Connecting Mode" Menu - HomeMatic HM-WDC7000 Operating Manual

The user can set the brightness threshold on an individual basis in order to adapt
the sensor to local conditions. The threshold value should be defi ned as when the
sun comes up or goes down so that the current brightness value can be used to
calculate the threshold.
Example: After sunrise the brightness value is 131, for example. This means that the
threshold value should be set to 131 so that the hours of sunshine start to be coun-
ted from that point.
- Select the "SYSTEM" menu then the "SUN CAL" option (via BEEP, DCF, DST,
INTERVAL, ALTITUDE and RAIN CAL) and the following appears:
SUN CAL
- Touch "ENTER" and the following appears:
SUN CAL
- Touch "+" or "-" to set the threshold value. The setting range runs from 0 to 255.
- Wait for a few seconds. The device will then return to normal mode.
1
It is not possible to directly convert this value into the lux unit of luminance.
4.3.8

"CONNECTING MODE" menu

In connecting mode you can teach-in the internal sensors of the WDC7000 to other
WDC7000 stations and to the HomeMatic central control unit. To do this, you must
set the corresponding connection partners and the WDC7000 to teach-in mode.
CONNECTING MODE
- To launch teach-in mode touch "OK" and the following appears:
The WDC7000 is now in teach-in mode. Once the teach-in procedure has been
completed successfully, teach-in mode and the confi guration menu are exited. If no
teaching-in is performed for 20 seconds, teach-in mode and the confi guration menu
are exited.
131 + 085 -
CONNECTING
ENTER
Decrease threshold
Threshold currently set
Increase threshold
Current brightness value1
OK
63
