USER'S MANUAL
MODEL: VST-WC588IH
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
This user's manual contains important information about your Alarm's operation. If you are installing the Alarm for use by others, you
must leave this manual—or a copy of it—with the end user.
MAIN FEATURES
DC operated Wireless Interconnectable carbon monoxide alarm
Electrochemical CO sensor
Test / Hush Button
High and stable sensitivity
With quick fix mounting bracket for easy installation
Fitting and battery tamper-resist feature
LED operation indicator
Extra loud alarm sound over 85 dB at 1m
Low-battery and battery missing warning indicator
Auto reset after CO is clear
SPECIFICATION
Detection Type:
Power Source:
Working frequency:
Emission distance:
Standby Current:
Alarm Current:
CO Alarm Level:
Alarm Sound Level
Operation Temperature:
Ambient Humidity:
Compact size:
IMPORTANT SAFETY INFORMATION
1. WHAT IS CARBON MONOXIDE?
Carbon monoxide is a colorless, odorless and tasteless poison gas that can be fatal when inhaled. CO blinds to the hemoglobin in the
blood and inhibits its capacity to carry oxygen. CO kills hundreds of people each year and injures many more because it is difficult to
be detected with the human senses. In high concentrations, CO can kill in minutes.
2. SOURCES OF CARBON MONOXIDE
WIRELESS CARBON MONOXIDE ALARM
Electrochemical CO sensor
9V(6F22) Battery
868MHz
>60m（open space）
25uA max
40mA max
50ppm (Between 60-90 min)
100ppm (Between 10-40 min)
300ppm (<3min.)
85 Decibels at 1 meter
4℃ to 40℃
15% to 90% Relative Humidity
110mm diameter
Advertisement
Table of Contents
Summary of Contents for rientalert VST-WC588IH
- Page 1 USER’S MANUAL MODEL: VST-WC588IH IMPORTANT! PLEASE READ CAREFULLY AND SAVE. This user’s manual contains important information about your Alarm’s operation. If you are installing the Alarm for use by others, you must leave this manual—or a copy of it—with the end user.
-
Page 2: Symptoms Of Co Poisoning
Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO. CO can be produced when burning any fossil fuel, such as gasoline, propane, natural gas, oil and wood. It can be produced by any fuel-burning appliance that is malfunctioning, improperly installed, or not ventilated correctly, such as: Automobiles, furnaces, gas ranges/stoves, gas clothes dryers, water... -
Page 3: General Limitations Of Co Alarms
Mild Exposure: Slight headache, nausea, vomiting, fatigue (often described as “flu-like” symptoms) Medium Exposure: Severe throbbing headache, drowsiness, confusion, fast heart rate. Extreme Exposure: Unconsciousness, convulsions, cardio respiratory failure, death. Many cases of reported CARBON MONOXIDE POISONING indicate that while victims are aware they are not well. They become so disoriented they are unable to save themselves by either the building or calling for assistance. - Page 4 If your bedroom hallway is longer than 40 feet (12 meters), install a CO Alarm at BOTH ends of the hallway. In a Single-level Home: Install at least one CO Alarm near or within each separate sleeping area. For added protection, install an additional CO Alarm at least 20 feet (6 meters) away from the furnace or fuel burning heat source.
-
Page 5: How To Install This Alarm
In extremely humid areas. This alarm should be at least 10 feet (3 meters) from a bath or shower, sauna, humidifier, vaporizer, dishwasher, laundry room, utility room or other source of high humidity. In areas where temperature is colder than 40˚ F (4˚ C) or hotter than 100˚ F (38˚ C). These areas include unconditioned crawl spaces, unfinished attics, uninsulated or poorly insulated ceilings, porches, and garages. - Page 6 The unit can be tested with CO by using one of the kits that comes with CO either in a glass phial or aerosol can. Follow the instructions on the kit. When it senses the CO，it will have a Pre-Alarming status, please refer to table A for all detailed alarming indicators: CO Alarm Response CO Level...
- Page 7 will require the power to be removed, Press and hold the button for a minimum of 10 seconds before powering again. Close battery compartment door, snapping it into place. Push test button to test alarm. See “TESTING THE SMOKE ALARM” for details. CAUTION: Due to the loudness of the alarm, always stand at an arm’s length away from the unit when testing.
- Page 8 Current Status Function (Press button and Function (Press button and hold it release it in 2 seconds) for 3 seconds minimum) Normal Operation、Hush State、Low Test Local Hush Battery Local Alarm Locate All Hush Remote Alarm Locate All Hush Locate Alarm None Local Hush Reset...
-
Page 9: Regular Maintenance
WARNING! The Hush Feature is for your convenience only and will not correct a CO problem. Always check your home for a potential problem after any alarm. Failure to do so can result in injury or death. NEVER remove the batteries from your CO Alarm to silence the horn. Use the hush feature. Removing the batteries removes your protection! See “If Your CO Alarm Sounds”... -
Page 10: If Your Co Alarm Sounds
To replace the batteries: Use screwdriver to twist out the tamperproof tabs on both sides of the alarm。 Turn alarm counterclockwise to detach it from the mounting plate. Open the battery cover and remove the battery from the compartment. Press and hold Test/Hush bottom for 10s and then release it. Insert a new 9-volt battery to compartment. -
Page 11: Troubleshooting Guide
operation of this equipment. If problems are identified during this inspection have the equipment serviced immediately. Note any combustion equipment not inspected by the technician, and consult the manufacturers’ instructions, or contact the manufacturers directly, for more information about CO safety and this equipment. Make sure that motor vehicles are not, and have not, been operating in an attached garage or adjacent to the residence. - Page 12 CO Alarm sounds frequently Unit is set to the same ID as a Change the ID of your units by following the even though no high levels system nearby. instructions in HOW TO SET THE of CO are revealed in an WIRELESS INTERCONNECTION investigation.
