433MHz Wirefree Remote Control (S R E)
These instructions should be read in conjunction with
your System Installation and Operating Instructions
and be retained for future reference.

Introduction

The S R E Remote Control is designed for use with
Response Wirefree Intruder
433MHz only.
Arm
Part-Arm/
Delay-Arm*
Disarm
* Part Arm with Control Unit
Systems or Delay-Arm with
Siren only systems
The Remote Control Unit is used to
the system. The Remote will activate the Instant
Part- rm/Delay- rm or Disarm functions dependent upon
which System it will be used with (refer to your System
Installation and Operating Manual).
The Remote Control also incorporates a Personal
Switch (P S). ctivating the P S will immediately initiate a Full
larm condition whether the system is rmed or Disarmed,
(unless the system is in Service, Test or Program mode).
Installation and Operating Instructions
larm systems operating on
ansmit LED
Tr
Slide up
to operate
Personal Attack
rm and Disarm
rm,
ttack
ny number of Remote Controls can be used with your
system, providing they are all coded with the same
system House Code.
The Remote Control is powered by a CR2032 type
Lithium Cell battery which under normal conditions will
have a typical life in excess of 1 year. Under normal
battery conditions the LED on the Remote Control will
only illuminate when a button is pressed.
under low battery conditions the LED will flash every
time the button is pressed. When this occurs the battery
should be replaced as soon as possible.
Setting the Remote
Ensure that the system is in Test/Service Mode
1. Remove the front cover by undoing the small screw on
the rear of the Remote Control.
House Code
Dip Switches
Jumper Link
Battery Clip
Battery
2. Located above the battery cover is a row of 8 DIP
switches. These switches set the House Code for the
However,
ontrol
