XNET Network Dome Camera User's Guide
XNET Network Dome Camera
User's Guide
Ver. 1.0 (070918)
1 of 44

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XNET and is the answer not in the manual?

Questions and answers

Related Manuals for SNB XNET

Summary of Contents for SNB XNET

  • Page 1 XNET Network Dome Camera User’s Guide XNET Network Dome Camera User’s Guide Ver. 1.0 (070918) 1 of 44...
  • Page 2 XNET Network Dome Camera User’s Guide Directions This product is designed for indoor use only. When using this camera at outdoors or in an environment that exceeds the limited range, you must separately use a water-resistant case. Be careful not to cause any physical damage by dropping or throwing the unit. Especially keep the device out of reach from children.

  • Page 3: Table Of Contents

    5.5. Sensor & Capture Setup ....................26 5.6. Alarm Device Setup......................28 5.7. Motion Region Setup ....................29 5.8. PTZ Setup(This is not related with XNET Network Dome Camera) .......31 5.9. Encryption Set up ......................33 5.10. Upgrade & Reset......................35 5.11. Status Report ......................37 6.

  • Page 4: Introduction

    XNET Network Dome Camera User’s Guide 1. Introduction 1.1. Overview The XNET is a state-of-the-art network camera which transmits synchronized video and audio data in real time at D1 resolution and at full frame rates. Depending on which model you purchased the XNET offered with a standard Ethernet interface.

  • Page 5: Xnet Applications

    XNET Network Dome Camera User’s Guide 1.3. XNET Applications Security surveillance (Buildings, Stores, Manufacturing facilities, Parking lots, Banks, Government facilities, Military, Etc.) Real-time internet broadcasting Remote monitoring (Hospitals, Kindergartens, Traffic, Public areas, Etc.) Teleconference (Bi-directional audio conference) Distance (Remote) Learning/Education Weather and environmental observation 2.

  • Page 6: Physical Description

    2.3. Physical description 2.3.1. Configuration DIP Switches Depending on which model you purchased, the XNET network dome camera comes with one of two optional modules (fixed focal type or vari-focal type). Figure 2-1 illustrates exterior view and internal parts. Accommodating various camera site requirements, the camera module can be configured to enable/disable various video features.
  • Page 7 XNET Network Dome Camera User’s Guide FL or F/L (Fickerless) Set this switch to “ON” to prevent flicker from the following AC Power conditions: Using an NTSC camera in a region with 50 Hz AC power, or a PAL camera in a region with 60 Hz AC power may cause a visible “video flicker.”...
  • Page 8 XNET Network Dome Camera User’s Guide Reset There is a factory default switch provided for returning the network camera to factory default state. Press the switch using tools with sharp tip for a few seconds while power is applied. 2.3.2. Bottom view and Cable Harness...
  • Page 9 This will damage the camera! CNBTEC assumes no responsibility for the damages caused by applying power using both connectors. Sensor In/Relay Out Used for connecting sensor, and alarm devices to XNET. Note that the each signal is differentiated by color of cable. Cable color Description Misc.

  • Page 10: Pc Requirements

    XNET Network Dome Camera User’s Guide 2.4. PC Requirements AV streaming data received from XNET can be decoded or stored in a PC running the XNET- NVR program, which is a live monitoring and digital video recording PC compatible application.
  • Page 11 Guide]. If network type is xDSL or Cable modem you need supplementary information provided by your ISP. ⑤ Connect to XNET in Administrator Mode for initial parameter set-up. The factory default state affords the ability to connect and configure the device in low bandwidth environments.
  • Page 12 Input DC Power to network camera ⑦ Remote video connection to XNET Before attempting to connect and view video from the XNET, install XNET-NVR to the PC. This will automatically install the ActiveX component needed for a direct connection with IE Explorer. For more detailed information on using “XNET-NVR” see the XNET-NVR User Guide.

  • Page 13: Connecting Xnet To Network

    Client PC Figure 3-1. Connecting the XNET to LAN 1. Follow steps 1 through 4 in Section 2.5 to assign an IP address to the XNET. 2. Install XNET and connect to LAN. 3. Test the ability to receive video data when connecting to XNET using XNET-NVR.

  • Page 14: Connecting To An Xdsl/Cable Modem

    3.2. Connecting to an xDSL/Cable Modem 1. Follow through steps 1 through 4 in Section 2.5 to assign IP address and other network parameters to XNET. 2. Install XNET and connect it to xDSL or Cable modem as in Figure 3-2. IP Network (LAN/WAN)

  • Page 15: Ip-Installer

    There are two ways of connecting to XNET/XNET-Wireless administrative mode. One is through Internet Explorer (IE) and the other is through “XNET-NVR” or “XNET-XNVR” program. But this user’s guide will explain accessing by IE and “XNET-NVR” only. (Please refer to the XNVR user’s guide in the supplied CD for using “XNET-XNVR”.)
  • Page 16 IP address]:[HTTP port]/admin.htm Example: http://172.16.64.133:8080/admin.htm 5.1.2. Log on from “XNET-NVR” Select video channel in the viewing window of “XNET-NVR”. Selected video channel will be highlighted. Click button on the right side of the display screen. Figure 5-1. Log on to administrative mode from “XNET-NVR”...
  • Page 17 XNET Network Dome Camera User’s Guide Figure 5-2. Login screen The default setting for the User Name and Password are ‘root’ and ‘dw2001’, respectively. Click on “OK” button to enter into the Basic Setup page of Administrative Mode. If you have changed the username and password of the Administrator, you must log on with the changed username and password.

  • Page 18: Basic Setup

    Select a language of your choice. English, Korean, Chinese, Language Japanese, Spanish, Italian, Portuguese are available. Logical name of the XNET. It is same as the one set-up by IP- System Name installer. You can reassign the system name. Save a image file captured from the web viewer to the folder of Screen Capture your choice.
  • Page 19 XNET Network Dome Camera User’s Guide Select the type of input audio. Audio Input Select Line In for using Line-out from audio devices. Selection Select Mic for using microphone. Input Video This filed is set by the factory Select a video size for transmission- Video Size NTSC(30 fps Max.): 720x480, 352x240, 176x144...

  • Page 20: Network Configuration

    XNET Network Dome Camera User’s Guide 5.3. Network Configuration Setup the network parameters appropriately in accordance with your network environment. Many of the parameters in this page are same as those set up by “IP-Installer”. Figure 5-4. Network Configuration 20 of 44...
  • Page 21 Sub Field Field/Button Description /Button The network types supported by the XNET/XNET-Wireless are LAN(fixed IP), PPPoE, and DHCP(automatic IP allocation) When the network environment is fixed IP, select ‘LAN’ in the network type, and put the IP address, Subnet Mask, Static IP Gateway, DNS1 and DNS2.
  • Page 22 XNET Network Dome Camera User’s Guide address set by “Recv E-Mail Address”. Recv E-Mail Enter E-mail address to receive information sent from your Address network camera. This is same as E-mail field in IP-installer. Return E-Mail Fill in this field with correct e-mail address to identify the...

  • Page 23: User Admin & Time Setup

    XNET Network Dome Camera User’s Guide 5.4. User Admin & Time Setup You can change the ID and password of users and also assign different attributes for each user. Figure 5-5. User Admin. & Time Setup Sub Field Field/Button Description...
  • Page 24 P – ptz(Pan/Tilt), not used for this model. You can delete specific user by clicking the DELETE button. If you want to restrict viewing access to the XNET/XNET- Wireless, check at the box left to Yes and click on Save.
  • Page 25 Synchronize the time with the internet time server at the with an right. When the time server is out of the reach from Internet XNET/XNET-Wireless, you can assign time server by filling in Time Server Specific Time Server field. Synchronize Synchronize the time with the time of the PC.

  • Page 26: Sensor & Capture Setup

    Normal Open and Normal Close. Name Input logical name for the sensor. It sets the condition of video transmission via FTP or E-mail. The XNET/XNET-Wireless supports 2 types of conditions which are mutually independent. Video Capture Sensor Check to enable Sensor initiated capture.
  • Page 27 XNET Network Dome Camera User’s Guide Transmission Check to send captured video by e-mail. E-mail is sent to the Recv E-mail address. Refer to [Section 5.3.] By E-Mail Captured video data for E-mail consists of intra frames only in consideration of the limited storage space for E-mail account.

  • Page 28: Alarm Device Setup

    XNET Network Dome Camera User’s Guide 5.6. Alarm Device Setup Test the alarm output and describe the condition of alarm annunciation. Figure 5-8. Alarm Output Setup Sub Field Field/Button Description /Button Test alarm devices. Click on On/Off for testing. Small box with white background indicates the status of the Alarm Device relay by On/Off.

  • Page 29: Motion Region Setup

    XNET Network Dome Camera User’s Guide 5.7. Motion Region Setup Set the motion detection regions. Up to 3 regions can be defined. Figure 5-9. Motion Region Setup Sub Field Field/Button Description /Button Channel Not applicable. Selection Channel Set the sensitivity in motion detection for each channel. 1 is Sensitivity the most sensitive, and 10 is the least sensitive.
  • Page 30 XNET Network Dome Camera User’s Guide Set up to 3 the motion detection zone Enable each zone by checking the box at the left of each Region. To set the region: Click on START and click on a box overlaid on the video Region 1, 2, Click on END and click on a box overlaid on the video.

  • Page 31: Ptz Setup(This Is Not Related With Xnet Network Dome Camera)

    XNET Network Dome Camera User’s Guide 5.8. PTZ Setup (This is not related with XNET Network Dome Camera) Setup and test the PT(Pan/Tilt) devices. Figure 5-10. PTZ Setup Sub Field Field/Button Description /Button Channel Not applicable Selection Choose the PT model.
  • Page 32 XNET Network Dome Camera User’s Guide Note that zoom is not applicable for XNET You can check the various operation of the PT devices. “Left”/”Right”/”UP”/”DOWN” Operation ZIN(Zoom In), AUTOFOCUS, ZOUT(Zoom Out) Check functions does not applicable to this product You can set up the PTZ limitation & preset positions if the PT device supports it.

  • Page 33: Encryption Set Up

    XNET Network Dome Camera User’s Guide 5.9. Encryption Set up Figure 5-13. Encryption Setup For additional security to the video and audio data transmitted from the network camera, you can set key codes and use them for encrypting the data from the network camera.
  • Page 34 XNET Network Dome Camera User’s Guide You can use up to 20 different key codes for the encryption of the data To generate the key value click on “GENERATE” button. The GENERATE boxes for the Key values will be filled with new values.

  • Page 35: Upgrade & Reset

    XNET Network Dome Camera User’s Guide 5.10. Upgrade & Reset You can upgrade the XNET/XNET-Wireless via the IP network. Figure 5-14. Upgrade & Reset For each of the upgrade of the system component, upgrade code should be downloaded from cnbtec’s home page before the system upgrade is performed.
  • Page 36 XNET Network Dome Camera User’s Guide Refer to [6.4. How To Upgrade Your XNET/XNET- Wireless System]. Upgrade the bootloader installed in the network camera via the network. Bootloader needed for the upgrade can be Bootloader downloaded from cnbtec’s home page.

  • Page 37: Status Report

    XNET Network Dome Camera User’s Guide 5.11. Status Report It shows you system records since the system started. Figure 5-15. Status Report You can check the problems as well as the versions and event status of the whole system and each module.

  • Page 38: Tips For Using Xnet

    XNET Network Dome Camera User’s Guide 6. Tips for Using XNET 6.1. Sensor-IN and Relay-OUT Use the Sensor-In and Relay-Out Cable to connect various sensing and alerting devices. Examples of sensing devices are infrared sensors, motion sensors, heat/smoke sensors, magnetic contact sensors, etc. Use the *Relay-Out connector for connecting device such as loud speakers, flashing lights, or access control devices.
  • Page 39 XNET Network Dome Camera User’s Guide 6.1.2. ALARM-OUT A Relay output is provided for connecting alarm devices or for remote on/off devices such as light control. Relay circuits are normal open and circuits are closed upon alarm output or remote on.
  • Page 40 XNET Network Dome Camera User’s Guide 6.1.3. Connection of Sensor, Alarm Device 6.1.3.1 Connection of Sensor Photo Coupler NO/NCType Open CollectorType Sensor1+ Sensor Sensor Device Device Sensor1- +12V Sensor Sensor Power Power Supply Supply 6.1.3.2. Connection of Relay Alarm Relay Switch Power Supply...

  • Page 41: Trouble Shooting

    Then press Enter. If you see the “Reply from …” message it means that the network is working properly. To check if the XNET/XNET-Wireless is connected, open the MS-DOS Prompt and type the following. ping [the IP of the server] Example) ping 192.168.1.112 If you see the “Reply from...

  • Page 42: Web Viewer

    6.3. Web Viewer XNET/XNET-Wireless is designed to be connected through internet explorer, too. For connection to XNET/XNET-Wireless using internet explorer type in IP address or host address in the address input field of the internet explorer. Figure 6-4. Web Viewer of XNET/XNET-Wireless...
  • Page 43 XNET Network Dome Camera User’s Guide Control Panel of Web Viewer Enable bidirectional audio. When bidirectional audio is enabled, voice from your PC is delivered to XNET/XNET-Wireless. Capture and store the still image on your desk top screen. Connect to XNET/XNET-Wireless in administrative mode of XNET/XNET-Wireless.

  • Page 44: How To Upgrade The Xnet/Xnet-Wireless

    XNET Network Dome Camera User’s Guide 6.4. How to Upgrade the XNET/XNET-Wireless Unless otherwise instructed, the owners of the XNET/XNET-Wireless are recommended to upgrade the system when upgraded firmware is released using manual upgrade procedure. (The automatic upgrade mode will supported soon later.) Followings are the procedure to apply for the automatic upgrade Save the upgrade system software to your PC.
