CONNECTIONS

A B C D
Connecting a DVD Player/Recorder, Video Recorder or
Cable/Satellite Box
TVs Input/Source should be set to SCART
DVD or VCR
TV Aerial
Wall Socket
14
Emotion Manual No.5.indd Sec1:14 Emotion Manual No.5.indd Sec1:14
E G
H
F
SCART
RF RF
OUT
IN OUT
Helpline No UK. 0871 2000 463 ROI. 01443 3940
Web Support: www.skymediauk.co.uk
A
USB
B
HDMI 1
C
HDMI 2
D
VGA(PC)
E
VGA(PC) Audio In
F
S-VIDEO
G
COMPONENT (HD)
H
VIDEO
I
R/L (COMPONENT)
J
R/L (VIDEO)
K
SCART 1
L
CI CARD IN
M
SCART 2
N
RF IN
O
COAX Audio Out
I
L
J
K
RF IN
SCART
Connections
USB port
HDMI input
HDMI input
VGA-PC input
3.5mm PC audio input
S-Video input
Component input (YPbPr)
Video input
Component audio input
S-Video/Video audio input
SCART input
Common Interface Card Input
SCART input
RF / TV Aerial Input
Digital Coax output (all sources)
