INSTALLATION & OPERATING
Applicable for use with all styles and sizes of Infrared Burner Natural Gas Log Sets.
Note: Installer should leave these instructions with the consumer to retain for future reference.
INFRARED
BURNER
Please call our Customer Service Department at 800-229-5647 for replacements.
Please Read
• If you smell gas:
1. Open windows
2. Don't touch electrical switches
3. Extinguish any open flame
4. Immediately call your gas supplier.
• Do not store or use gasoline or flammable vapors and liquids in the vicinity of this or any other appliance.
• Do not place clothing or other flammable material on or near the appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance.
© SURE HEAT MFG. 2008
INSTRUCTIONS FOR
FIREPLACE GAS LOGS
Model Numbers: GO18TIR and GO24TIR
Do not return to retailer if a log is broken or parts are missing.
these instructions carefully before you begin to install this gas log set.

FOR YOUR SAFETY

NOTICE
THANK YOU
INFRARED
BURNER
Complies with ANSI Z21-84

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO18TIR and is the answer not in the manual?

Questions and answers

Related Manuals for EmberGlow GO18TIR

Summary of Contents for EmberGlow GO18TIR

  • Page 1: For Your Safety

    INSTALLATION & OPERATING INSTRUCTIONS FOR FIREPLACE GAS LOGS Model Numbers: GO18TIR and GO24TIR Applicable for use with all styles and sizes of Infrared Burner Natural Gas Log Sets. Note: Installer should leave these instructions with the consumer to retain for future reference.
  • Page 2 © SURE HEAT MFG. 2008 Complies with ANSI Z21-84...

  • Page 3: Log Placement

    LOG PLACEMENT STEP 1 STEP 2 STEP 3 INFRARED BURNER PARTS LIST Figure 1 Grate & Burner Assembly Manual Shutoff Valve Damper Stop Clamp 3/8" Flared Tubing Granules Glowing Embers Pipe Sealant REF. DUAL BURNER RADCO PART NUMBER QTY PART NUMBER 18"...

  • Page 4: Fireplace Preparation

    1. This gas log set is only to be installed and burned in a fully vented fireplace with a fully functional damper and chimney that is free of any obstructions. The fireplace must be constructed of non-combustible materials and approved to burn wood. WARNING: Do not burn wood or other material in any fireplace fitted with a gas log set.
  • Page 5 D. Installation to existing gas line in fireplace. A manual on-off valve should be present within easy reach of the gas log set. If a manual valve is not present, one must be installed prior to the gas log installation. E.

  • Page 6: Maintenance

    GRANULE AND EMBER PLACEMENT A. Spread granules (Part #16) over the installed burner pan. Granules should be sloped to the same angle as the burner pan filling the entire pan. (See Figure 4). NOTE: The top two burners inside the burner pan should be covered, leaving the bottom infrared burner, which is below the grate, exposed.

  • Page 7: Limited Warranty

    LIMITED WARRANTY Warranty shall apply to the original purchaser at the original installation point only. All logs are guaranteed for three years against manufacturer’s defects. The burner assembly system is guaranteed for a period of (3) years from the date of purchase and will be replaced for freight costs only.
  • Page 8 © SURE HEAT MFG. 2008 Complies with ANSI Z21-84...
