Page 1: User Manual
RG-P47IC10-KE7A USER MANUAL —RGBW 4IN1 10W7Leds Indoor Par Can Guangzhou Geliang Lighting Technology Co.,Ltd Tel:+8620-86872001/2/3 www.rigelighting.com... -
Page 2: Table Of Contents
CONTENS GENERAL INFORMATION 2. PACKING LIST 3. SCHEMATIC DIAGRAM 4. PRODUCT FEATURES 5. TECHNICAL SPECIFICATIONS 6. MOUNTING AND INSTALLATION 7. UNDERSTANDING DMX 8. CONTROL BOARD 9. DMX CHANNEL TRAITS 10. MAINTENANCE AND CLEANING 11. 1-YEAR LIMITED WARRANTY... -
Page 3: General Information
RGBW 4IN1 10W7Leds Indoor Par Can 1. GENERAL INFORMATION INTRODUCTION: Congratulations, you have just purchased one of the most innovative and reliable lighting fixtures on the market today! The Par Can has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit. -
Page 4: Packing List
RGBW 4IN1 10W7Leds Indoor Par Can 2. PACKING LIST RGBW 4IN1 10W7Leds Indoor Par Can 1 pcs User Manual 1 pcs Power cable 1 pcs 3-XLR signal cable 1 pcs 3. SCHEMATIC DIAGRAM 4. PRODUCT FEATURES Unlimited programming effects Professional color mixing Soft light effect High power Led 10W /pcs RGBW 4IN1 32-bit color (16.7 million color combinations) -
Page 5: Technical Specifications
RGBW 4IN1 10W7Leds Indoor Par Can 5. TECHNICAL SPECIFICATIONS Main Color Black Main Material Dia cast aluminum body:Dia cast aluminum , glass plane , Plastic knobs Control Mode Automatic run mode, DMX-512 mode, Sound active mode DMX Channels 9 DMX Channels Gray Level 256 level LEDs... -
Page 6: Understanding Dmx
RGBW 4IN1 10W7Leds Indoor Par Can kept at least 0.5m away from any flammable materials (decoration etc.). Always use and install the supplied safety cable as a safety measure to prevent accidental damage and/or injury in the event the clamp fails. Mounting points Overhead mounting requires extensive experience, including amongst others calculating working load limits, a fine knowledge of the installation material being used, and periodic... - Page 7 RGBW 4IN1 10W7Leds Indoor Par Can DMX-512 control connection Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the fixture. You can chain multiple fixture together through serial linking.
-
Page 8: Control Board
RGBW 4IN1 10W7Leds Indoor Par Can 8. CONTROL BOARD 8.1 ADDR This function is used to set or adjust the fixture’s starting DMX address. Every device controlled by DMX has to have a unique starting address. The addressing feature is what allows DMX to function properly. -
Page 9: Dmx Channel Traits
RGBW 4IN1 10W7Leds Indoor Par Can 8.2 Automatic Mode This function including FLAS,FADE,ACS- ,three modes,which allows the internal programs to run in either stand-alone or master-salve mode. 8.3 Sound Control Mode This function allows you to control the fixture via the sound with two different effect. 8.4 Synchronization mode (Master-slave mode) In “Master”... -
Page 10: Year Limited Warranty
RGBW 4IN1 10W7Leds Indoor Par Can cleaning to the fixture Clean the inside and outside lens each week to avoid the weakness of the lights due to accumulation of dust. A detailed electric check by approved electrical engineer each three months, make sure that the circuit contacts are in good condition, prevent the poor contact of circuit from overheating. - Page 11 RGBW 4IN1 10W7Leds Indoor Par Can consequential, arising out of the use of, or inability to use, this product. ● G. This warranty is the only written warranty applicable to our products and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
