Handy Home Products 16628 Instruction Booklet

Important! Please follow these instructions. This kit may be different from the one specified in instruction booklet.
COMBINATION 8X8 and 10X8 FLOOR KIT
This floor kit will build either the 10' wide or 8' wide x 7' 8-5/8" deep floor size
FOR MARCO SERIES, SOLAR SHED AND MWP IMPERIAL ONLY
This floor kit is for 10' x 7' 8-5/8" and 8' x 7' 8-5/8" buildings. Please refer to the appropriate pages
of this instruction manual to build the floor size needed. If constructing an 8X8 storage building,
you will have additional material which can be used to construct a shelf (some cutting required)
or other projects.
- B E F O R E
First...
Read these instructions thoroughly before you begin
assembly. Assembly is easiest if you follow the steps in
the order shown.
Lumber is graded from only one side. Check the part for
the most attractive face and make sure to face it to the
outside.
Check all parts
Compare parts you have to the list on page 2. If a part is
missing, circle the part in question in the parts list and
call us toll-free at 1-800-437-0784.
Assistance required
We recommend that you assemble this floor on level
ground in the location it will be used. Assistance is
necessary to handle, fit, and secure some components.
Two people maybe needed for some steps.
Squareness is very Important!
Keeping all 90° corners and 90° perpendiculars square
throughout the assembly of this floor kit will make each
succeeding step easier and is necessary to assure that
all components fit together properly.
Check local zoning
Before starting construction, check with your local
building code official for any required permits, variances,
etc.
Check floor kit size
Before starting construction on your floor, make sure
that you check in the instruction manual to ensure that
you are building the correct size floor kit for your
building.
Always wear OSHA-APPROVED safety
glasses throughout assembly process
#16628
Y O U B E G I N -
■ Tools required
❑ Hammer
❑ Level
❑ Pencil
❑ Tape Measure
■ Optional tools
❑ Chalk Line
❑ Square
❑ Nail Pouch
❑ Saw
1
8x8
See pages 2-3-4
10x8
See pages 5-6
07/31/2006
