Summary of Contents for Technisonic Industries Limited TAC-2OOA
- Page 1 DUAL AUDIO CONTROLLER MODEL TAC-2OOA Installation and Operating Instructions Til Document No. 96REl97 Rev. D June 1997 250 Watline Avenue, Mississauga. Ontario L4Z 1 P4 Tel:(905)890-2113 Fax:(905)890-5338 656 North French Road, Suite 2, Amherst, New York 14228 Tel:(716)691-0669...
- Page 2 CAUTION This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed circuit boards. WARRANTY INFORMATION The Model TAC-200A Audio Controller is under warranty for one year from date of purchase. Failed units caused by defective parts, or workmanship should be returned to: Technisonic Industries Limited...
- Page 3 REVISIONS for DOCUMENT?? 9( DATE PAGE DESCRIPTION APPROVED 17/03/97 2 - 3 FIGURE 2-2 Corrected pin ID’s. on 15 pin “D”. 2 - 6 17/04/97 FIGURE 2-5 Moved signal flow direction arrows from pins 9 to 1 and 11 to 3. 2 - 3 11/06/97 FIGURE 2-2 changed pinout...
-
Page 4: Table Of Contents
TABLE OF CONTENTS P a g e Title P a r a g r a p h GENERAL DESCRIPTION SECTION 1 ..........l - l Introduction Description . - Page 5 LIST OF TABLES Table No. Title ........l - 3 l - l Operational Limitations Specifications .
-
Page 6: Introduction
1 . 1 This publication provides operating and installation information on the Model TAC-200A, Dual Audio Controller manufactured by Technisonic Industries Limited. This unit is designed to provide high performance operation for installations requiring two completely independent audio controllers in a single panel mounted box. The pinout configuration... -
Page 7: General
FIGURE l-l TAC-2OOA DUAL AUDIO CONTROLLER - GENERAL VIEW l - 2... -
Page 8: Operational Limitations
T E C H N I C A L S U M M A R Y A summary of the relevant electrical, operational, mechanical and physical characteristics of Table 1-2, the control panel are given in General Specifications. OPERATIONAL LIMITATIONS These specifications are the minimum and maximum operating characteristics, within which Table l-l the TAC-200A should operate reliably. - Page 9 TABLE 1-2 GENERAL SPECIFICATIONS TAC-200A MODEL Dual Audio Controller PHYSICAL CHARACTERISTICS: ........... 5.76 inches Width Height .
-
Page 10: Wiring Requirements
SECTION 2 INSTALLATION INSTRUCTIONS GENERAL This section contains information and instructions for the correct installation of the TAC- Make certain that the unit is correctly operating in accordance with the equipment user’s requirements prior to releasing the equipment for service. 2 . -
Page 11: Outline Drawing
0 0 2 6 FIGURE 2-1 Outline Drawing for Model TAC-200A Audio Controller 2 . 5 INSTALLATION - KIT CONTENTS The installation kit P/No. 969732, consists of: One 50 pin Cannon D mating connector (female) complete with crimp pins and hood. One 37 pin Cannon D mating connector (female) complete with crimp pins and hood. -
Page 12: Main Power
G R O U N D MAIN GND K E Y I N G L I N E FIGURE 2-2 Pinout Diagram for 50 pin, 37 pin, and 15 pin “D” connectors CONNECTIONS The Pilot, Co-pilot and rear microphones require a PTT (Push To Talk) button or switch to key the transceivers as required. -
Page 18: Backlighting
2 . 1 2 ICS TIE AND ICS KEYING The ICS Bus is a bidirectional audio line allowing connection of multiple intercom systems and panels in one installation. This can be achieved simply by connecting together all of the ICS Bus signals of all the devices. -
Page 19: Storage
BOARD GROUND ISOLATION, S W I T C H BOARD SWITCH BOARD GROUND ISOLATION, J U M P E R - 34 I N T E R N A L V I E W - S’rVITCH B O A R D B O A R D R E M O V E D ) (LID... - Page 20 SECTION 3 OPERATING INSTRUCTIONS FRONT PANEL OPERATORS SWITCHES AND CONTROLS This section deals with the explanation and description of all the controls of the TAC-200A Audio Controller. All Pilot and Co-pilot Controls are on the front Panel of the unit and are variable or selectable.
- Page 21 3.1.3 CO-PILOT TX INDICATOR This LED indicator indicates that the audio received from the Co-pilot Microphone and the transmit signal (PTT), after keying the PTT button, is being routed to the Transceiver selected (3.1.6). via the Transceiver SELECTOR 3 . 1 . 4 C O - P I L O T I N T E R C O M V O L U M E C O N T R O L This knob controls the Co-pilot’s intercom volume level.
- Page 22 3.1.8 PILOT RX MONITOR These four switches indicated COM1, COM2, FM1 and FM2 allow the Pilot to monitor the Receivers - independant of the setting of the Transceiver SELECTOR (3.1 2). Any number or combination may be used at the same time. 3.1.9 PILOT TX INDICATOR This LED indicator indicates that the audio received from the Pilot Microphone and the transmit signal (PTT), after keying the PTT button, is being routed to the Transceiver selected via the...
-
Page 23: Tac-200A Configuration Controls
AMPLITUDE INPUT 3.2.6 SIGNAL AMPLITUDE 1 3 . 2 . 7 C O - P I L O T AMPLITUDE SOURCE SELECTOR 3.2.3 PILOT 3 . 2 . 4 C O - P I L O T RX SOURCE 3 2.7 PASSENGER 3.2.1 DIRECT AUDIO... - Page 24 CO-PILOT RX SOURCE 3.2.4 These DIP-switches select all or any combination of the available Receiver audio sources connected to the TAC-200A and when selected, these input signals can be monitored with other transceivers selected by the Co-pilot Transceiver Selector (3.1.6). This audio is adjusted via the Co-pilot RX volume control (3.1.5).
