Summary of Contents for GVI Security GV-FXDVFA28
-
Page 1: Operating Instructions
Operating Instructions GV-FXDVFA28 GV-FXDVFA40 GV-FXDVFA28P GV-FXDVFA40P Before installing and using the camera, please read these instructions thorough- ly and retain them for later reference. - Page 2 Regulatory Notices For U.S.A CAUTION RISK OF ELECTRIC SHOCK This equipment has been tested and found DO NOT OPEN to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC CAUTION TO REDUCE THE RISK OF Rules.
-
Page 3: Table Of Contents
Table of Contents Safety precautions ......4 What's in the box ......5 Construction . -
Page 4: Safety Precautions
Safety precautions Do not attempt to disas- Avoid the camera with semble the camera direct sunlight To prevent electric shock, do not remove Do not aim the camera at bright objects. screws or covers. There are no user Never face it with direct sunlight or other serviceable parts inside. -
Page 5: What's In The Box
What's in the box M4 Tapping Screws (2EA) (Pan Lock Screw) Camera Body Accessory Video Cable... -
Page 6: Construction
Construction Front view GVI logo 4-pin Dip Switch Tilt Base Zoom Lever Tilting Lock Screw Focus Lever Side view Dome Cover Lens Tilting Lock Screw Dome Cover Separatory Spring... -
Page 7: Rear View
Construction Rear view Dome Cover Separatory Spring Video Out AC Power In Pan Base Base Fixing Hole... -
Page 8: Installation
Installation Video Cable Connection AC 24V WHITE Cable BLACK Cable 1. AC 24V 2. AC 24V 3. WHITE : Connect the WHITE Cable to 3(V). 4. BLACK : Connect the BLACK Cable to 4(G). -
Page 9: Camera Installation
Installation Camera Installation 1. Aim the GVI logo to the place that you wish to watch. 2. Tighten the M4 Tapping Screws to fix the Dome Camera on the ceiling, then adjust the Pan (Left / Right) by moving the Pan Base. - Page 10 Installation NOTE When you disassemble the Dome Cover, lift the Dome Cover • Separatory Spring on the opposite side of GVI logo and turn the Dome Cover clockwise simultaneously. Dome Cover Separatory Spring When you install the camera, handle with care. The camera •...
-
Page 11: Camera Connection
Installation Camera Connection Connect the AC Power Adapter (AC24V, 300mA; supplied) to the Power Input Jack of the camera as shown below. Adapter supplied (Not Rear Panel Monitor... -
Page 12: Setup
Setup 4-pin Dip Switch Setting This camera has the 4-pin Dip Switch inside of the camera for setting. 1. ALC / ELC : ELC (Electronic IRIS), ALC (Auto IRIS) The default setting is ALC. 2. Y/ DC IRIS : When you use Video Lens or DC IRIS Lens The default setting is DC. -
Page 13: Backlight Compensation Setting
Setup Backlight Compensation Setting Backlight compensation eliminates strong background light which makes the camera picture dark such as a spotlight. You can select the mode for adjusting the iris lens. There are two mode as follows. 1. BLC : Set the BLC to ON. The lens iris is manually fixed at the value that you have set regardless of an object. -
Page 14: Line Lock Phase Adjustment Volume
Setup Line Lock Phase Adjustment Volume This function is that V.SYNC signal of the VIDEO signal can move based on the power sig- nal. Use this function when screen conversion of the cam- eras can't become softly. (When screen conversion is working, it prevents the screen from becoming jump with vertical direction.) -
Page 15: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. The picture is poor. • Does the Dome Cover have lots of dust on the surface? Use a dry cloth to clean the camera when it is dirty. Smear may be caused to the screen of night than daytime. -
Page 16: Dimension
Dimension ø100 91mm 10mm 31mm ø121.5 AC24V VIDEO... -
Page 17: Specifications
-68ºF ~ 140ºF (-20ºC ~ 60ºC) (Humidity : 0%RH ~ 85RH) Weight 0.6 Ibs (273g) Dimensions ø121.5(Diameter)x91(H), Dome Size=ø100 * Lens :Vari-Focal Lens f=2.6 ~ 6.0mm/F=1.4 GV-FXDVFA28, GV-FXDVFA28P ** Angular Field of View : 125°~60° GV-FXDVFA28, GV-FXDVFA28P Design and specifications are subject to change without notice. - Page 18 GVI Security, Inc. 2801 Trade Center Dr., Suite 120 Carrolton, TX 75007 Toll Free: 888-595-2288 Fax: 972-245-7333 www.gviss.com MADE IN KOREA P/NO: 3834RS0072K...
