Impath Networks i-Volution iN7000 Pro User Manual

Impath networks i-volution in7000 pro user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
i-Volution
iN7000 Pro
User
Guide
Release 1.0
971-007556-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i-Volution iN7000 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Impath Networks i-Volution iN7000 Pro

Summary of Contents for Impath Networks i-Volution iN7000 Pro

  • Page 1 Pro User Guide Release 1.0 971-007556-001...
  • Page 2 IMPATH NETWORKS Copyright 2009 Impath Networks Canada Corporation. Impath is a registered trademark of Impath Networks Canada Corporation. TeleVue, ClientVue and i-Volution are trademarks of Impath Networks Canada Corporation. Microsoft And Ms Are Registered Trademarks And Windows Is A Trademark Of Microsoft Corp.

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS ..................... I ABOUT THIS GUIDE....................1 About Impath Networks............................2 Our Products...............................3 Website................................4 Support & Contact Information..........................5 CHAPTER 1: INTRODUCTION .................. 1 iN7000 Overview..............................1 iN7000 Desktop..............................2 Features................................4 CHAPTER 2: IN7000 CLIENT SOFTWARE : GETTING STARTED ......5 iN7000 Client Software............................5...
  • Page 4 Application Module Settings..........................29 General Setting (Program Settings)........................30 Scheduler................................32 Weekly Schedule..............................33 One Time Schedule............................34 CHAPTER 4: PLAYBACK ..................35 Playback Window (Local and over IP)......................35 Timeline Playback (Local and over IP)......................40 CHAPTER 5: MODULES ..................42 Capture Source..............................42 DirectShow-Based Video Device........................43 DirectShow-Based Audio Device........................44 Network Camera...............................45 Windows Media URL............................46...
  • Page 5 Connecting an Impath Capture Source......................102 Setting Up Recording............................102 Setting Up the Web Server and Video Server....................102 Settings Up Motion Detection...........................102...

  • Page 7: About This Guide

    About This Guide This guide is intended for technical users such as engineers, integrators, developers, IT managers and technicians. It assumes that users have some PC competence and are familiar with Microsoft Windows operating systems and web browsers such as Windows Internet Explorer and Mozilla Firefox, and knowledge of the following: Installation of electronic equipment •...

  • Page 8: About Impath Networks

    With over 20 years of experience helping the world's leading system integrators deploy complex video networks, and an early pioneer in the development and introduction of Video over IP solutions, Impath Networks is the Proven Player when it comes to meeting your video networking requirements.

  • Page 9: Our Products

    Our Products Impath offers the i-Volution family of digital Video Over IP products for surveillance and enterprise network applications that can extend across a campus or around the world. The breadth of Impath's i-Volution product variant helps the company meet the unique needs of each of its customers.

  • Page 10: Website

    Website For information on all Impath products, please visit http://www.impathnetworks.com. 971-007556-001 iN7000 User Guide...

  • Page 11: Support & Contact Information

    Impath Networks Impath Networks Canada Corporation 42 Payzant T: 902-468-1010 Avenue, Suite 100, Halifax, NS Canada B3B 1Z6 F: 902-468-1044 Impath Networks Ltd. 9 Camelot Drive, Suite 100, T: 613-226-4000 Ottawa, ON Canada K2G 5W6 F: 613-226-4602 900-007556-001 iN7000 User Guide...

  • Page 13: Chapter 1: Introduction

    Introduction iN7000 Overview The iN7000 Pro series introduces a new dynamic digital video recording system from Impath Networks combining DVR and NVR functionality in a scalable, high capacity and feature rich platform. The iN7000 desktop is extremely versatile and customizable. It is designed with floatable windows permitting the operator to easily resize and/or move the various windows across multiple monitors for achieving the most productive layout for your requirements.

  • Page 14: In7000 Desktop

    iN7000 Desktop Figure 1-1: iN7000 Desktop 971-007556-001 iN7000 User Guide...
  • Page 15 900-007556-001 iN7000 User Guide...

  • Page 16: Features

    Features The key features of the i5810-E include: • Full 4CIF/D1 - 704x480/720x480 resolution per channel • Internal Storage up to 9 TB • RAID 5 HDD Configurations • Search by Timeline and Keyword • DVD-RW, Blu-Ray and USB archiving •...

  • Page 17: Chapter 2: In7000 Client Software : Getting Started

    Chapter 2: iN7000 Client Software : Getting Started iN7000 Client Software In most cases iN7000 will be delivered as a complete system with Impath certified / optimized hardware with the Client software installed. In rare cases the software may be installed at site. iN7000 requires Microsoft.Net Framework 3.5 pre-installed.

  • Page 18: System Requirements

    System Requirements • PC running Windows 2000, Windows XP or Windows Vista • Network access • Internet Web browser Microsoft Internet Explorer (version 6.0 or later), or Mozilla Firefox • Java Software: download the latest version from h ttp://www.java.com/en/download/index.jsp License Activation The software can be activated at any time during the trial period.

  • Page 19: Logon

    Logon When you start the program, a log on dialog is displayed. Figure 2-3 : Logon Window You should logon with an account you defined in iN7000 The account is NOT your license id or password). If this is your first time to run the program or you did not modify your account setting, you can log on by using administrator/administrator as username/password.

  • Page 20: Chapter 3: In7000 Desktop

    Chapter 3: iN7000 Desktop The iN7000 software provides a complete suite of windows for setting up and using the application in video security environment. The windows allow the User to view live video, view recorded video, search and replay video and to configure the system. The Main Desktop is the departure point whether setting up or using iN7000 to view video.

  • Page 21: Playback Window

    Playback Window Figure 3-5 : Playback Window Timeline Playback Window Figure 3-6 : Timeline Playback 900-007556-001 iN7000 User Guide...

  • Page 22: Module View

    Module View The Module View can contain several modules including the Log Viewer, eMap, and Spot Screen. The Operator can detach each module to an independent window. Figure 3-7 Module View – eMap Module Displayed 971-007556-001 iN7000 User Guide...

  • Page 23: Main Desktop: Description

    Main Desktop: Description 2 3 16 900-007556-001 iN7000 User Guide...
  • Page 24 Live Video and Main Controls – real-time video preview and main controls. Playback.- Click to open the playback window. Float-out – float out a tab-view. The floated-out control unlocks the window so it can be moved to another monitor. This feature is useful for users using multiple monitors. Channel control bar –...
  • Page 25 Storage Capacity Healthy, Low, Empty Windows Media Broadcast (Active, Inactive) Video Server (Active, Inactive) Web Server (Active, Inactive) Net Service (Active, Inactive) Figure 3-10: Program State Indicators Run/Stop Channels – Click to raise a pop-up menu to run or stop selected or all channels. Most modules will not execute unless the channel(s) is(are) “running”.
  • Page 26 Figure 3-11 : Channel Group Controls Preview tab auto-switching - Switch the preview tab automatically. You can right-click on the but- ton to show up the setting dialog: 971-007556-001 iN7000 User Guide...

  • Page 27: Module Binding

    Module Binding Most functions in iN7000 require module binding. A module is a logical block that provides a specific func- tion. For example, an Advance Video Analysis module provides functions such as object counting, loiter- ing object detection. The Bind Module box must be checked to activate a module. Each channel can have several modules associated with it.

  • Page 28: Program Settings

    Program Settings Figure 3-13 : Program Settings Window Click the tools icon in the main desktop to open the Program Settings dialog. The dialog provides access to configure Channel Setting, Account Management, Application Module Setting, General Setting and Schedule Setting. Click on an icon to go to the corresponding dialog. 971-007556-001 iN7000 User Guide...

  • Page 29: Program Settings - Tools

    Program Settings - Tools The Tools menu contains sub-menus Export Setting, Import Setting, Reset Application Persistence and Reset Application Settings. Figure 3-14 : Program Settings - Tools Import/Export settings Use this menu to import/export iN7000’s Channel Setting, Application Module Setting and General Set- ting.

  • Page 30: Channel Settings

    Channel Settings Channel settings are the most important settings in iN7000 for setting up the channel pipeline. Figure 3-15 : Channel Settings The Channel Settings section provides the pages for controlling the channel specific modules their para- meters including General, Capture Source, Analytics, Filters, Event Handlers, Devices and Com- pression.

  • Page 31: General

    General Figure 3-16 : Channel Settings – General Page Enable Channel / Friendly Name Check this box to enable the channel and for viewing/recording. You may enter a user friendly name that will be used later in the application. Media Storage Type Select to save video data in ASF or database file.
  • Page 32 that of ASF, so the file size is bigger. The database file size is also up to 500MB; so no matter how large value you set in “Media-file Maximum Size”, once the database size reach 500MB, video data will be split into a new database file.

  • Page 33: Capture Source

    Capture Source Configure the channel source in this page. The iN7000 supports several video and audio sources. Refer to the Modules chapter for details about the Capture Source Figure 3-17 Capture Source Configuration Page Video Under “Constraint Module”, you may select DirectShow-Based source (USB webcam, PCI/PCI-E capture card) and hardware compression cards.

  • Page 34: Analytics

    Analytics Here you can bind a channel to motion detection module and advance video content analysis module (de- pending on the version of iN7000 you have). These modules enable features such as motion detection, object counting, illegal parking detection, loitering object detection. Refer to the Modules chapter for details about the Analytics features.

  • Page 35: Filters

    Filters The filters provide features such as OSD timestamp, de-interlacing, event tag overlay, and POS transac- tion overlay. You can bind one or all filter to individual channels. Refer to the Modules chapter for details. Figure 3-19 Filters Settings Page 900-007556-001 iN7000 User Guide...

  • Page 36: Event Handlers

    Event Handlers The events occurring for each channel can be bound to event handlers. The handlers provide the ability to customize the video analysis result presentation and several advanced events including email notifica- tion on events, forward event over IP, alarm popup to mention a few. Refer to the Modules chapter for details.

  • Page 37: Devices

    Devices Use this page to bind external devices to the channel. External devices include PTZ control, PTZ Key- board, and RS232 alarm box for IO support. Refer to the Modules chapter for details. Figure 3-21 Devices Settings Page 900-007556-001 iN7000 User Guide...

  • Page 38: Compression

    Compression The iN7000 includes a compression module for local storage, broadcast and event recording. You can use the existing compressed stream or bind the channel to a compression module in this page Refer to the Modules chapter for details. Figure 3-22 Compressions Settings Page 971-007556-001 iN7000 User Guide...

  • Page 39: Account Management

    Account Management Figure 3-23 : Account Management Window Here you can add/remove account or change account permissions. There are 2 types of account: Administrator and Standard User. The Administrator can launch account management while Standard User cannot. There is a default Administrator account “administrator” with password “administrator”.

  • Page 40: Remote Connection To Video Server

    Remote Connection to Video Server Figure 3-24: Account Management - Permissions This permission control user access to connect to iN7000 Video Server through Internet. Authorized Channel(s) Enter the channel(s) you wish to authorize to view/connect over Internet (e.g. by using Microsoft IE or oth- er iN7000).

  • Page 41: Application Module Settings

    Application Module Settings The iN7000 currently has several main application modules: Windows Media Broadcast, Video Server, Web Server, Application Status Log, and e-Map. These modules are primarily system features that can be individually activated. Please refer to the Modules chapter for details on settings the modules Figure 3-25 Application Modules 900-007556-001 iN7000 User Guide...

  • Page 42: General Setting (Program Settings)

    General Setting (Program Settings) Figure 3-26: General Program Settings Video preview priority You can change the priority of the real-time preview video. Higher priority produces smoother preview video but consumes more CPU resource. Complex video scenes can impact the system resources. 971-007556-001 iN7000 User Guide...
  • Page 43 Allow multi-channel audio preview on the same preview panel Only the main channel audio will be rendered by default. If checked, the audio of all channels will be rendered simultaneously. Minimum disk space Enter the minimum size of disk space to keep in a storage location. If the disk space of a storage location is lower than this value, recording will continue on next storage location or Storage Recycle will begin.

  • Page 44: Scheduler

    Scheduler Figure 3-27: The Schedule Pages There are 2 schedule types: Weekly Schedule and One-time Schedule. A schedule by itself does not begin the recordings. The schedule defines when the system can record if all other configuration is first satisfied. The recording event trigger or continuous recording must first be configured in the Channel set- tings.

  • Page 45: Weekly Schedule

    Weekly Schedule Adding A Schedule A recording schedule requires selecting the cameras that will be included in the schedule and the time to run it. A schedule can be created for each day of the week. Select the Day of week, the individual camera(s) or all cameras with the Select All button that you wish to record from the Run Channel(s) table.

  • Page 46: One Time Schedule

    One Time Schedule One-time Schedule has higher priority than weekly schedule. The One-time schedule overrides the weekly schedule wherever they overlap so the weekly schedule will be ignored during the overlap period. Figure 3-28: One-Time Schedule 971-007556-001 iN7000 User Guide...

  • Page 47: Chapter 4: Playback

    Chapter 4: Playback Playback Window (Local and over IP) Video Log Search Browser Figure 4-29 Playback Window Search Results: Shows the search result with tag, description and event time. Click on the result to open the corresponding media-file and seek to the position where the event occurred. Channel Selectors: Select the channel to search.
  • Page 48 Figure 4-30 Advance Search Dialog There are 3 search modes: a) Simple – condition matches when a tag contains the search keyword. b) Exact – condition matches when a tag is exactly equal to the search keyword. c) Wildcards – search tag with wildcards. i) ‘%’: represent a string of zero or more characters.
  • Page 49 Date Panel: enter the range for searching. Playback Control Panel: conatins the playback buttons and playback status. Figure 4-31 Playback Controls Tag List: When you select a media file on the browser, or click on a search result, the tag list of the corresponding media file is displayed in this area.
  • Page 50 Add a Tag: you can enter a tag for the currently playing media file at the current playback position. To add a tag, the current playback state must be paused or stopped. Snapshot: you can take a snapshot of the current playing media. To take a snapshot, the current playback state must be paused or stopped.
  • Page 51 Figure 4-33 Site Selection 900-007556-001 iN7000 User Guide...

  • Page 52: Timeline Playback (Local And Over Ip)

    Timeline Playback (Local and over IP) This feature permits accessing recorded videos with a 24-hour (down to second) timeline and date con- trol. The video/audio from different channels can be played synchronously in forward or reverse. Figure 4-34 Timeline Playback Channel Control Bar: here you can enable/disable the audio of the playing media or popup a nor- mal playback window for that media.
  • Page 53 Date Selection Control: Select the search date. Site Selection: dialog for login into other sites for remote playback over IP. The default is local. You can also build your site book with frequently visited sites. The remote site to login must bind the Net Service module.

  • Page 54: Chapter 5: Modules

    Chapter 5: Modules Capture Source iN7000 supports hybrid video and audio sources. This means your USB-webcam, PCI/PCI-E capture card hardware, compression card, IP Camera, Windows Media Stream, and remote iN7000 can be connected on the same iN7000 system. However, you have to make sure there is no conflict in your hardware. For example, PCI capture cards from different bands may not be able to work together due to driver and hardware conflicts.

  • Page 55: Directshow-Based Video Device

    DirectShow-Based Video Device Figure 5-36: Capture Source This module allows you to select a DirectShow-based video device as a video source. Examples of Dir- ectShow-based device are USB webcam and PCI/PCI-E capture cards (if the card vendor provides a driver with DirectShow capture filter). In the setting dialog you can select video standard, pixel format, res- olution (from 160x120 to 1920x1080), and frame rate (from 5fps to 60 fps).

  • Page 56: Directshow-Based Audio Device

    DirectShow-Based Audio Device This module allows you to select a DirectShow-based audio device as an attached audio source. The word “attach” is to emphasize that the audio stream is added independent of the video source; that is, they may not be already synchronized. If this situation happens, you should tune the “Attach audio time adjustment”...

  • Page 57: Network Camera

    Network Camera Figure 5-38 : Network Cameras as Capture Source iN7000 includes drivers for many common network camera modules under Unconstraint Type. The most common are JPEG and MJPEG because most network cameras in the market today support them. You may require the network address, ID and password of the device you are adding.

  • Page 58: Windows Media Url

    “.asf”), you could try to connect with the Windows Media URL module. The software natively supports Impath H.264 streams in the i5000 and i5120 series. For a list of suppor- ted IP camera, please contact Impath Networks. 971-007556-001...

  • Page 59: Connecting To Other In7000

    Connecting to Other iN7000 Figure 5-40 : Connecting to other iN7000 This module allows you to connect to a remote iN7000 Video Server. The Video Server module in the re- mote iN7000 must be enabled and you must have a valid account credentials. In addition the account must have permissions enabled for each channel you want to view.

  • Page 60: Analytics

    Analytics 971-007556-001 iN7000 User Guide...

  • Page 61: Basic Motion Detection

    Basic Motion Detection Figure 5-41 : Basic Motion Detection This module raises a “Motion Detect” event when motion is detected on the “unmasked area”. You can create unlimited number of detectors for a channel. Each detector can has its own masked area, sensitiv- ity and tag.

  • Page 62: In7000 Video Content Analysis

    iN7000 Video Content Analysis Figure 5-42 : Video Content Analysis This module analyzes video content for counting objects, detecting loitering objects, detecting objects en- tering or leaving an area. The module has 2 sub-modules: Object Tracker and Event Detection. Object tracking is a technology to track objects in video streams.
  • Page 63 Import Notes About Video Content Analysis Please take note of the following before you use this module or decide to buy the Video Content Analysis Edition: - Video content analysis is a sophisticated technology for the general video security environment. Impath cannot guarantee the accuracy of the results under field settings.

  • Page 64: Object Tracker

    Object Tracker Object tracking is the heart of almost all event detectors. The proper setting of Object Tracker is one of the most important factors for the accuracy of the results. You should study every single setting carefully and experiments for tuning the settings to produce the best possible result. You can create multiple Object Trackers for multiple event detectors.
  • Page 65 Figure 5-44 : Object Tracking Parameters - Object maximum allow hidden time: this value sets the maximum time that an object disappears (e.g. hide behind a building or tree). If an object has disappeared for this time, it is considered immobile. - Hidden-object life-time threshold: object tracker can remember objects that disappear.

  • Page 66: Event Detectors

    Event Detectors Figure 5-46 : Event Detector The video content analysis module currently provides seven event detectors including: “Detect Object Moving inside Region”, “Detect Object Enter or Leave Region(s)”, “Detect loitering object(s)”, “Detect ob- jects congregating in an area”, “Detect illegally stopped objects”, “Detect object cross line(s)”, and “Object counter”.
  • Page 67 Figure 5-47 : Adding Event Detectors To add an event detector, press the Add button. The Add Event Detector dialog will display the available detectors. At this time you should define a tag for that detector instance. The tag will be inserted with the event being triggered and can be used as a keyword in video searching.

  • Page 68: Object Moving Inside Region

    Object Moving inside Region Figure 5-48 : Object Moving Inside Region This detector requires you to select an object tracker and the directions to be detected. 971-007556-001 iN7000 User Guide...

  • Page 69: Detect Object Enter Or Leave Region(S)

    Detect Object Enter or Leave Region(s) Figure 5-49 : Detect Object Enter or Leave Region(s) This detector requires you to select an object tracker and the direction (entering or leaving) to detect. 900-007556-001 iN7000 User Guide...

  • Page 70: Detect Loitering Object(S)

    Detect loitering object(s) Figure 5-50: Detect loitering object(s) This detector requires you to select an object tracker and a threshold to define loitering. If an object stays or keeps moving in the defined region for over the threshold time, it triggers the loitering event. 971-007556-001 iN7000 User Guide...

  • Page 71: Detect Objects Congregating In An Area

    Detect objects congregating in an area Figure 5-51: Detect objects congregating in an area This detector requires you to select an object tracker and a threshold of object number to define congreg- ating. If the number of objects in the defined region exceeds the threshold number, it triggers the event. 900-007556-001 iN7000 User Guide...

  • Page 72: Detect Illegally Stopped Object(S)

    Detect illegally stopped object(s) Figure 5-52: Detect objects congregating in an area This detector requires you to select an object tracker and a threshold to define “illegally stopped”. If an ob- ject stays motionless in the defined areas for over the threshold time, it triggers the event. Please note that the “object maximum allow motionless time”...

  • Page 73: Detect Object Cross Line(S)

    Detect object cross line(s) Figure 5-53: Detect object cross line(s) This detector requires you to select an object tracker and the lines to detect. 900-007556-001 iN7000 User Guide...

  • Page 74: Object Counter

    Object Counter This detector requires you to select an object tracker and the lines to count. You can also configure when to reset the counter. 971-007556-001 iN7000 User Guide...

  • Page 75: Filters

    Filters Timestamp OSD Filter Figure 5-54: Object Counter To embed a timestamp on the video you must bind this filter. This filter allows you to add additional strings, such as channel number, in the embedded timestamp. Mask Region Filter Figure 5-55: Mask Region Filter If your video contains sensitive areas and you want to exclude those areas from the video, you can use this filter.
  • Page 76 Tag Overlay Filter This filter can filter event tag to the screen, as below: Figure 5-56: Tag Overlay Filter Figure 5-57: Tag Overlay Filter Controls You can configure the offset, font, font size, dwell time (the interval the tag to stay on screen after the event is over), and event of interest.
  • Page 77 POS Text Overlay Filter This filter overlay POS transaction to the live video, as below: Figure 5-58: POS Text Overlay Filter This module can be used together with the Transact(POS) application module, or on a client computer to subscribe POS transaction event from the another iN7000 computer and overlay transaction in real-time. Figure 5-59: POS Text Overlay Filter Controls In the dialog you can setup offsets, font, font size and dwell time (the interval the transaction text to stay on screen after the transaction is over).

  • Page 78: Event Handler

    Event Handler Basic Event Presenter Figure 5-60: Basic Event Presenter Controls This presenter presents events from Motion Detection Module as alarm. You can set the duration and col- or for visual alarm. You can also configure whether to trigger sound alarm and alarm indicator. Figure 5-61: Event Presenter Example The figure above shows that motion is detected on an area of interest.
  • Page 79 Video Content Analysis Result Presenter The Advanced tab opens a page for customizing the on-screen presentation result of the video content analysis. Figure 5-62: Video Content Analysis Result Presenter There are settings for object tracker and other event detectors. For object tracker, you can configure whether to show object boundary, object direction, object trajectory, object center, alarm and normal colors.
  • Page 80 For event detector, you can set the duration and color for visual alarm. You can also configure whether to trigger sound alarm and alarm indicator. Figure 5-64: Video Content Analysis Result Presenter The setting for object counter presenter is a little bit more: Figure 5-65: Video Content Analysis Result Presenter More than the normal event detector setting, you can also setup the count value font size, as well as se- lect whether to show the tag and count value on the left upper corner.
  • Page 81 Email Notification Module Figure 5-66: Event Notification Module This module sends email to your email account whenever event occurs. Here are descriptions of some selected settings: - Alarm Interval: the minimum interval between each email sending. - Attach Image: attach channel video images to the email. 5 images will be attached. The sample interval between each image is 1 second.
  • Page 82 Figure 5-67: Email Notifier – Event Settings Add/Remove events that should initiate an email messages. Uncheck “Tags of Interest” to activate for all/any tags of that event. 971-007556-001 iN7000 User Guide...
  • Page 83 Alarm Popup Figure 5-68: Alarm Popup Event Handler This module raises a pop up video window when selected events occur. You can use regular expression pattern in defining “tags of interest”. Regular expression is a very powerful tool to express text pattern. For a detail tutorial you can search the Web.
  • Page 84 Net Event Subscriber Subscribe event from other instances of iN7000. This module connects the Net Service module running on any other iN7000 system. Figure 5-69: Net Event Subscriber The security mode must match that of the Net Service to be connected. 971-007556-001 iN7000 User Guide...
  • Page 85 Net Event Forward This is a module to actively forward event to other instance of Cyeweb. For example, in serverclient solu- tion, the clients may need to actively inject event to the server. This is the module to use. Figure 5-70: Net Event Forward In the setting dialog you need to configure the destination iN7000 system’s Net Service address, port, lo- gin id/password, channel, security mode, and events to forward.

  • Page 86: Devices

    Devices 971-007556-001 iN7000 User Guide...

  • Page 87: Ptz Control

    PTZ Control Figure 5-71: PTZ Control iN7000 provides a PTZ Control device module supporting Pelco-D and Pelco-P protocols. This module enables control of the PTZ camera connected to video capture device of the channel under configuration. 900-007556-001 iN7000 User Guide...

  • Page 88: Rs232 Alarm Box

    RS232 Alarm Box This module allows you to connect external alarm box to integrate sensors and digital outputs for con- trolling external devices. Figure 5-72: Alarm Box Use this dialog to setup the protocol, serial port, device address, alarm in (digital input), alarm out. In the Alarm In setting there is a Check Interval for configuration of the frequency to check the digital in- put.

  • Page 89: Compression

    Figure 5-74 Alarm Box - Alarm Out Compression 900-007556-001 iN7000 User Guide...

  • Page 90: Built-In Compression Module

    Built-In Compression Module Figure 5-75: Compression Module iN7000 currently has one video/audio compression module for local storage and Internet broadcast. The audio and video compression codecs are WMA Pro and WVC1 respectively(a VC-1 compliant codec, which is a direct competitor to H.264. You can find more information by searching the keyword ‘VC-1’...
  • Page 91 Figure 5-76: Same as Storage - Use existing compressed stream: Depending on your capture source, there may be already com- pressed video/audio stream. For example, source from network camera typically has a compressed MJPEG stream in which case you can save a compressor. Using existing compressed stream is not man- datory.
  • Page 92 - Pre-compress Cache Size: the size of the buffer that stores uncompressed data. A large value con- sumes more system memory, while a small size can render the “Pre-event time” ineffective. You should calculate an appropriate size according to the frame rate and resolution of your capture source. For ex- ample, a video capture source with resolution 640x480 at 30fps and I420 pixel format requires 640x480x30x1.5 = around 13 MB per second.

  • Page 93: Application Module Settings

    Application Module Settings Select Application Modules from the Program Settings page. Several program level application mod- ules can be activated with this page. Click the Add button to view the Select Modules dialog. The dialog list only modules that have not yet been activated. Activated modules will are listed in the Selected Mod- ules field of the page and can be edited or removed.

  • Page 94: Windows Media Broadcast

    Windows Media Broadcast Figure 5-77: Windows Media Broadcast This module receives compressed video/audio from the compression module and then broadcasts to In- ternet in Windows Media format. Select the channels to broadcast and set the maximum number of con- nection clients allowed for each channel and set the seed port. If you set the seed port to 9801 (default), the broadcast URL for channel 1 is as follows: mms://<your_internet_address>:9801, channel 2 is mms://<your_internet_address>:9802, and so on.

  • Page 95: Video Server

    Video Server This is the iN7000 system’s video streaming server for streaming media to Internet over TCP/IP protocol. Connections can be made by using Microsoft IE or a remote iN7000. Figure 5-78: Video Server Channels are individually enabled for remote access in each account profile via Account Management.

  • Page 96: Web Server

    Web Server The Web Server is an Http web server module for users connecting remotely with Microsoft IE. Check the Bind Module box to enable the server. To use this module you must also bind the Video Server module because when IE will actually pull live videos from the iN7000 Video Server.
  • Page 97 Upon successfully installing the ActiveX control and connecting with an authorized account level the video should appear. You may select the channel(s) to view using the Enabled Channels controls. If video is lagging because of low network bandwidth, try disabling some channels. You can use the PTZ Control sto move the camera after selecting the camera in the drop down box (Select for PTZ).

  • Page 98: Application Status Log

    Application Status Log Figure 5-83: Application Status Log This module posts application log messages, including video server connections, IP camera connections. You can configure the number of lines of log data to display on the log window. After binding this module, you will see the application log window on the Module view in the Main console.

  • Page 99: E-Map

    E-Map Figure 5-84; e-Map With the e-Map module, you can organize your cameras and devices into a map view. The e-Map has an event viewer where you can quickly locate the device/camera that triggered the events and open a play- back window to review the video at the position where the event occurred.
  • Page 100 Figure 5-86: Channel Facility Dialog You can also define Event Button(s) that the operator can click to manually post event to the system. Figure 5-87: Event Buttons 971-007556-001 iN7000 User Guide...
  • Page 101 You can move the facility to any location by dragging it on the map. Right-click the facility icon to edit, de- lete, or duplicate it. Figure 5-88: Edit the Facility e-Map Control Figure 5-89: E-Map Controls 1) Tree View of the map layers 2) Map: the map and facilities of the selected map layer.
  • Page 102 Figure 5-90: Quick View Window 3) Quick Videos: live video of the selected channel facility are displayed here. 4) Event Viewer: events in any facility are displayed in this area. The 2 buttons on the left hand side of the event log immediately locate the facility and launch a pop up playback window at the position where the event occurred (the popup playback is effective on channel facility with compression module bound).

  • Page 103: Spot Screen

    Spot Screen The Spot Screen module is for viewing alarmed channel in a single large monitor. There is no setting re- quired for this module. Simply bind the module and then click on the channel icon (as shown below) of the alarmed channel to display its video in the Spot Screen The Spot Screen is displayed in the floatable Module View window.

  • Page 104: Transact (Pos)

    Transact (PoS) Figure 5-93: Transact (POS) Transact module can be used for loss prevention to capture activities at the counters of supermarket, ATM, etc. The administrator defines alarm rules for abnormal transactions such as high amount of refund or withdrawal. The operator can search through the transact-activities and playback the videos with just a few keywords.
  • Page 105 Settings Figure 5-94: Transact (POS) Settings You can create transact configurations for up to 64 channels with the option to enable or disable transact monitoring and define 2 helper channels for each channel. The helper channels are for cases where 2 or 3 cameras are used to monitor one transact-location.
  • Page 106 Figure 5-95: PoS Filtering Rules In the filtering rule window, you first capture data from PoS system or load a text file storing raw capture data. (If you capture data directly from PoS system you can save it to file for future configuration use.). You may also define the encoding.
  • Page 107 examples: - “^ABC$”: represent a string of exactly “ABC”. - “^refund.*”: represent a string start with “refund” and flowed by any number of characters. - “\$.*.,...\..*”: represent a string that contains a ‘$’ following by any number of characters and then a ‘,’ and any 3 characters and then a ‘.’...
  • Page 108 Figure 5-97: Add PoS Alarm The condition mask is the rule of the alarm. The program will check every line of a receipt with the rule. If the rule matches, the alarm will be triggered. You can use regular expression (described in the Filter sec- tion) to define the rule.
  • Page 109 Net Service POS has a Net Service to accept transaction query and injection over IP. A third-party developer can use the SDK to inject transaction into the POS module. To setup the Net Service, you need to assign a port, select a security mode, and optionally define a con- nection key code.
  • Page 110 Browse and search Figure 5-99: Browse and Search Transact Activity The operator can browse and search the transact-activities via the main desktop. The control is similar to the playback system with browsing transactions by time and channel, or keywords which can include wild- cards.

  • Page 111: Object Counter Statistics Module

    Object Counter Statistics Module This module collects counter data and presents it graphically. There is no setting required for this module but you need to bind it. The Object Counter Statistics Module uses a separate database to collect counter data in real-time.

  • Page 112: Net Service

    Net Service This module is to support event forwarding, injection and remote playback. Bind this module if you want to use these functions. Figure 5-101: Net Service Module There are 2 security modes: None and Windows. Selecting Windows (use Active Directory for encryption and authentication) is safe on Internet environment and the computer connecting to this Service must lo- gin with the same Windows ID and password.
  • Page 113 Figure 5-102: Net Service Events Publisher Select the channels, events and tags to publish in the Channel Event Publisher. This is for other in- stance of iN7000 or software using the SDK for subscribing events over IP. If you uncheck Send Event Details, only event id and tag will be sent. Other event details such as motion region, counting lines, etc will not be sent.
