Page 1: User Manual
User Manual HD Player Pro Rev.2 AV Stumpfl GmbH Mitterweg 46 A-4702 Wallern Tel.: +43-7249-42811 Fax: +43-7249-428114 E-Mail: AVstumpfl@AVstumpfl.com Internet: http://www.AVstumpfl.com... - Page 2 FCC Notices It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
8.4 Seamless-Function ........................25 8.5 FTP auto download function ......................26 8.6 Controlling the HD Player Pro (RS232/TCP) .................. 29 8.7 How to sync several HD Player Pro ....................30 8.7.1 Important to know: ......................33 HTTP COMMAND FUNCTION ......................34 9.1 Control ............................ - Page 4 10.2.2 Advance Schedule......................43 10.2.3 Explanation of the Warning Message ................45 10.3 Apply the Schedule on the HD Player Pro..................45 OPTIONAL AUXILIARY EQUIPMENT ....................46 11.1 Play-Button Box (SCV-HDZ-PBB) ....................46 11.2 IR cable (SCV-HDZ-IRC) ....................... 46 11.3 PIR sensor (SCV-HDZ-PIR) ......................47 11.3.1...
-
Page 5: Package Contents
1. PACKAGE CONTENTS 1. HD Player Pro 2. Remote Control 3. CF Card Protective Cover 4. Video & Audio Cable 5. RS-232 Cable (optional) 6. VGA to Y.Pb.Pr Cable 7. Power Adapter 8. Quick Guide 9. CD Driver - Schedule Software... -
Page 6: Features
Export of the Configuration Value: You can export the configuration value to the CF card The configuration value can be modified on your PC, and can be applied to the HD Player Pro Supports FTP Auto Download Function: Connect to Remote FTP server and download data to the CF card automatically ... -
Page 7: Hardware Overview
4. HARDWARE OVERVIEW... -
Page 8: Remote Control
CF Card Socket: for Compact- Flash memory card SDHC-Card Socket: for Secure- Digital- High- Capacity Cards “RESET” Button: for restarting the HD Player Pro 5. REMOTE CONTROL Power on/ off Select the output mode Numeric Key Delete last entry... -
Page 9: Entering Text Or Ip-Address
Status 1: If the “AUTOPLAY (Movie/ Picture/ All Files/ MultiLayer)” function is enabled and there are media files on the CF card or the HD Player Pro is already connected to the display device, the HD Player Pro will auto play media files after Power on. -
Page 10: Setting Up
IP Assigned by DHCP: If you have a DHCP-enabled router, please select “On”, and then the router will automatically assigns an IP address to the HD Player Pro. If you don’t have a DHCP –enabled router, select “Off” and type the network information in “Assign IP Address”. - Page 11 Assign IP Address: If the HD Player Pro is connected to a network without a DHCP server or you want to use Local FTP Server function, enter the fixed IP address, Mask, Gateway and DNS for the HD Player Pro.
-
Page 12: Setting The Network From The Ip Detect Tool
7.1.2 Setting the Network from the IP Detect Tool With the bundle tool “IP Detect”, users can search for HD Player Pro on the local area network. Users are also able to change the IP setting via this tool. For example, you want to assign a static IP to HD... - Page 13 Step3: Double click on the icon to start the tool. Step4: Click on the “Auto Detect” button, then the tool will show all available HD Player Pro in the local area network. NOTE: When use HD Player Pro under a DHCP-enabled network, user sometimes does not know which IP address is assigned to HD Player Pro.
- Page 14 Step6: The default IP mode of HD Player Pro is DHCP. User should change the mode to “Manual”, if he wants to assign a static IP address to HD Player Pro. Then enter the preferred “IP”, “Net Mask” and “Gateway” in the “Network Setting”. Finally, click on the “Setup” button for completing the setting.
-
Page 15: Ftp Setup
Local FTP Server: Turn on/ off the HD Player Pro server. (If you use the HD Player Pro server, please disable the DHCP function and input a fixed IP address, Mask, Gateway and DNS of the HD Player Pro) Local FTP Server Setup: Set the “Port”, “User ID”... - Page 16 NOTE: GMT and applied regions Time Zone Region Time Zone Region (GMT-12:00) Eniwetok, Quazalen (GMT+02:00) Helsinki, Riga, Tallinn (GMT-11:00) Midway, Ireland, Samoa (GMT+03:00) Nairobi Moscow, Saint Petersburg, (GMT-10:00) Hawaii (GMT+03:00) Volgograd (GMT-09:00) Alaska (GMT+03:00) Baghdad Pacific GMT (U.S. & Canada); (GMT-08:00) (GMT+03:00) Kuwait, Raid...
-
Page 17: Video Setup
Local HTTP Server: Enable/ Disable the HTTP command function. Local HTTP Server Setup: To set the “Port”, “User ID” and “Password” of the HD Player Pro. (The Default Port: 80, User ID: root, Password: admin) NOTE: Press the “SETUP” button on the remote control to save the settings, and it will auto exit the settings screen, then restart the HD Player Pro. -
Page 18: Other Setup
SlideShow Interval: Set the time each photo is shown to 10, 15, 30 seconds or 1, 10, 15, 30 minutes or 1 hour. . Lock Remote Controller: Enable/ disable the auto key lock function. (The HD Player Pro will auto lock when there is no further input for 1 minute.) ... - Page 19 Player Pro, the HD Player Pro will apply the new settings automatically. Play Button: Only for used with play buttons. The HD Player Pro supports two options (Repeat Default / Repeat All) when the demo file finishes playing. ...
-
Page 20: Scrolling Text Setup
7.5. Scrolling Text Setup Multiple Display: Movie (full) Movie (small) Movie + Pic (L) Movie + Pic (R) Picture Slide: Sets the mode of picture slideshow (By Slide Time/ Match Video). Scrolling text: Sets the style of the font. Supported fonts are: Latin1, Latin2, Japanese and Greek ... -
Page 21: Using The Hd Player Pro
Play media files on the CF-Card Step 1: Insert the CF card with media files, then turn on the HD Player Pro and press the “ENTER” button on the remote control when “’mnt/CF” is highlighted to take you into the CF card. -
Page 22: Using The Remote Control When Media File Is Playing
8.1.1 Using the Remote Control when Media File is playing SETUP: Press the button to adjust the brightness, contrast or saturation while the video or picture is displayed. With the “+ VOLUME –” button - First Press: Adjust the brightness - Second Press: Adjust the contrast - Third Press: Adjust the saturation Brightness... - Page 23 Original Size First Press：ZOOM 01 Second Press：ZOOM 02 Third Press：ZOOM 03...
-
Page 24: Multiple Display Zones
8.2 Multiple display zones Step 1: Put your movies, pictures (only supports PNG format/ size: 213x641/ 96DPI) and text file on the CF card. Picture Files If you select the “By Slide Time” item of the picture slide mode; please name the picture files 0.png ~ 9.png. -
Page 25: Log Function
NOTE: 1. MOV video file limitation: - Frame rate: up to 30fps - Bit rate: 30~40 Mbps - Resolution: up to 1080p 2. If the Seamless Playback function is enabled, the HD Player Pro can only play the MOV videos. -
Page 26: Ftp Auto Download Function
2009/08/21 10:40:0 Format: yyyy/mm/dd hh/mm/ss Note: This field cannot be blank; otherwise the HD Player Pro won’t restart nor play the downloaded files. Delete the original files on the CF card after finish downloading. [del] on: Delete the original files on the CF card HD Player Pro off: Keep the original files. - Page 27 Item Description Enter the filename you want to download. [file] 001.mpg Note: The length of file name and extension cannot exceed 20 characters. 002.mpg The file schedule.ini is created by the Schedule Maker software. (refer to section 10) 0.png The file message1.txt is a text file that can change scrolling text settings. Use the “Notepad” to 1.png create the text file on your PC as shown below, and named the file message1.txt (you can schedule.ini...
- Page 28 Example: The MAC address of HD Player Pro is 0013fe098819, and named the file d0013fe098819.txt. NOTE: The MAC address of HD Player Pro will be displayed in the setup menu. Step3: Put all the files (included media files/ command file (ex. d0013fe098819.txt/ schedule.ini/ message1.txt) to the FTP server.
-
Page 29: Controlling The Hd Player Pro (Rs232/Tcp)
8.6 Controlling the HD Player Pro (RS232/TCP) Use the tool “Tera Term” or other tools to control the HD Player Pro with ASCII command. To enable this function the RS232 Control must be set to “Command” RS232-Control: baud rate: 19200 8N1... -
Page 30: How To Sync Several Hd Player Pro
8.7 How to sync several HD Player Pro Step1. Please connect all HD Player Pro via a RJ-45 Cable with an Ethernet Switch Step2. Assign IP Address to HD Player Pro: The Address must be in the same Subnet, Gateway and DNS. - Page 31 Step3. Turn on the Sync-Control on every HD Player: Step4. Set Master/Slave: Set one HD Player Pro to be the Master and the other units (up to 254 units) to be Slaves.
- Page 32 NOTE: HDPlayerSettings.txt-File For easier configuration you are able to export the “Settings File” of the HD Player onto the CF- Card: Press Enter to Export Settings File Insert the CF-Card with the “HDPlayerSettingsd.txt” in your PC. Open the “HDPlayerSettings.txt”-File with notepad.exe or wordpad.exe or any other text editor.
-
Page 33: Important To Know
In the HDPlayerSettings.txt-File you can assign a new IP Address and change other Settings. When you now reinsert the CF-Card to the HD Player Pro it will “read” these Settings and assumes these Settings as the new ones. ATTENTION: If you set a Local IP, please turn of “IP Assigned by DHCP” (ref.: 7.1.1) 8.7.1 Important to know:... -
Page 34: Http Command Function
Setup” has been completed (refer to 7.2). Set your router or firewall, and open the port 80 for the HD Player Pro. The following figure is an example - please refer to your user’s manual of router for opening ports. -
Page 35: Control
Control Control: Select one of the control command s, and press the “Send” to control the HD Player Pro immediately. Stop: Stop playback Play: Start playback. Pause: Pause the playback. Prev: Play the previous file. -
Page 36: Network
General Setup Enable DHCP: Enable or disable the DHCP function. IP/ Subnet/ Gateway/ DNS server: Enter the fixed IP address, Subnet, Gateway and DNS for the HD Player Pro. Wireless Setup (not used for this type of Player) -
Page 37: Server
Password: Enter the password of the HD Player Pro (default password: admin). FTP Server Address: Click on the address to directly connect to the HD Player Pro server. Enter the user name and password (Default User Name: root, Default Password: admin) to log on. -
Page 38: Time
Time NTP Server Enable: Enable or disable the NTP server function. GMT Server: Enter the NTP server IP address like: 66.187.233.4. Time Zone: Set the time zone of your location. -
Page 39: Features
Port: Enter the port of the HD Player Pro (default port: 80) User ID: Enter the user name of the HD Player Pro (default ID: root). Password: Enter the password of the HD Player Pro (default password: admin). -
Page 40: Schedule Function
10. SCHEDULE FUNCTION NOTE: The “NTP Server” or “Local Time” must be set before using the Schedule Function. (refer to 7.2) 10.1 Install the Schedule software Step1: Insert the driver CD into your CD-ROM drive, then open the Folder “Scheduler” and run the IPSetup.exe. -
Page 41: Start The Schedule Software
10.2 Start the Schedule Software You might double click the “Schedule Maker” icon on your desktop for opening the “Schedule Generator”. Or you might click on <Start> → <Programs> → <Schedule Maker 20090217> → < Schedule Maker > for starting the program. ... - Page 42 Select the file that you want to modify in the list, and press the “Modify” button. Remove: Click this button to remove the file from the list. Move Up / Move Down: Click these buttons to change the order that the files are played.
-
Page 43: Advance Schedule
Press the “SAVE” button and a pop-up window will appear. Select the path, then click the “SAVE” button to save your setup. NOTE: Do not rename the file (schedule.ini), otherwise the HD Player Pro will not be able to read the file. - Page 44 Step 4: After finishing all setup, press the “SAVE” button and a pop-up window will appear. Select the path, then click the “SAVE” button to save. NOTE: Do not rename the file (schedule.ini), otherwise the HD Player Pro will not be able to read the file.
-
Page 45: Explanation Of The Warning Message
10.3 Apply the Schedule on the HD Player Pro Put the “schedule.ini” file and the associated media files on the memory card, and insert the memory card to the HD Player Pro. The HD Player Pro will auto play the files at the designated time. -
Page 46: Optional Auxiliary Equipment
Demo File 4：a01.xxx Demo File 5：b55.xxx Step 2: Insert the CF card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. Step 3: Press one of the buttons 1-5 to play the corresponding demo file. -
Page 47: Pir Sensor (Scv-Hdz-Pir)
11.3.1 Using the PIR Sensor Step 1: Set the repeat mode to the “Repeat Default”. Step 2: Insert the CF card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. -
Page 48: Ex. Using The Wireless Touch Sensor Buttons
11.4.4 Play the Demo Files Step 1: Insert the CF card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. Step 2: Press one of the touch-sensor buttons 1-5 to play the corresponding demo file. -
Page 49: Led Button Box
Demo File 4: a01.xxx Demo File 5: b55.xxx Step2. Insert the memory card to the HD Player Pro, and the HD Player Pro will play the default file automatically while powered on. Step3: Make sure the Play Button item is set Repeat Default (refer to section 7.4 <Play Button> →... -
Page 50: Usb Auto-Copy Function
Step2: Put the files that you want to copy and the file “AUTOCOPY.ini” onto the USB flash driver. Step3: Insert the USB flash drive to the HD Player Pro, and it will automatically copy the files from USB flash drive to CF card (it takes about 30sec until the HD Player starts copying the Files). -
Page 51: Troubleshooting
Check your IP settings on the Network Setup page. (refer to 7.1) Network Not Working If using wired network, make sure the network cable is plugged in on both the HD Player Pro and your network hub. Check connections of the RJ45-Cabel Check if the Switch is turned on Check if “sync.-Control”... -
Page 52: Recommended Cf-Cards
RECOMMENDED CF-CARDS Manufacturer Productname Size [GB] SanDisk SanDisk SanDisk SanDisk Extreme SanDisk Extreme III SanDisk Extreme IV SanDisk Extreme IV Transcend 600x Transcend 400x Kingston ultimate600x 16. RECOMMENDED VIDEO FILE FORMATS MPEG-4.10 (H.264) BP@L3 SMPTE 421M (VC-1) MP@HL and AP@L3 ...
