- Page 1 EASYA ® User manual / Manuel d'utilisation English page 16 Français page 28...
-
Page 2: Important Safety Instructions
rEAd firSt ! importAnt SAfEtY inStructionS ! The lightning flash with arrowhead Caution : to prenvent yhe risk of electric The exclamation point within an equilat- symbol within an equilateral triangle, is shock, do not remove cover (or back). No eral triangle is intended to alert the user intended to alert the user to the presence user-serviceable parts inside. - Page 3 ® Profiled vent: powerful, distortion-free bass. High-efficiency acoustic wadding: excellent internal damping, sustained, deeper bass. Decoupling spikes included. Due to constant technological advances, Focal reserves its right to modify specifications without notice. Images may not conform exactly to specific product..
- Page 4 EASYA U s e r m a n u a l Setting up the system Connect the speakers to the mains using the cables supplied for your region (EU or U.S.). Press the "ON" switch on the speakers to turn them "ON".
- Page 5 EASYA U s e r m a n u a l hub connections There are several ways to connect your audio and video devices to the Hub: Analogue inputs: The Hub has 2 analogue inputs (3.5mm jack and RCA). Digital inputs: The Hub has 3 digital inputs (Coaxial, TOSlink and mini USB).
- Page 6 ® The Hub is identifiable on the linked device as "Focal Hub Bluetooth Receiver". To complete the link, please refer to the manual for your device for linking with the Hub. If no device is linked within 30 seconds, the Hub will exit linked mode.
- Page 7 EASYA U s e r m a n u a l remote control Functions and use of buttons: (Fig. E) INPUT SELECT/ ON/OFF SELECTION DES ENTREES PAIRING REMOTE LEARNING PROGRAMMATION TELECOMMANDE • Power OFF: allows you to manually set the Hub to standby mode. All LEDs on the front panel are turned off. Does not allow auto ON mode, the speaker goes straight to standby mode.
- Page 8 Remote learning • In a process of ultimate simplification of the system, each of the functions of the Focal remote can be programmed in an infrared remote control of your choice (TV, ADSL Box, CD player or universal) through the remote program- ming mode.
- Page 9 Your television’s Speakers If Easya loudspeakers are installed around your TV then you need to disable the speakers of your TV so that the sound is broadcast only through Easya. If you can not find the correct setting to turn off your TV speakers, please consult...
- Page 10 10/15°...
- Page 11 The loudspeakers and the Hub have been linked at Focal prior to carrying out the final test on your system. The Hub can only be linked to a maximum of 2 speakers. In the event that the link between the Hub and one or two speakers...
- Page 12 If the dome surface is marked this could have an impact on the tweeter. cleaning instructions The only maintenance required for Easya is dusting with a dry cloth. If the cabinet becomes marked, we recommend simply using a damp cloth. Never use solvents, detergents, alcohol-based or corrosive products, scrapers or scourers to clean the loudspeaker surface.
- Page 13 EASYA U s e r m a n u a l Specifications Easya Powered wireless 2-1/2 way bass reflex Type floor standing 5” (13cm) Polyglass woofer Speakers 5” (13cm) Polyglass bass/midrange 1” (25mm) Al/Mg TNV2 inverted dome tweeter Frequency response...
- Page 14 Please contact your Focal dealer if you encounter any problems. The guarantee for France on all Focal products is 2 years, non-transferable if the product is re-sold, from the date of purchase. In the case of defective equipment, the equipment must be shipped at your expense in its original packaging to the dealer who will test the equipment in order to determine the nature of the fault.
- Page 15 Focal-JMlab - BP 374 - 108, rue de l'Avenir - 42353 La Talaudière cedex - France - www.focal.com ® Tel. (+33) 04 77 43 57 00 - Fax (+33) 04 77 43 57 04 - SCAB-130916/3 - codo1386...
