DP), you may conclude that the SP or the DP pressures are out of alignment exactly the same amount at each pressure marker (linear shift). When this occurs, you may either re-calibrate the µFLO or you may set the Transducer to zero.

  • Page 81: Troubleshooting

    Troubleshooting Reset Procedures After closing µFLO door, check door mounted LCD for normal operational readings. Cold Start A cold start clears all the data that is stored in RAM as well as resetting all entered variables to their factory default values. A cold start should be used for new µFLO installations.
  • Page 82 Reset Procedures, Continued Warm Start A warm start occurs when the charging source and main power is removed, then re-applied while memory backup is enabled. This does not clear the data stored in RAM. The warm start will only reset the µFLO microprocessor and not disturb any data that has been stored in RAM.
  • Page 83 4-19...

  • Page 84: Table 4-4 Μ Flo 2100767 Board With Communication Configurations

    µ Table 4–4 FLO 2100767 Board with Communication Configurations ID Number Description Remote Communication Connector Security Switch Battery Connection External Charger S Drive PCCU Interface Contrast Potentiometer Static Ram (R Drive) LCD Display Interface Flash EPROM Processor Lithium Battery Battery Cover Battery Mounting Bracket Memory Backup Enable/Disable RTD Connector...

  • Page 85: Visual Alarm Codes

    Visual Alarm Codes After the µFLO completes recording hourly flow and operational records the LCD will show any alarm conditions that have occurred (see Figure 4–6). Also, the date, hour and type of alarm conditions are stored in the µFLO memory. An alarm can be a word, character, letter or symbol. The entire list of Status and Alarm codes may be found in Chapter 1, Table 1–2.

  • Page 86: Troubleshooting Alarms

    Troubleshooting Alarms Alarm conditions and their probable cause, and procedure(s) for correcting the problem, are presented below in Table 4–6. Table 4–6 Troubleshooting Alarm Codes In the following procedure, the common name for a component or it’s jumper number if available (abbreviated J) or part is followed by a number in parentheses.
  • Page 87 Troubleshooting Alarms, Cont. Table 4–6 Troubleshooting Alarm Codes, continued Alarm Probable Condition Cause Procedure Temperature A faulty RTD Probe, or loose wiring connection(s), can cause an AD alarm Measurement code. Causing Alarm • Check RTD wiring on board terminal connector J9 (Figure 4–5, Item 17).

  • Page 88: Communications Overview

    Communications Overview These troubleshooting procedures are applicable only to a µFLO with an installed radio communication unit. The three basic types of radio communications that can be used between the µFLO and a radio receiver, are: • RS-232 Communications • RS-485 Communications •...
  • Page 89 RS-232 Communications, Continued Table 4–7 Troubleshooting RS-232 Serial Communication, Cont. Power to transceiver can be provided from the µFLO’s power supply. This allows µFLO to switch external power to transceiver. Switching is accomplished using a 12VDC switch line connected to the 2100888-002 field termination board TB1-7 SWVBATT (WHT).

  • Page 90: Table 4-8 Troubleshooting Rs-485 Communications

    RS-232 Communications, continued Table 4–7 Troubleshooting RS-232 Serial Communication, continued Procedure Instructions Measuring Using an oscilloscope or digital voltmeter, connect it to the 2100888-002 field Transmitting Data termination board TB1 (Figure 4–5, Item 19) green connector across the (TXD+) Voltage following terminals.
  • Page 91 RS-485 Communications, Continued Table 4–8 Troubleshooting RS-485 Communications, Cont. Procedure Instructions In the following procedure, the common name for a component or it’s jumper number if available (abbreviated J) or part is followed by a number in parentheses. This refers to the call out item number referenced on each drawing.

  • Page 92: Rs-422 Communications

    RS-422 Communications The following RS-422 Communications troubleshooting procedures will assist the user in what may be the possible cause for indicated error message. Refer to Table 4–9. Table 4–9 Troubleshooting RS-422 Communications Error Message Possible Cause µFLO Will Not • If using manufactured cable, verify Radio cable is connected fully Respond To •...
  • Page 93 RS-422 Communications, Continued Table 4–9 RS-422 Communications, continued Procedure Instructions Measuring Transmit Using an oscilloscope or digital voltmeter, connect it to the 2100888-003 field Data Voltage termination board TB1 (Figure 4–5, Item 20) connector between the following terminals. Voltage should vary between +5 Vdc and 0 Vdc when communication data is being transmitted from µFLO to CCU.

  • Page 94: Wake-Up

    Wake-Up The SLEEP mode is a safety feature which maintains the flow records but discontinues flow measurement calculations. When the µFLO is in the SLEEP mode the word SLEEP is displayed on the µFLO along with the date and time the unit went to sleep. If µFLO battery voltage falls below 11VDC, µFLO enters SLEEP mode after 2 minutes.

  • Page 95: Chapter 5 Totalflow ® Definitions And Acronyms

    “micro”. Pronounced as a long u. µFLO Totalflow’s Micro Flow Computer is a low power, microprocessor based units designed to meet a wide range of measurement, monitor and alarming applications for remote gas systems, while being a cost effective alternative.
  • Page 96 Term Definition AGA-5 American Gas Association Report No. 5, methods (Volume, Mass or Energy) for calculating BTUs without knowing the composition of the gas. AGA-7 American Gas Association Report No. 7, method of calculating gas volume using a Pulse Meter. AGA-8 American Gas Association Report No.
  • Page 97 The average atmospheric pressure at sea level (for scientific purposes) has been defined at 14.696 pounds per square inch absolute. Audit To examine or verify data for accuracy. Totalflow’s DB1 and DB2 records may be edited to generate a more accurate representation of data information. Audit Trail Using the Long Term Archive files to justify changes made to records that more accurately reflects the correct data.
  • Page 98 Term Definition Barometer An instrument which measures atmospheric pressure. Barrel The unit of volume measurement used for petroleum and it’s products; 1 barrel = 42 US gallons. Base Pressure The pressure used as a standard in determining gas volume. Volumes are measured at operating pressures and then corrected to base pressure volume.
  • Page 99 Term Definition Bounce Bouncing is the tendency of any two metal contacts in an electronic device to generate multiple signals as the contacts close or open. When you press a key on your computer keyboard, you expect a single contact to be recorded by your computer.
  • Page 100 Term Definition Butane (C4H10) A saturated hydrocarbon (alkane) with four carbon atoms in it’s molecule ). A gas at atmospheric pressure and normal temperature, but easily liquefied by pressure. Generally stored and delivered in liquefied form and used as a fuel in gaseous form, obtained by processing natural gas as produced and also from a process in petroleum refining.
  • Page 101 Chromatography- A method of separating gas compounds by allowing it to seep through an adsorbent so that each compound is adsorbed in a separate layer. Communication Interface Module. Totalflow’s version is called TFIO Communication Interface Module. Circuit 1. The complete path between two terminals over which one-way or two- way communications may be provided.
  • Page 102 Comm. Port (abbreviation) refers to the host computer's physical communication's port being used to communicate with the equipment. Used by Totalflow when discussing local or remote communication with various equipment including the XFC, FCU, XRC and RTU etc. Complimentary Metal-...
  • Page 103 Term Definition Contact Current carrying part of a switch, relay or connector. Conversion Time The time required, in an analog input or output system, from the moment a channel is interrogated (such as with a read instruction) to the moment that accurate data is available.
  • Page 104 Data Collect Physically, locally or remotely, retrieving data stored with a Totalflow unit. This data is typically stored in records located in a data base format. See Direct Current...
  • Page 105 A Microsoft data exchange format generally used to transfer data from one or Dynamic Data program to another. It is a very simple format to use and Totalflow Exchange customers often use TDS to acquire data from Totalflow devices and then transfer the data to an Excel spreadsheet using DDE.
  • Page 106 Term Definition Digital-to-Analog An electronic device, often an integrated circuit, that converts a digital Converter number into a corresponding analog voltage or current. DIN Rail Rail on which modules are mounted. Allows modules to snap on and slide right and left. Diode A semiconductor that allows current to flow in one direction only.
  • Page 107 It “pushes” new data to the iVision database, saving time and network resources by not transmitting redundant data. The DVI includes the Totalflow WinCPC code and thus supports all Totalflow software and functions – including WinCCU, TDS, PCCU, Report by exception, cryout, etc.
  • Page 108 Term Definition Electromagnetic Any electromagnetic disturbance that interrupts, obstructs, or otherwise Interference degrades or limits the effective performance of electronics/electrical equipment. It can be induced intentionally, as in some forms of electronic warfare, or unintentionally, as a result of spurious emissions and responses, intermodulation products, and the like.
  • Page 109 Term Definition F.O.B. Abbreviation of free on board with the cost of delivery to a port and loading onto a ship included. Orifice Thermal Expansion factor. Faux Full Well Stream Factor. Basic Orifice factor. Federal Communications Commission. Feed Points Connections between gas feeder lines and distribution networks. Feedback Occurs when some or all of the output of the device (such as an amplifier) is taken back to the input.
  • Page 110 Term Definition Reynolds Number factor. Frequency The number of cycles per second for any periodic waveform - measured in cycles per second - now called Hertz. Frequency Modulation Modulation where the frequency of the sinewave carrier alters with the amplitude of the modulating signal. Fiberglass Reinforced Polyurethane.
  • Page 111 Term Definition Gas, C2 Ethane. Gas, C3 Propane. Gas, C6+ Hexanes Plus (C6, C7, C8, C9, C10, C11, etc.). Gas, CO2 Carbon Dioxide. Gas, Dry Gas whose water content has been reduced by a dehydration process. Gas containing little or no hydrocarbons commercially recoverable as liquid product.
  • Page 112 Term Definition Gas, Unconventional Gas that can not be economically produced using current technology. Gas, Wet Wet natural gas is unprocessed natural gas or partially processed natural gas produced from strata containing condensable hydrocarbons. The term is subject to varying legal definitions as specified by certain state statutes. Gate Station Generally a location at which gas changes ownership, from one party to another, neither of which is the ultimate consumer.
  • Page 113 Term Definition GPS 2261 See Gas Processors Standard 2261. See Ground. Ground 1) An electronically neutral circuit having the same potential as the surrounding earth. Normally, a non-current carrying circuit intended for the safety purposes. A reference point for an electrical system. 2) A large conducting body (as the earth) used as a common return for an electric circuit and as an arbitrary zero of potential.
  • Page 114 A method that allows the CPU to distinguish between the different boards in a system. All boards must have different addresses. See Integrated Circuit Programming Language used by Totalflow for user applications. See Integrated Multivariable Transducer. Inch of Mercury A pressure unit representing the pressure required to support a column of mercury one inch high at a specified temperature;...
  • Page 115 Term Definition Integrated Circuit A circuit component consisting of a piece of semiconductor material containing up to thousands of transistor and diodes. A chip. Integrating ADC An ADC whose output code represents the average value of the input voltage over a given time interval. Interface (computer) Usually refers to the hardware that provides communication between various items of equipment.
  • Page 116 Long Term For Totalflow’s purpose, the application of this term refers to storing data over a period of time that is greater than a minimal time. Such as data collected weekly versus data collected weekly but stored indefinitely.
  • Page 117 Term Definition Man-Machine Interface Software program that converts machine instructions and commands into a user interface. MasterLink MasterLink is the name of the software program used to communicate with the LevelMaster for purposes of doing setup, calibration, troubleshooting, generating site files, monitoring levels and collecting data. Mbytes/s A unit for data transfer that means 1 million or 10 bytes/s.
  • Page 118 A property of an operating system in which several processes can be run simultaneously. Multivariable Transducer Transducer supplying more than 1 variable. Totalflow uses this term to encompass units that read Static Pressure, Differential Pressure and Temperature. Historically these units were coined AMU for Analog Measurement Unit.
  • Page 119 OPC Servers. The idea is to provide a universal way to collect data into a SCADA system regardless of the equipment vendor. This standard was developed and is maintained by the OPC Foundation. The Totalflow Driver, TDS32, supports OPC. 5-25...
  • Page 120 (2) In programming, the term parameter is synonymous with argument, a value that is passed to a routine. PCCU Portable Collection and Calibration Unit. PCCU32 Windows version of PCCU software to process, archive and collect data from the Totalflow equipment. 5-26...
  • Page 121 Different techniques are used to decide how long to shut in and flow the well. Polling A snapshot view of the readings taken by the Totalflow equipment. Port A communications connection on a computer or a remote controller. A place of access to a device or network, used for input/output of digital and analog signals.
  • Page 122 Term Definition Programmable Read Computer memory in which data can be routinely read and written to. Only Memory ROM is used for storing data or programs (e.g. operating systems) and characteristic files on a semi-permanent basis. Programmed I/O The standard method a CPU uses to access an I/O device-- each byte of data is read or written by the CPU.
  • Page 123 Term Definition RBUS Communication abbreviation for Results Bus. Communication abbreviation for Received. Read Only Memory Computer memory in which data can be routinely read but written to only once using special means when the ROM is manufactured. ROM is used for storing data or programs (e.g.
  • Page 124 Term Definition Remote Controller, X Totalflow’s X series Remote Controller is a low power, microprocessor Series. based unit designed to meet a wide range of automation, monitor, control, alarming and measurement applications. Remote Terminal Unit An industrial data collection device similar to a PLC, designed for location at a remote site, that communicates data to a host system by using telemetry (such as radio, dial-up telephone, or leased lines).
  • Page 125 Term Definition SDRIVE Serial E Prom. Self-Calibrating A property of a DAQ board that has an extremely stable onboard reference and calibrates its own A/D and D/A circuits without manual adjustments by the user. Semiconductor Material that is nether a conductor nor insulator. Its properties can be altered by a control voltage.
  • Page 126 Term Definition See Static Pressure Specific Gravity The ratio of the mass of a solid or liquid to the mass of an equal volume of distilled water at 4°C (39°F) or of a gas to an equal volume of air or hydrogen under prescribed conditions of temperature and pressure.
  • Page 127 A “DOS Box” will be displayed on your screen. Type ipconfig to get the ip address. When you enter a URL (e.g., www.TotalFlow.com) in a browser, a DNS server (on the network) resolves this into an IP address and directs your request to the machine with that address.
  • Page 128 Term Definition TF.NET Totalflow network used to access iVision/web data. Thermocouple A temperature sensor created by joining two dissimilar metals. The junction produces a small voltage as a function of the temperature. Thermowell A closed-end tube designed to protect temperature sensors from harsh environments, high pressure, and flows.
  • Page 129 (DP), Static Pressure (SP), and Flow Rate for the purpose of positioning a flow valve to maintain a desired value of DP, SP, or Flow Rate. VAS32 Totalflow’s Voice Alarm System. A software program that receives and transmits alarm notifications via cell, telephone or pager systems. VBATT Battery Voltage.
  • Page 130 WINCCU Windows Central Collection Unit. Windows version of software to process, archive and manipulate data collected from the Totalflow products. Witness In the field, where hydrocarbons are changing hands and actual cash register transactions being performed, it is not uncommon for one party or the other to request / require a representative or company employee be present during calibrations and or routine maintenance.

  • Page 131: Chapter 6 Drawing & Diagrams

    This Chapter of the manual has been provided as a location for the user to place drawings that accompanies their new Totalflow units. Totalflow recommends that a complete set of all drawings that accompany a Flow Computer be placed in this Chapter. This would ensure that the user have only drawings applicable to their units and drawings that are at the latest revision level.

Table of Contents
