- Page 1 USER’S MANUAL HD H.264 MPEG4 DTR5102N www.digitalworld.ro --- Suport tehnic: Tel. 021-410.01.37...
-
Page 2: Table Of Contents
INDEX 1. Main Features ……………………………..……………………………………..5 R em ot e C o n t r ol l er … … … … … … … … … … … … … … … … … … … … . . . 6 3. - Page 3 5.1.6 ZOOM………………………………………..........15 5.1.7 O PT IO N … … … … … … … … … … … … … … … … … … … … . . … … . . . 1 5 5.1.7.1 TV Setup ……………………………………………..……....15 5.1.7.2 Password ………………………………………………..…….....15 5.1.7.3 PVR …………………………………………………..……....15 5.1.8 Advance Timer ……………………………..........16...
- Page 4 SAFETY PRECAUTION CAUTION: The lightning flash with Warning: The exclamation point within arrowhead symbol, within an To reduce the risk of electric an equilateral triangle is equilateral triangle, is shock, don't open the cabinet. intended to alert the user to intended to alert the user to Refer servicing to qualified important operating and...
- Page 5 Object and Liquid Entry: Never put objects of any kind into this STB through openings, as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill any liquid on the STB. Note: Moisture may be formed on the lens In the following conditions: Ø...
-
Page 6: Main Features
This manual contains important safe measurements and correct operational information, so please read all the information carefully before use in order to avoid any damage, Main Features It’s a set top box with multimedia player, with the features of volume delicate and easy to use. It’s a good helper for your entertainment. -
Page 7: Welcome Page
button function button function POWER turn on/off the device BLUE display information MUTE mute on/off PLAY press to play the file NUMBER 0-9 channel number PAUSE press to pause the file MENU enter the main menu INFO display information recording favorite files Press to stop recording AUDIO... -
Page 8: Setup & More
(1) Press [CH+/CH-] key to move highlight. (2) Press [VOL+/VOL-] key to select the item (3) Move highlight to [Channel Search] and press [OK] key to begin the auto scan. (4) Press [Exit] key to exit menu. 4. SETUP & MORE When pressing the [Menu] key to enter the main menu, which shows as below: 4.1 Setup... -
Page 9: Tv Setup
(4) Press [VOL-/VOL+] to select “OSD Style” (5)Press [VOL-/VOL+] to select whether the GMT is “ON” or ”OFF” (6)Press [VOL-/VOL+] to select “Time Zone” (7)Press [Exit] to save current setting 4.1.3 TV Setup (1) Press [VOL-/VOL+] until switching to “TV Setup”. Then press [OK] or [ CH-] to enter (2) Press [CH-/CH+] to select sub-menu of “... -
Page 10: Sw Update
4.1.5 SW Update (1) Press [VOL-/VOL+] until switching to “SW Update”. Then press [OK] or [CH-] to enter (2) Press [CH-/CH+] to select sub-menu of “SW Update” 4.1.5.1 Card Reader/USB Upgrade (1)Press [OK] to enter Card Reader/USB Upgrade menu. (2)Press [CH-/CH+] to browser file directories. (3)Press [VOL-/VOL+] to focus on the upgrade file list. -
Page 11: Calendar
(2) Press [VOL-/VOL+] until switching to “More”. (3) Press [OK] to enter “More” menu. 4.2.1 Calendar “Calendar”: user may see current year, month and day. (1)Press [VOL-/VOL+] to focus on “Calendar” item. (2)Press [OK] to enter the “Calendar” menu. (3)Press [VOL-/VOL+] to change year. (4)Press[CH-/CH+] to change month. -
Page 12: Broadcasting
(4) Press [VOL-/VOL+/CH-/CH+] to select target position. (5) Press [OK] to place chess. 5. BROADCASTING In “Broadcasting” menu, one may select the service type to watch in service mode, including TV, Radio and Recorder. (1) Press [Menu] to enter “Main Menu”. (2) Press [CH-/CH+] until switching to “Broadcasting”... -
Page 13: Favorites
such as “No Signal” 5.1.2.3 Favorites “Favorite”: User may group the channels into eight pre-defined favorites groups, including “Music”, “Sports”, “Shopping”, “Traffic”, “Movie”, “News”, “Fav1” and “Fav2”. (1) Press [Navi] to enable the “List” Navi bar. (2) Press [VOL-/VOL+] to select “Favorite” item. (3)Press [ CH-/CH+]to select the channel to FAV. -
Page 14: Sort
(5) Press[OK] to confirm the target channel position. (6) Press[OK] to confirm save and [Exit]to cancel save 5.1.2.7 Sort User may sort the channels in this Navi bar. The channels are sorted by name (A-Z), Pay-Free or TP. (1) Press [VOL-/VOL+] to select “Sort” item. (2) Press [OK] to display sort types. -
Page 15: Subtitle
5.1.3 Subtitle (1) Press [Navi] to enable the “subtitle” Navi bar. (2) Press [VOL-/VOL+] to select “subtitle” item. Then Press [OK] to enter subtitle display, or press “SUB-T”key 5.1.4 Teletext (1) Press [Navi] to enable the “Teletext” Navi bar. (2) Press [VOL-/VOL+] to select “Teletext” item. (3) Press [OK] to enter Teletext display, or press “TTX”key 5.1.5 Audio language... -
Page 16: Pvr
5.1.7.3 PVR (1) Press [Navi] to enable Navi bar. (2) Press [CH-/CH+] to select “Option” bar item. (3) Press [OK] to enter “Option” page. (4) Press [VOL-/VOL+] to focus on “PVR”. (5) Press [OK] to enter “PVR” page A: Timeshift For step (1) ~ (5), please see chapter 5.1.7.3 (6) Press [CH-/CH+] to focus on “Timeshift”... -
Page 17: Edit Event
(5) Press [CH-/CH+] to focus on “Channel No” bar. (6) Press [VOL-/VOL+] or [0~9] to input booking channel number. (7)Press [CH-/CH+] to focus on “Start Date” bar. (8) Press [0~9] to input booking start date (year/month/day). (9) Press [CH-/CH+] to focus on “Start Time” bar. (10) Press [0~9] to input booking start time (hour/min, in 24 hour format). -
Page 18: Timeshift
stop current recording and “No” would exit the message box and continue to record 5.1.9.2 Timeshift To use timeshift function, “Timeshift” should be turned on at first. See chapter5.1.7.1 for details. (1)Timeshift is implemented by recording channel (2)data in timeshift data buffer on storage device. (3)The function is enabled only if there is storage device plugged-in STB, with a minimum 512Mbytes free disk size. -
Page 19: Play Records
editing and save the new name (3)In “Vol” item, current volume can be read/set through a displayed volume bar. Pressing [Exit] would exit the current Navi bar item. (4)Selecting “Del” Navi bar item, system would ask whether to delete the selected files. Press [OK] to confirm and [Exit] to cancel. -
Page 20: Multimedia
6. Multimedia 6.1Music Focusing on “Main Menu” -> “MULTIMEDIA” -> “Music”, press [OK] to enter “Music Thumbnail’s file manager mode” page. Press[Exit]，enter music thumbnail. If the focused item is playable folder or file，press[Yellow] start play music. Press [Menu] to exit the Music Thumbnail” page and return to “Main Menu”... -
Page 21: Movie Play
folder or file，press[Yellow],start play movie 6.2.1For details of Top option, please check 6.1.1 carefully 6.2.2 For details of Navi Nar, please check 6.1.2 carefully 6.2.3 MOVIE Play “Movie Play” screen can be entered by pressing [Yellow] key in “Movie Thumbnail” or choose “Exit & play” in “Top Option” Press [Red] to play backward in trick mode. -
Page 22: Packing List
Press<Navi> to display/hide the Navi bar. 7. Packing list PART QUANTITY Set top Box Adapter Remote Control CD User Manual 8. Troubleshooting If you encounter problems when using this unit, check the following points before requesting service. Problem Solution Please: Confirm that you have an appropriate power source Check if all connections between wall outlet and power No Power... - Page 23 indicated. Check if the TV is switched on. No Picture Select the appropriate video input on your TV Adjust the volume. No sound or distorted Check the audio cables are connected correctly. sound Select the audio output that is supported by your TV. WARNING Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.
