Summary of Contents for Smart Lan PW54
-
Page 1: User Manual
WIRELESS ADAPTER 54Mbps USER MANUAL Easy to install and configure PW54 (802.11b/g) - Page 2 PW54 11G Wireless PCI Adapter Ralink PCI Wireless LAN Adapter User’s Manual 1 Install the driver a Insert the installation CD into your CD-ROM driver, Double click the icon to start setup b click Yes to go on d click Finish to end the setup...
- Page 3 PW54 11G Wireless PCI Adapter 2 Turn off your computer, Plug in your PCI wireless LAN adapter, and then turn on your computer. it will be recognized and auto installed. Just confirmed it like below: 3 Make infrastructure connection Double click the icon in red circle You will see: www.smartlan.us...
- Page 4 PW54 11G Wireless PCI Adapter You can click the button Rescan to find which AP is in range, they will show on the window, choice one you want to connect, and click the button connect, and click ok to finish the connection operation.
- Page 5 PW54 11G Wireless PCI Adapter How to find out which a WIFI environment you are inside 5 Make Ad-Hoc mode connection 5.1 Make an Ad-Hoc SSID www.smartlan.us...
- Page 6 PW54 11G Wireless PCI Adapter www.smartlan.us...
- Page 7 PW54 11G Wireless PCI Adapter 5.2 Setup static IP address for the Ad-Hoc link A At its property page, double click item Internet Protocol (TCP/IP) www.smartlan.us...
- Page 8 PW54 11G Wireless PCI Adapter You will get C Fill the IP address blank, example as below: www.smartlan.us...
- Page 9 PW54 11G Wireless PCI Adapter D Click ok to finish the setup 5.3 Ad-Hoc setup for one point accomplished 5.4 Setup another Ad-Hoc point as step A,B,C,D. 5.5 Ad-Hoc mode link accomplished. And you can visit each other. Note: To make an Ad-Hoc mode link, Do remember to choice the same channel, its static IP address should be in the same netsub, and the SSID should be the same too.
- Page 10 www.smartlan.us...
