  • Page 1 – Gebruikshandleiding – Instruktionsbog – Instruktionsbok – Käyttöohjekirja – Brukerhåndbok – Manuale del proprietario/opera- tore – Manual del operador/propietario – Manual do Proprietário/ Operador – Руководство владельца/пользователя – Instrukcja Obsługi / Operatora - 988316 - HR1536FXPCE 988319 - HR1544FXPCE (Rear Discharge) 988320 - HE1748FLPCE ENGLISH FRANÇAIS...
  • Page 2 Facsimile (920) 756-2407 DECLARAÇÃO DE CONFORMIDADE CE EMITIDA PELO FABRICANTE – We the undersigned, ARIENS COMPANY, certify that: Nous, soussignés ARIENS COMPANY, certifions que : Der Unterzeichnete, ARIENS COMPANY, bescheinigt, dass: Wij, de ondergetekenden, ARIENS COMPANY, verklaren dat: Undertegnede, ARIENS COMPANY, attesterer, at: La sottoscritta società...
  • Page 3 Quality and Conformance Manager (Keeper of Technical File) Date Date Datum Responsable de la qualité et de la conformité des produits Datum Dato Data Ariens Company (Dépositaire de la fiche technique) Manager Qualitätssicherung Fecha Dato Datum Brillion, WI 54110-0157 USA und Konformität (Archivar der technischen Akte) Kwaliteits- en...

  • Page 4: Table Of Contents

    Discuss and emphasize the Safety Precautions. Give PRODUCT REGISTRATION customer Owner/Operator, Parts, and Engine The Ariens dealer must register the product at the time of Manuals. Advise customer to thoroughly read and purchase. Registering the product will help the company understand them.

  • Page 5: Safety

    SAFETY PRACTICES AND LAWS WARNING: This cutting machine is capable Practice usual and customary safe working precautions, for of amputating hands and feet and throwing the benefit of yourself and others. Understand and follow all objects. Failure to observe the safety safety messages.
  • Page 6 1. Danger! To avoid serious injury or death 3. Warning! Read the operator’s manual. Always stand clear of discharge. OL0910 OL1801 Keep children and others away from unit DO NOT operate mower unless guards are in while operating. operating position or bagger is attached. OL3320 OL4370 Never direct discharge toward other people.
  • Page 7 Read the entire Owner/Operator manual and other training NEVER modify or remove safety devices. material. If the operator or the mechanic cannot read the ALWAYS keep discharge cover or complete grass catcher in manual, it is the owner’s responsibility to explain it to them. place and in proper working condition.
  • Page 8 Secure unit chassis to transport vehicle. NEVER secure California to cause cancer and reproductive harm. Wash from rods or linkages that could be damaged. hands after handling. Reverse connections may cause sparks which may result in DO NOT transport machine while engine is running. injury.

  • Page 9: Assembly

    ASSEMBLY WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. 1. Remove the unit from shipping container. 2. Adjust tire pressure to 8 to 16 psi (55 to 110 kPa). 3. Service and connect battery. See Charge Battery on page 21.

  • Page 10: Controls And Features

    CONTROLS AND FEATURES Figure 4 1. Operator Presence Control Lever 11. Ignition Switch 2. Parking Brake 12. Bypass Valve Levers 3. Choke Control 13. Control Levers 4. Throttle Lever 14. Control Stop Lock Lever 5. PTO Switch 15. Pivot Bar 6.

  • Page 11: Operation

    OPERATION WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. CONTROLS AND FEATURES See Figure 4 for controls and features locations. SAFETY INTERLOCK SYSTEM Won’t Runs Engage DANGER: SAFETY INTERLOCK SYSTEM FAILURE and improper operation of unit can Disengages Runs result in death or serious injury.
  • Page 12 Ignition Switch (988316, 319) Recoil Starter Handle Pull the recoil starter handle to start the engine. Operate the ignition switch with the removable key. The switch uses two positions: Off (1) and Hour Meter On (2). To start the engine, turn the key to On Recoil Start: The hour meter measures the (2) and pull the recoil handle.
  • Page 13 Add fuel to the fuel tank as needed. See engine manual for IMPORTANT: DO NOT operate starter motor more than 15 type and grade of fuel. seconds per minute, as overheating and damage can occur. If engine will not start, refer to Troubleshooting or Engine To add fuel to the fuel tank: Manual.
  • Page 14 • To turn to the left, push the right hand control lever CUTTING HEIGHT ADJUSTMENT forward. Fixed Decks 1. Shut off the unit. See Shut Off on page 13 and "To stop mowing." 2. Lift deck by handle until mower lock pins can be pulled out of holes.
  • Page 15 LAWN STRIPER ADJUSTMENT (48" decks) TO TRANSPORT UNIT The striper drags behind the deck and shapes grass as you ALWAYS shut off engine, remove key and drain fuel when mow. transporting unit on a truck or trailer. Use extra care when loading or unloading unit.

  • Page 16: Maintenance Schedule

    MAINTENANCE SCHEDULE Period Service Task Check Safety Interlock System WARNING: Safety interlock system failure and improper operation of unit can result in death or serious injury. Test this system each time the unit is operated. If this system does not function as described, do not operate until repairs are made.

  • Page 17: Service And Adjustments

    SERVICE AND ADJUSTMENTS 2. Remove tank from frame and allow tank to tip rearward WARNING: AVOID INJURY. Read and to allow oil to drain from system (Figure 8). understand the entire Safety section before 3. After most of the oil has drained, turn the tank upside proceeding.
  • Page 18 GENERAL LUBRICATION Check Reverse Tracking Apply a small amount of oil to the pivot points as required for WARNING: Uncontrolled reverse travel can smooth operation (Figure 9). result in serious injury. Apply high quality lithium based grease to all lube fittings Do not put control levers into the reverse every 50 hours of operation.
  • Page 19 2. Disconnect clevis from speed control arm. Tire Parking Brake Arm 3. Remove speed control arm from hydraulic pump. 1/8" (3 mm) NOTE: Save speed control arm and hardware to return unit to slower speed range. 4. Connect clevis to return to neutral bracket on the hydraulic pump with clevis pin and hairpin.
  • Page 20 1. Armature 3. Inspection Slot 2. Rotor 4. Gap Adjustment OG0795 Figure 16 1. Mower Clutch 4. Hydro Pump Belt OG1500 Sheave 5. Pump Pulleys 2. Mower Belt BATTERY (988320) 3. Pump Belt Idler Spring Unit comes equipped with a maintenance-free battery that requires no regular maintenance except cleaning the Figure 15 terminals.
  • Page 21 Charge Battery Jump-Starting Ariens does not recommend jump-starting your unit. WARNING: FROZEN BATTERIES CAN Jump-starting can damage engine and electrical system EXPLODE and result in death or serious injury. components. See your engine manual for more detailed information. DO NOT charge a frozen battery. Let the battery thaw before charging.
  • Page 22 Deck Belt MOWER BLADES NOTE: Mower drive belt must be removed before removing NOTE: If mower is used under sandy soil conditions, replace the deck belt. blades when air lifts become eroded through at ends (Figure 20). DO NOT sharpen to this pattern Sharpen to this pattern OG1395 1.

  • Page 23: Storage

    Sharpen the Mower Blades 2. Sharpen mower blade by removing an equal amount of material from each end of mower blade. DO NOT Figure 20. change angle of cutting edge or round the corner of the mower blade. CAUTION: DO NOT sharpen mower blades while on unit.

  • Page 24: Service Parts

    PROBLEM PROBABLE CAUSE CORRECTION Changes in the 1. Loose or missing fasteners. 1. Check all the fasteners. Replace if necessary. sound or 2. Mower blade problem. 2. Check blades for wear or damage. See MOWER vibrations of the BLADES on page 22. unit 3.

  • Page 25: Specifications

    SPECIFICATIONS Model Number 988316 988319 988320 Model HR1536FXPCE HR1544FXPCE HE1748FLPCE Engine Engine Kawasaki Engine Model Number FH430V-BS06 FH500V-AS35 Engine Power – hp (kW) at Maximum RPM 15 (11.2) 17 (12.7) Governed RPM (May be different from 2750 ± 50 2550 ± 50 3250 ±...
  • Page 26 Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407 www.ariens.com...
