Summary of Contents for Legend LSD2
-
Page 1: User Manual
USER MANUAL LSD2 – LEGEND STANDARD DEFINITION SET TOP BOX www.legenddigital.com www.legenddigital.com v1.2... -
Page 2: Table Of Contents
CONTENTS Safety Instruction Packing List Front Panel Rear Panel Remote Controller Installation Guide 7-11 Feature Specification... -
Page 3: Safety Instruction
SAFETY INSTRUCTIONS Please read the following instruction carefully: Do not overload power outlets, extension cords or integral convenience receptacles as this can result in a risk of fire or electrical shock Never allow liquids, spray or other materials to come into contact with the inside of the Set Top Box (STB). -
Page 4: Packing List
PACKING LIST ITEMS Qty. REMARK DIGITAL TERRESTRIAL RECEIVER INSTRUCTION MANUAL REMOTE CONTROL Batteries inc AV CABLE NOTE: Any changes will not be noticed in advance. Our company reserves the rights for the explanation of the discrepancy. -
Page 5: Front Panel
FRONT PANEL 10 9 1. Card slot (NOT USED FOR AUSTRALIA) 6. Standby switch 2. EXIT: return to the program-watching status 7. Volume decrease/ left button 3. MENU: Menu entry 8. Channel increase/ up button 4. OK: menu confirmation/ channel list 9. -
Page 6: Remote Controller
REMOTE CONTROLLER KEYS Advise you operate each function of the STB using the button on the remote controller. Please read this section to help advance your understanding of the function of the STB. : Standby control : mute the audio output 3. -
Page 7: Installation Guide
LSD2 – LEGEND STANDARD DEFINITION SET TOP BOX This document will guide you step by step on how to connect and set up your LSD2 set top box. Users with experience in entertainment systems setup may not require this document as it is intended for those with little or no prior knowledge on these units. - Page 8 4) You now must connect your aerial. You may have an inside aerial (rabbit ear type) or a roof antenna with a wall plug. Using an appropriate cable, connect the aerial to the RF IN connection on the rear of the unit (top middle) as below: 5) Now you must connect the AV cables (the red, white, and yellow cables that came with your unit) to the rear of the unit.
- Page 9 Diagram above shows all connections in place for LSD2. Read on for further instruction. 6) The other end of the AV cables will need to then be connected, in the same way, to the AV-INPUT connectors on either your VCR or your TV. In order to record from your digital box to videocassette, you will need to connect the unit direct to the VCR (set VCR to appropriate AV channel as indicated on the connection you use, eg AV1, AV2…) and...
- Page 10 8) Now you must SCAN in your channels. Make sure the batteries (supplied) are installed in your REMOTE CONTROL unit. Point the remote at the digital box and press MENU. Then use the up and down buttons on the remote to highlight SCAN at the bottom of the menu, and press OK.
- Page 11 Your local TV service technician can assist with these. 11) If everything has been done right, you have been TURNED ON with Legend Digital! You may now enjoy the benefits of Digital Television, and can refer to your user manual for...
-
Page 12: Epg
EPG – Electronic Program Guide To show information on programs currently playing press the EPG button. Press the red key to show information on the current program and the green key to show what program is on next. Press the yellow key to read the particulars. Press the blue key to show the weekly information. -
Page 13: Specification
SPECIFICATION Tuner Input Frequency UHF 470 MHz ~ 862 MHz VHF 174 MHz ~230 MHz RF Input Level -78dBm ~ -20dBm (75W) RF Input connector IEC type Female RF Output connector IEC type Male Nominal input impedance 75 ohm Channel selection system Electronic tuning, PLL synthesizer Step frequency 166.67KHz...
