- Page 1 DPB-10000P 10” LCD TV AND DVD PLAYER ACCESSORIES: 1 x AC to DC Adaptor 1 x Remote Control with battery 1 x Instruction Manual 1 x Audio/Video Adaptor 1 x Cigarette Lighter Adaptor...
-
Page 2: Table Of Contents
Contents A. INTRODUCTION B. CAUTIONS AND WARNINGS C. POWERING AND INSTALLATION D. UNIT VIEW E. REMOTE CONTROL VIEW F. Menu G. SETUP H. Display I. Playing Audio CDs J. Playing MP3 Discs K. Playing JPG file L. SPECIFICATIONS M. TROUBLE SHOOTING DVD MODE N.TROUBLE SHOOTING TV MODE... -
Page 3: Introduction
A. INTRODUCTION Thank you for choosing the 10” LCD TV and DVD player. Please read the entire instruction manual supplied with this product prior to using. The documentation will assist you in installing the system properly to obtain the best equipment performance. Please save this manual for later use. B. - Page 4 Disassemble Do not attempt to disassemble the cabinet. There is a risk of electric shock and/or exposure to Laser Radiation. Contact qualified service personnel if your system needs repair. Cleaning Unit When cleaning, make sure the system is unplugged from the power source.
- Page 5 CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage”...
-
Page 6: Powering And Installation
C. POWERING AND INSTALLATION 1. Powering the system indoors Plug one end of the AC to DC Adaptor into the DC jack on the side of the LCD TV and DVD player, then plug the other end into the 110~240V AC power outlet. - Page 7 2. TOP OF LCD TV AND DVD PLAYER 1) Power Button: Turns on or off the unit. 2) Program Buttons: Press to scan the program channels automatically. (You can press it with tiny and sharp object. The tiny design is to prevent you from pressing it carelessly.) 3) PR- Button: To select the previous channel.
- Page 8 3. LEFT OF LCD TV AND DVD PLAYER 1) TV Jack: Insert an antenna into the jack. 2) E-Port: Connect with Game Pad. 3) SD/MMC/MS Slot: Insert an SD/MMC/MS Card into the slot. 4) USB Jack: Insert a USB Flash Driver into the jack. 5) AV Input Jack: Insert the A/V cable to extra device.
-
Page 9: Remote Control View
E. REMOTE CONTROL VIEW 1) DVD/TV/AUX: selects either DVD, TV, AV or E-Port mode. 2) Power: Press to power on or off. 3) Display: Press to display disc information. 4) Audio: Selects one of the audio soundtracks. 5) Subtitle: Selects one of the subtitle languages programmed on a DVD. -
Page 10: Menu
menu screen. 22) Stop: Stops playback. 23) Volume+: Turns up the volume. Selects next channel 24) PR+: Selects previous channel. 25) PR-: 26) System: Select different TV system modes. F. Menu DVD Mode: A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. -
Page 11: Setup
BAND: Displays the frequency band (VHF-L/VHF-H/UHF) of the current channels. G. SETUP 1. General Setup Page 1) In DVD mode with no disc inside the player, press ‘SETUP’ to display the main screen of the Setup Menu on the screen and “General Setup Page” appears. - Page 12 NOTE: Not all discs contain above features. The above features are disc dependent. c). OSD Language Please To select any language which you desire as the OSD (on screen display) Language. d). Screen Saver *On: Enables screen saver *NOTE: The DVD player will enter the Screen Saver mode after approximately five minutes if the same image remains on the screen.*Off: Disables screen saver (off) e).
- Page 13 3) Press the UP or DOWN button to select the other menus in the preference page. 4) Press RIGHT to enter the sub menu. 5) Press the UP or DOWN button to select the sub menu and press the ENTER to confirm your selection. 6) Repeat steps 3-5 for other menus.
-
Page 14: Display
NOTE: The level of 8 Adult is the factory default. e) Default Select ‘Default’ by pressing the UP or DOWN button in the preference page. And press RIGHT to enter the sub menu. Press ENTER to make the setting returns to the factory-set mode. NOTE: The parental setting is not affected by the default reset function. - Page 15 Title Remain: The remaining time of the title Chapter Elapsed: The elapsed time of the chapter Chapter Remain: The remaining time of the chapter Display Off: The DVD’s time Information will not be displayed. 2. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed.
-
Page 16: Playing Audio Cds
4. REPEAT a. During playback press ‘1/All Repeat’ constantly to see the repeat mode. Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Repeat Off: Resume normal playback The ‘Chapter’ repeat display is shown below for example: I. -
Page 17: Playing Mp3 Discs
has been playing. 4) Total Remain: The current track playing and the amount of time remaining on the CD. 5) Display Off: The CD time Information will not be displayed. J. Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. -
Page 18: Specifications
hand icon will appear on the display meaning that these options are not available. L.SPECIFICATIONS Compatible DISC: DVD/CD/MP3/JPEG Signal system: Panel size: 10 inch Audio S/N: Better than 60 dB Dynamic range: Better than 85 dB Power source: DC 12V Operating temperature: 5~35°C Weight :... -
Page 19: N.trouble Shooting Tv Mode
1. The disc might be damaged. Try another disc. 2. It is normal for some distortion to appear during forward or reverse scan. No forward or reverse scan? 1. Some discs have sections that prohibit rapid scanning or title and chapter skip. 2. - Page 20 There is no sound when enjoying the program? 1. Turns up the volume. 2. Check the mode of MUTE is Off. 3. Confirm the system of TV (PAL-I,PAL-BG or PAL-DK) Picture is snowy The aerial is inadequate use an outdoor antenna to improve reception. Picture is ghosting Orientate this aerial to improve the picture.
- Page 21 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
