Summary of Contents for CPcam CPN103

  • Page 1 Video Web Server Video Web Server 2CH MJPEG VIDEO WEB SERVER 2CH MJPEG VIDEO WEB SERVER User ’ s Manual User ’ s Manual Please read instructions thoroughly before operation and retain Please read instructions thoroughly before operation and retain it for future reference.
  • Page 2 Thank-You Note Before You Get Start First of all, we would like to express our gratitude to you for purchasing this product. This product is designed to meet your personal needs with our great industry-designing ability and our everlasting perseverance to the quality of all our products. This manual will introduce to you how to install this apparatus.
  • Page 3 IMPORTANT SAFEGUARD IMPORTANT SAFEGUARD CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NO OPEN DO NO OPEN CAUTION: CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS PARTS AND FEATURES PARTS AND FEATURES 1.1 FEATURES ------------------------------------------------------------------------------------------------------------ 1.2 PACKAGE CONTENTS -------------------------------------------------------------------------------------------- 1.3 SPECIFICATION ----------------------------------------------------------------------------------------------------- 1.4 PANEL ------------------------------------------------------------------------------------------------------------------ INSTALLATION AND CONNECTION INSTALLATION AND CONNECTION 2.1 SYSTEM CONNECTION ------------------------------------------------------------------------------------------- 2.2 CONNECT DVR TO VIDEO WEB SERVER ------------------------------------------------------------------ 2.3 SOFTWARE INSTALLATION ------------------------------------------------------------------------------------ 2.4 IP SETTING AND LAN CONNECTION ------------------------------------------------------------------------ 2.5 CONNECT VIA INTERNET ---------------------------------------------------------------------------------------...

  • Page 5: Parts And Features

    PARTS AND FEATURES PARTS AND FEATURES 1.1 FEATURES 1.1 FEATURES Network: Network: JPEG real time compression format Support TCP/IP, PPPoE, DDNS and DHCP for network connection Support DDNS function as a router Alarm: Alarm: Support alarm trigger recording Full alarm-triggered event list for easy search and quick playback Whenever alarm system triggered, video streaming or pictures will be uploaded over FTP, email as an instant notification.

  • Page 6: Specification

    1.3 SPECIFICATION 1.3 SPECIFICATION Specification CPN103 Specification CPN103 Video Input 2 channel for analog & digital products, 1.0 Vp-p 75 composite, BNC Alarm Input 4 inputs / 2 outputs Watch dog RS-485 Port Network Interface Ethernet (10/100 Base-T) Image Compression...

  • Page 7: Panel

    1.4 PANEL 1.4 PANEL Solder Side of DSUB 9 PIN LAN: LAN: Connect Video Web Server to the Internet or LAN or connect directly to PC (Use crossover cable or straight-through cable). VIDEO INPUT (2 channels): VIDEO INPUT Connect to video source, such as camera or DVR video output. ALARM I/O (optional for advanced applications): ALARM I/O Connect control devices, such as PTZ, DVR and external alarm signal input.

  • Page 8: Installation And Connection

    INSTALLATION AND CONNECTION INSTALLATION AND CONNECTION 2.1 SYSTEM CONNECTION 2.1 SYSTEM CONNECTION Power: Connect to DC 12V regulated adapter. Power: Video Input: Connect to video outputs of CAMERA or DVR…etc. Video Input: Take DVR as an example, after connection, set the baud rate and ID of the DVR. Make sure that the baud rate and ID as same as the settings of the VIDEO WEB SERVER.

  • Page 9: Connect Dvr To Video Web Server

    2.2 CONNECT DVR TO VIDEO WEB SERVER 2.2 CONNECT DVR TO VIDEO WEB SERVER DVR Baud Rate and ID Setting: DVR Baud Rate and ID Setting: Set the baud rate and ID of the DVR. Make sure that the baud rate and ID as same as the settings of the VIDEO WEB SERVER (P.21 Peripheral).

  • Page 10: Software Installation

    2.3 SOFTWARE INSTALLATION 2.3 SOFTWARE INSTALLATION Put the attached CD into a CD-ROM and it will start to install application program into PC. Click “Install Video Server“ to run the setup program. Click “Finish” button to complete the setup. And you will see the icon “ “...
  • Page 11 Step 1- 2: Before changing any PC properties setting, please write down the original network setting in order to recover the original PC network setting after “VIDEO WEB SERVER IP SETTING AND LAN CONNECTION” . Step 1- 3: Click on “Use the following IP address” , set IP address and subnet mask. The IP address should be like 192.168.1.XXX (under the same subnet).
  • Page 12 When you see the following screen, means successfully logged in the live viewer of the Video Web Server. Click “System Config” to set up. In the Peripheral setting, set “Baud Rate”, “ID” and “Model” which you want to remote control later. Press “APPLY”...
  • Page 13 Click on the Network, set “Server IP”, “Gateway”, “Net Mask” which are provided from your local ISP ( internet service provider ), “Web Port” and “IP type”. Press “APPLY” to enable the change after the setting. Static IP: Static IP: Note: Dynamic IP: Dynamic IP:...

  • Page 14: Connect Via Internet

    2.5 CONNECT VIA INTERNET 2.5 CONNECT VIA INTERNET Recover PC network setting to the original setting and link PC to the internet. ( Since the PC IP setting has been changed, now it must recover to the original setting for connecting to internet ). Click twice and enter “User Name”, “Password”, “Static IP”...

  • Page 15: Operation Guide

    OPERATION GUIDE OPERATION GUIDE 3.1 SOFTWARE OPERATION 3.1 SOFTWARE OPERATION After physical connection and network setting of the video web server. Please following the illustrations in this section for software operation. Click twice to enter Login page. Key in “User Name”, “ Password”, and “Server IP” (Static IP) or “Host name”(Dynamic IP).
  • Page 16 Introduction of Basic Operation: Video Web Server Control Panel Video Web Server Control Panel Image transfer rate per second c d e Data transfer rate Connect / Disconnect Resolution: NTSC: 352 × 240 ; 704 × 480 PAL: 352 × 288 ;...
  • Page 17 Digital Device Control Panel ~ PTZ Digital Device Control Panel ~ PTZ (Take PTZ (Normal) for an example) Preset Points 1 ~ 16 AUTO Zoom Tele Zoom Wide l. m. o. p. q. r. Focus Near Focus Far Continuously Zoom In Continuously Zoom Out Menu / up / down / left / right Enter...

  • Page 18: Playback Operation

    3.2 PLAYBACK OPERATION 3.2 PLAYBACK OPERATION Please find a manual recorded file in the PC and double click on to playback. One click to activate One click to activate AP Config. Setting Box : • De-interlace • De-blocking • OSD •...

  • Page 19: Advanced Setting

    3.3 ADVANCED SETTING 3.3 ADVANCED SETTING Press “System Config ” button to enter the system setting page. Network Network The network configuration allows DVR to be available for Ethernet network or dial-up. Static IP: Static IP: Enter the “ Server IP”, “ Gateway”, Server IP Gateway...

  • Page 20: Ddns

    DDNS DDNS DDNS is a service for transforming “Dynamic IP” to a corresponding specific “Hostname”. DDNS Apply: DDNS Apply: Go to a website which provide free DDNS services and apply a “Hostname”. See the example below. Enable the DDNS function: Enable the DDNS function Enter your DDNS user name into “User Name”...

  • Page 21: Mail

    Mail Mail When the recording is triggered by an alarm or a motion, a video copy file can be captured. The DVR will send an e-mail notification to the assigned recipients (up to 5 recipients). ***Note***: ***Note***: To activate the e-mail notification function, please enable the function of e-mail notification in the “Alarm”...

  • Page 22: Server Time Config

    Sever Time Config Sever Time Config Correct time from SNTP server : ● SNTP (Simple Network Time Protocol) SNTP (Simple Network Time Protocol is for time setting. So it also concerns to schedule recording. Or you could correct time by your own by choosing “Correct by user”.

  • Page 23: Alarm List

    Alarm List Alarm List It’s a database, which precisely lists all alarm triggered events, with information such as IP address, alarm triggered time, and Frame per second (FPS). You could directly “Play” or “Delete” all alarm trigger recording events easily. All the alarm triggered files will be listed systematically for easy search.

  • Page 24: Account

    a. Connect / Disconnect b. Resolution: Account Account c. Image Quality d. Image Adjusting e. Snapshot Record Set up the user’s account ( Max 5 g. System config accounts) , password, life time, and authority level. Max 5 users on line at the same time). Max 5 users on line at the same time User’s level: SUPERVISOR...

  • Page 25: Online User Info

    Online User Info Online User Info Get all the online users’ information here (Name, IP Address, Authority Level, Resolution and Image Quality). Press “Info Refresh” button to update the online user information. File Path File Path Snapshot Path: Snapshot Path Assign the route for saving the snapshot picture.

  • Page 26: Dvr Pin Connection

    APPENDIX #1 APPENDIX #1 APPENDIX #1 – DVR PIN CONNECTION APPENDIX #1 – DVR PIN CONNECTION Connect the Sub-D plug of Video Web Server with DVR products. Solder Side of DSUB 9 PIN Solder Side of DSUB 15 PIN Solder Side of DSUB 25 PIN 13 12 11 10 9 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 25 24 23 22 21 20 19 18 17 16 15 14...
  • Page 27 Set the “Baud Rate”, “ID” and “Remote Mode (RS-232 / RS-485)” in the DVR products. NOTE : NOTE : The settings above must be as same as “Peripheral” setting in the Video Web Server. Set the “Peripheral Control” in the system config of Video Web Server.

  • Page 28: Ptz Pin Connection

    APPENDIX #2 APPENDIX #2 APPENDIX #2 – PTZ PIN CONNECTION APPENDIX #2 – PTZ PIN CONNECTION Connect the Sub-D plug of Video Web Server with our own brand PTZ products. Solder Side of DSUB 9 PIN 1 Video Output Connector 2 Power Cable 3 RS485-B (orange color line) 4 RS485-A (brown color line)
  • Page 29 APPENDIX #3 APPENDIX #3 APPENDIX #3 – IE BROWSER APPENDIX #3 – IE BROWSER You could go access Video Web Server through the web page. Just type the IP address of video web server into the URL address box and press Enter. Then you will see the following pages.

  • Page 30: Ddns Apply

    APPENDIX #4 APPENDIX #4 APPENDIX #4 – DDNS APPLY APPENDIX #4 – DDNS APPLY Go to a website which provide free DDNS services. For example, “http://www.dyndns.org”. Create an account in DynDNS. Click on “Account”, then you could see the following page. Click on “Create Account”, then you could see the following page.
  • Page 31 After created account, you will receive an confirmation e-mail within a few minutes. To complete registration, please follow the directions that you will receive. You must complete these steps within 48 hours to complete the registration. If you do not the confirmation e-mail within an hour or so, request a “password reset”...
