MO1202-EA
© 2012 CASIO COMPUTER CO., LTD.
Keep the watch exposed to bright light
Bright Light
Solar panel
E-2
The actual level at which some functions are disabled depends on the watch model.
Be sure to read "Power Supply" (page E-59) for important information you
need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch's Power Saving function
has turned off the display to conserve power.
See "Power Saving Function" (page E-85) for more information.
E-4
Contents
General Guide ....................................................................................................... E-10
Radio-controlled Atomic Timekeeping ............................................................... E-12
Tide/Moon Data ..................................................................................................... E-34
World Time ............................................................................................................. E-41
Alarms .................................................................................................................... E-44
Stopwatch .............................................................................................................. E-49
Countdown Timer .................................................................................................. E-51
Illumination ............................................................................................................ E-55
Power Supply ........................................................................................................ E-59
Timekeeping .......................................................................................................... E-67
Tide Site Name ...................................................................................................... E-75
Reference .............................................................................................................. E-78
Specifications ....................................................................................................... E-93
E-6
To set an alarm time ............................................................................................. E-45
To test the alarm ................................................................................................... E-46
To turn an alarm on and off .................................................................................. E-47
To turn the Hourly Time Signal on and off .......................................................... E-48
To measure times with the stopwatch ................................................................ E-50
To configure the countdown timer ...................................................................... E-52
To use the countdown timer ................................................................................ E-54
To illuminate the display manually ...................................................................... E-55
To specify the illumination duration ................................................................... E-56
To turn the auto light switch on and off .............................................................. E-58
To set the time and date manually ...................................................................... E-68
E-8
Operation Guide 3278/3279
The electricity generated by the solar panel of the watch is
stored by a rechargeable battery. Leaving or using the
watch where it is not exposed to light causes the battery
to run down. Make sure the watch is exposed to light as
much as possible.
When you are not wearing the watch on your wrist,
position the face so it is pointed at a source of bright
light.
You should try to keep the watch outside of your sleeve
as much as possible. Charging is reduced significantly if
the face is covered only partially.
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Warning!
The measurement functions built into this watch are not intended for taking
measurements that require professional or industrial precision. Values produced
by this watch should be considered as reasonable representations only.
The Moon phase indicator and tide graph data that appear on the display of this
watch are not intended for navigation purposes. Always use proper instruments
and resources to obtain data for navigation purposes.
This watch is not an instrument for calculating low tide and high tide times. The
tide graph of this watch is intended to provide a reasonable approximation of
tidal movements only.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of this
product or its malfunction.
The watch continues to operate, even when it is not exposed to light. Leaving the
watch in the dark can cause the battery to run down, which will result in some watch
functions to be disabled. If the battery goes dead, you will have to re-configure watch
settings after recharging. To ensure normal watch operation, be sure to keep it
exposed to light as much as possible.
Battery charges in the light.
Bright Light
Solar panel
Electrical
(Converts light to
energy
electrical power.)
All
LEVEL 1
functions
LEVEL 2
enabled
LEVEL 3
Charge
LEVEL 4
Rechargeable battery
About This Manual
Depending on the model of your watch, display text appears either as dark figures
on a light background (Module 3278), or light figures on a dark background (Module
3279). All of the illustrations in this manual show Module 3278.
Button operations are indicated using the letters shown in the illustration.
Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the "Reference" section.
Module 3278
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To specify your Home City ................................................................................... E-13
To perform manual receive .................................................................................. E-27
To turn auto receive on and off ........................................................................... E-29
To check the latest signal reception results ...................................................... E-30
To adjust the high tide time ................................................................................. E-38
To reverse the displayed Moon phase ................................................................ E-40
To view the time in another city ........................................................................... E-42
To toggle a city code time between Standard Time and
Daylight Saving Time ...................................................................................... E-43
To configure tide site settings ............................................................................. E-75
To turn the button operation tone on and off ..................................................... E-84
To recover from the sleep state ........................................................................... E-86
To turn Power Saving on and off ......................................................................... E-86
E-1
Battery discharges in the dark.
LEVEL 1
LEVEL 2
Some or all
LEVEL 3
Dis-
functions
charge
LEVEL 4
disabled
E-3
Module 3279
E-5
E-7
E-9

Advertisement

loading

  Summary of Contents for Casio 3278

  • Page 1: Table Of Contents

    © 2012 CASIO COMPUTER CO., LTD. Operation Guide 3278/3279 Getting Acquainted Congratulations upon your selection of this CASIO watch. To get the most out of your purchase, be sure to read this manual carefully. Warning! The measurement functions built into this watch are not intended for taking measurements that require professional or industrial precision.
  • Page 2: General Guide

    Operation Guide 3278/3279 World Time Mode Alarm Mode General Guide • Press C to change from mode to mode. • In any mode (except when a setting screen is on the display), press L to illuminate the display. • When you return to the Timekeeping Mode, the day of the week will be displayed after the name of the site you selected.
  • Page 3: To Perform Manual Receive

    Operation Guide 3278/3279 Japan Signals Signal reception may not be possible at the distances noted below during certain times of the year or day. Radio interference also may cause problems with reception. 500 kilometers 500 kilometers Mainflingen (Germany) or Anthorn (England) transmitters: 500 kilometers...
  • Page 4: Tide/Moon Data

    Operation Guide 3278/3279 To check the latest signal reception results Signal Reception Troubleshooting Press D to view the latest successful receive time and Check the following points whenever you experience problems with signal reception. date. Press D again to return to the previous screen.
  • Page 5: World Time

    Operation Guide 3278/3279 To reverse the displayed Moon phase World Time 1. In the Tide/Moon Data Mode, hold down A until the World Time shows the current time in 48 cities (31 time hour digits start to flash. City code 2.
  • Page 6: Countdown Timer

    Operation Guide 3278/3279 To measure times with the stopwatch Countdown Timer Elapsed Time Dual timers can be set with two different starting times. ➤ ➤ ➤ ➤ Number of Repeats The watch can be configured so the two timers alternate,...
  • Page 7: Timekeeping

    If you experience problems getting the rechargeable battery to charge fully, contact your dealer or Auto and manual receive, CASIO distributor about having it replaced. Battery power illumination, and beeper Never try to remove or replace the watch’s rechargeable battery yourself.
  • Page 8: Tide Site Name

    Operation Guide 3278/3279 Auto DST ( ) can be selected only while LIS, LON, MAD, PAR, ROM, BER, Screen: To do this: Do this: STO, ATH, MOW, TPE, SEL, TYO, HNL, ANC, YVR, LAX, YEA, DEN, MEX, CHI, Press D (+) and B (–).
  • Page 9: To Turn The Button Operation Tone On And Off

    Operation Guide 3278/3279 Moon phase (part you can see) (part you cannot see) Tidal Movements Tides are the periodic rise and fall of the water of oceans, seas, bays, and other bodies of water caused mainly by the gravitational interactions between the Earth,...
  • Page 10 Operation Guide 3278/3279 Initial Screens World Time When you enter the World Time Mode or Alarm Mode, the data you were viewing The seconds count of the World Time is synchronized with the seconds count of the when you last exited the mode appears first.
  • Page 11 Operation Guide 3278/3279 City City City City Tide Site Tide Site Tide Site Tide Site Code Code Code Code BENOA,BALI INDONESIA IRAGO JAPAN VICTOR AUSTRALIA NOUMEA NEW CALEDONIA HARBOR AMPENAN, INDONESIA WAKAYAMA JAPAN USER USER LOMBOK KANNOURA JAPAN SUVA,FIJ FIJI ISLANDS...
