Rack
M ount
U ninterruptible
P ower
S upply
(These instructions are intended for use by a technician familiar with electronic products)
Commercial
g rade
2 4
v olt
p ower
s upply
w ith
b uilt-‐in
•
batteries
Seamless
t ransfer
t o
b atteries
d uring
A C
p ower
f ailure
•
Built-‐in
l ow
v oltage
d isconnect
( LVD)
t o
p revent
e quipment
•
damage
Automatically
r echarges
b atteries
o nce
A C
p ower
i s
•
restored
Separate
f ront
p anel
i ndicators
f or
D C
o utput
a nd
A C
f ailure
•
Power
f actor
c orrection
( PFC)
f or
" green"
o peration
•
AC
f ail
a larm
c ontacts
•
3
y ear
w arranty
•
DESCRIPTION
RU2-1524-UPS is a rack mount continuous duty uninterruptible power supply with self contained battery, charger, AC fail
circuit, and low voltage disconnect.
SPECIFICATIONS
Output Voltage........................................................................................................................................................................ 27.5 VDC
Output Voltage Tolerance.......................................................................................................................................................... +/- 1 pct
Output Amperage ........................................................................................................................................................... 15 Amps cont.
Maximum Power, continuous ..................................................................................................................................................500 watts
Output Voltage Adjustment................................................................................................................................................... 23-28 VDC
Maximum ripple and noise............................................................................................................................................100 mV p-p max
Auto Ranging AC Input ....................................................................................................................................................... 85-264 VAC
Input frequency range.............................................................................................................................................................. 47-63 Hz
Maximum AC current ..................................................................................................................7 Amps/120 VAC; 3.5 Amps/240 VAC
Typical Efficiency ........................................................................................................................................................................ >80 pct
Max inrush current, single cycle ............................................................................................................................................... 35 Amps
Short Circuit protection ............................................................................................................................................... Foldback Limiting
Overload Protection (operates) ................................................................................................................................typical 110-120 pct
Line Regulation.............................................................................................................................................................................50 mV
Load Regulation ............................................................................................................................................ 100 mV (20-100 pct load)
Fan Control .................................................................................................................................... Heat sink temp >140 F (60 C) = ON
Over Temperature ........................................................................................................................ >195 F (90 C) auto output shutdown
Rise Time following ON ................................................................................................................................................................50 mS
Hold Time following OFF ..............................................................................................................................................................10 mS
Working Temperature range............................................................................................................................. -4 – 140 F (-20 -+ 60 C)
Storage Temperature ..................................................................................................................................... -40 – 185 F (-40 - +85 C)
Withstand Voltage* ................................................................................................................. 1.5 KV @ 10 ma (I/P-O/P, I/P-FG)/1 min
(Continued) ............................................................................................................................. 500 V @ 10 ma (O/P-FG)/1 min
Dimensions ......................................................................................................................................3.5H x 19W x 13D inches, nominal
Weight ............................................................................................................................................................................ 20 lbs, nominal
RU2-‐1524-‐UPS
Owners
G uide
1
Advertisement
Table of Contents
Related Manuals for DuraComm RU2-1524-UPS
Summary of Contents for DuraComm RU2-1524-UPS
-
Page 1: Specifications
3 y ear w arranty • DESCRIPTION RU2-1524-UPS is a rack mount continuous duty uninterruptible power supply with self contained battery, charger, AC fail circuit, and low voltage disconnect. SPECIFICATIONS Output Voltage..................................27.5 VDC Output Voltage Tolerance................................+/- 1 pct Output Amperage ................................ - Page 2 NOTE: The individual user should take care to determine, prior to use or installation, whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great variation, DuraComm makes no representation or warranty as to the merchantability, suitability or fitness of these units for any specific application.
- Page 3 RU2-1524-UPS Wiring Layout This system setup will provide continuous power to the load and maintain battery bank with smart charger while AC power is on. There is a seamless transfer of the load to the battery when the AC power goes off. The LVD will disconnect the battery if the voltage drops below 21.5 VDC.
-
Page 4: Limited Warranty
DuraComm, at its option, will repair or replace the faulty product or parts thereof, which, after examination by DuraComm, prove to be defective or not operational according to specifications in effect at the time of sale to the initial end user.
