Summary of Contents for Fisher Solid Fuel Heater
- Page 1 BLENHEIM FS CA SOLID FUEL HEATER INSTALLATION & OPERATING INSTRUCTIONS Feb 2010...
-
Page 2: Installation
Keep this booklet as a reference guide. Installation of Fisher Wood Heater Fisher recommends you use a qualified solid fuel heater installer or a registered plumber to install your fire. Your dealer or heating specialist will be able to help with recommendations as well as advise on permits/consents required for the installation in your area. - Page 3 8 Install the flue system (see flue installation instructions supplied with flue system). Remember: • The flue system should rise vertically from the appliance with as few offsets as possible. Offsets should be avoided where possible as each change in direction creates a resistance to airflow and makes flue cleaning difficult.
- Page 4 CONSIDERED TO BE IN BREACH OF THE APPROVAL GRANTED FOR COMPLIANCE WITH AN/NZS 4013. 3. PLEASE ENSURE THAT ONLY COMPONENTS APPROVED BY FISHER ARE USED FOR THE INSTALLATION as substitutes may adversely affect performance and might nullify compliance with the requirements of AS/NZS 2918.
- Page 5 Correct Operation of Your Fisher Solid Fuel Heater Simply by burning your Fisher heater correctly, you can improve efficiency, reduce fuel consumption and minimise air pollution. STARTING A NEW FIRE Please note: If lighting the heater for the first time dust heater, glass, trim and flue before firing to avoid particles sticking or discolouring.
- Page 6 Try to avoid smothering the fire with the new pieces. Placing the pieces on the burning kindling can help prevent smothering. As your Fisher heater is a radiant heater it requires approximately 45-60 minutes to preheat the steel firebox before it can effectively radiate heat into the room.
- Page 7 (see above) Small and Large Fuel Load Geometry Fire in cycles: Don't expect perfectly steady heat output from your Fisher heater. Solid fuel heaters burn in cycles. A cycle is the time between the ignition of a load from charcoal and the consumption of the load back to a coal bed.
- Page 8 The long-burning fire: To achieve a long burning fire, rake the embers evenly, as with the small hot fire, and use larger and more pieces of wood. Place the pieces in a similar pattern to the small hot fire, using more pieces and larger pieces (especially the top layer).
- Page 9 To prevent this extreme negative pressure, one option is to open a window slightly to allow combustion air into the room. Improper heater firing technique: When a solid fuel heater is starved for air it smoulders, producing a relatively cool, smoky fire. The temperatures throughout the system are low.
- Page 10 Maximum log length varies according to model. BURNING COAL Due to their construction, the burning of coal in the Fisher Blenheim Clean Air heater is prohibited. Please also refer to ‘Exclusions’ in the Warranty Page 14.
- Page 11 General maintenance checks should include the following:- ASH REMOVAL - Due to the high efficiency of your Fisher heater, ash removal should only be necessary every few weeks. Ashes can be removed easily through the fire door when the fire is at its lowest, such as first thing in the morning, or when it is completely out.
-
Page 12: Cracked Glass
Warnings Below is a list of warnings to ensure efficient and safe operation of your Fisher heater: • WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE. • WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHEN IT IS OPERATING. - Page 13 There is no doubt in our minds that you will extend the life of your heater. We select only certain companies to act as our Fisher fire dealers as we believe they must have high standards and be able to provide a total service both pre and post sale to you the customer.
- Page 14 Any repairs undertaken without the written authority of the Manufacturer, will invalidate this warranty. Fisher Blenheim CA model is not approved to be fitted with a Water Booster. The warranty is only valid to the initial purchaser of the product.
-
Page 15: Warranty Card
PLEASE COMPLETE AND RETURN WITHIN 30 DAYS OF INSTALLATION TO RETAIL LINKS LTD PO BOX 9056 ANNESBROOK NELSON NAME: ________________________________________________________ ADDRESS: ________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ EMAIL: ____________________________ PHONE: _____________________ FISHER MODEL: _____________________________________________ SERIAL NUMBER: _____________________________________________ DATE PURCHASED: _____________________________________________ PURCHASED FROM: _____________________________________________ DATE INSTALLED: _____________________________________________ INSTALLED BY: _____________________________________________ Retail Links Ltd reserves the right to change specifications or design of its product without prior notice.
