Parts checklist
Your telephone package includes the items shown below.
User's Guide
Model: EX30014
CALL WAI T I N G
LOW
Telephone base
with mounting
bracket attached
SPEAKERPHONE WITH CALL WAITING/CALLER ID
Telephone
line cord
Telephone Jack Requirements
To use this phone, you need an RJ11C type modular telephone
jack installed on your line. If you do not have
a modular jack, call your telephone service
provider to find out how to have one installed.
If you have DSL high speed Internet service,
a DSL filter is required (not included). Contact
your DSL service provider for more information
about DSL filters.
Installing or replacing batteries
IMPORTANT: The caller ID records and memory location records will
be lost approximately 90 seconds after the batteries are removed
from the telephone. Please read the instructions before replacing
visit our website
the batteries and have the batteries ready for replacement.
www.thehomephones.com
Your telephone uses 4 AA-size alkaline batteries for receiving
and storing caller ID records and for storing the numbers you
use for memory dialing, pulse dialing, and redial.
1. Turn the telephone base over, and detach the mounting
bracket by pressing on the top of the bracket.
2. Press on the tab to open the battery compartment cover
on the back of the base. Insert 4 AA alkaline batteries (not
included) into the compartment matching the engraving in
the battery compartment as shown.
3. Replace the mounting bracket to the telephone base with
the engraved texts "THIS END UP FOR DESK USE" correctly
oriented.
CAUTION: If the telephone will not be used for an extended period of
time, remove the batteries from the base to prevent possible leakage.
Model EX30014 is a trademark of
The General Electric Company,
P/N: 905-30014204-00
EX.E Version 1.0 06/2011 and is under license by
Printed in China CCT Tech Global Limited,
Central, Hong Kong
© 2011 CCT Tech Global Limited
+
-
-
+
+
-
-
+
Handset
Handset
coiled cord
User's Guide
Installing on a desk or table
Model: EX30014
1. Choose an area near a telephone modular jack (RJ11C), and
place your telephone on a level surface, such as a desktop or
tabletop (for wall mounting, see instructions on page 5).
SPEAKERPHONE WITH CALL WAITING/CALLER ID
2. Make sure the rotating handset tab is rotated to the DESK
position as shown in figure 1 below. You can use a coin or a
small flat tool if needed.
User's guide
3. Plug one end of the handset coiled cord into the jack on the
bottom of the handset (near the mouthpiece) and the other
end into the handset jack (on the left side of the base), then
place the handset onto the base cradle.
1 3
4. Plug one end of the telephone line cord into the LINE jack at
the top of the base and the other end into a modular jack as
shown in figure 2 below. Please Note: If you have DSL high
Wall plate
speed Internet service, a DSL filter is required (not included).
Contact your DSL service provider for more information
Modular
about DSL filters.
telephone
jack The unit is properly installed if you pick up the handset and
hear a dial tone. If you do not hear a dial tone, re-check all
installation steps.
CALL WAI T I N G LOW
Figure 1
Figure 2
2 4
Installing on a wall
1. Turn the rotating handset tab to the WALL position as shown
in figure 3 below. You can use a coin or a small flat tool if
needed.
2. Detach the mounting bracket by pressing on the top of the
bracket. Turn the mounting bracket until the text "THIS END
UP FOR WALL USE" is correctly oriented, and then replace
the bracket onto the base as shown in figure 4.
3. Plug one end of the handset coiled cord into the bottom of
the handset (near the mouthpiece) and the other end of the
cord into the handset jack (on the left side of the base), then
place the handset onto the base cradle.
4. Plug one end of the telephone line cord into the telephone
jack at the top of the base and the other end into the
modular telephone jack as shown in figure 4 below. Please
Note: If you have DSL high speed Internet service, a DSL filter
is required (not included). Contact your DSL service provider
vol + vol -
for more information about DSL filters.
Press to increase Press to decrease
5. Slip the mounting holes (on the bottom of the base) over the the volume during the volume during
a call. a call.
wall plate posts on the modular jack and slide the unit down
firmly into place.
The unit is properly installed if you pick up the handset and
hear a dial tone. If you do not hear a dial tone, re-check all
installation steps.
CALL WAITING
LOW
THIS END UP FOR
Figure 4 WALL USE
Figure 3
5
Telephone base layout Telephone operation
Rotating handset tab
Placing a call
Rotate to switch between
Handset
desk/wall installation.
1. Lift the handset and listen for a dial tone.
2. Dial the number.
3. Return the handset to the base to end the call.
CALL WAI T I N G
LOW One-touch
memory
locations
Speakerphone
Press to dial
The speakerphone works similarly to a two-way radio (also
programmed
one-touch
called FRS or "Walkie-Talkies") in that you can only listen or talk
memory
at one time. Stay within 2 to 3 feet of the phone so that you can
numbers.
be clearly heard by the caller.
ringer switch
Switch to adjust The speaker indicator lights when the speakerphone is in use.
the ringer
You can adjust the speaker volume by adjusting the vol +/-
volume level.
buttons while the speakerphone is in use.
mute
Press to mute For best speakerphone performance, avoid the following:
a call, press
• Areas with high background noise (the microphone might
again to resume
pick up these sounds and prevent the speakerphone from
conversation.
speaker going into the receiving mode when you finish talking).
Press to switch • Surfaces affected by vibration.
between
• Recessed areas such as in a corner, under a cupboard, or
speakerphone
and normal next to a cabinet, which can generate an echo effect.
redial/pause flash/exit dial
handset use.
1. Press speaker on the base and listen for a dial tone.
• Press to redial • During a call, press • Press to call
to answer a second
the last dialed numbers in the 2. Dial the number.
incoming call if you
number. caller ID records.
receive a call waiting 3. Press speaker again to end the call.
• Press to add a • Press to call
alert (if you have
dialing pause numbers in
subscribed to the
when dialing or the memory
Answering a call
call waiting feature
entering numbers locations.
from your telephone
into memory. Handset
service provider.
1. Lift the handset when the telephone rings.
• During programming,
press to cancel and
2. Return the handset to the base to end the call.
return to idle mode.
6
Speakerphone
1. Press speaker to answer a call when the telephone rings.
CALL WAI T I N G
LOW
2. Press speaker again to hang up.
You may switch between speakerphone and normal handset
use anytime during a call.
Speakerphone to Handset - Lift the handset to disable
speakerphone. The speakerphone indicator turns off.
store
Handset to Speakerphone - Press speaker, and then return the
Press to program
number into memory
handset to the base. The speakerphone indicator turns on and
locations.
the handset is disabled.
rev or
• Press to review caller
Volume
ID records.
• Press to switch
You can adjust the volume of both the handset and the
between options
during programming. speakerphone.
menu While using the handset or speakerphone, press vol
• Press to enter the +/- to adjust the handset volume from level 1 to 4 or the
telephone setting
speakerphone volume from level 1 to 8. A tone emits when the
menu.
del
• Press to save a
volume is adjusted to the maximum or minimum level.
Press to delete the
setting and move to
last number or
the next setting.
letter entered.
Temporary Tone Dialing
This feature allows you to switch to touch-tone dialing
temporarily when you are using pulse dialing service.
*
Press to switch to tone dialing during a call. The telephone
returns to pulse dialing after you hang up.
Flash
Press flash/exit during a call to access customer calling
services such as call waiting or call transfer, which are provided
by your telephone service provider.
7 9
Redial
Redial the last number you called by pressing redial/pause
after you hear a dial tone.
NOTE: The redial memory stores the last number you dialed (maximum
of 32 digits). All numbers, including numbers dialed to access voice-
menu system, are recorded in the memory.
Mute
Press mute to mute the microphone during a call. You will hear
the calling party but they will not hear you. Press mute again to
resume conversation.
8 10
Telephone settings
NOTE: When you finish a setting, press menu to save and move to the next
setting, or press flash/exit to return to idle mode.
Viewing the Set Up menu
You can view the Set Up menu structure as follows:
1. Place the handset in the cradle of the telephone base.
2. Press menu. The screen displays DATE/TIME.
3. Press rev or to scroll the menu structure and view
the submenus (DATE/TIME, LANGUAGE, CONTRAST, LOCAL
AREA CODE, LONG DIST CODE, LOCK, CHANGE PIN ?, T/P
DIAL MODE, and FLASH TIME).
NOTE: You may press the del key anytime to exit the Set Up menu. If no keys are
pressed within 10 seconds, the phone automatically exists the Set Up menu and
returns to the NO CALLS summary screen.
Setting date/time
You can set the date (month and day) and time (hour and
minute) of the telephone unit.
1. Press menu. The screen displays DATE/TIME.
2. Press menu again to show the current hour setting.
3. Press rev or to select the desired digits for hour setting:
• 0 to 23 for 24-hour format
• 1 to 12 for 12-hour format
4. Press menu to confirm your setting and move to the minute
setting.
5. Press rev or to select the desired digits for minute
setting (00 to 59).
6. Press menu to confirm your setting and move to the month
11
setting.
7. Press rev or to select the desired digits for month
setting (1 to 12).
8. Press menu to confirm your setting and move to the day
setting.
9. Press rev or to select the desired digits for day setting
(01 to 31).
10. Press menu to confirm your setting and move to the Time
Format.
11. Press rev or to select the desired time format setting
(12H or 24H).
12. Press menu to confirm your setting.
The date and time will be updated, every time a FSK Caller ID
message has been received.
If a DTMF Caller ID has been received, then it will get the date
and time from the system clock of the phone.
NOTE: The phone returns to idle mode if no key has been pressed for 10
seconds or if the delete key is pressed before the completion of the current
operation. The phone will time out and return to idle mode without changing the
current time.
Setting the language
You can select ENGLISH, RUSSIAN, ROMANIAN, BULGARIAN,
TURKISH, POLISH, GREEK, SPANISH or FRENCH as the display
language. The default setting is ENGLISH.
1. Place the handset in the cradle of the telephone base.
2. Press menu. The screen displays DATE/TIME.
3. Press rev or until LANGUAGE appears.
