- Page 1 DV900/DV939/DV708 Black Box Vehicle Video Recorder User Manual 2011 JAN. V1.0 ATBS Technology Co. http://www.tpms.tw/...
-
Page 2: Table Of Contents
Table of Contents A. Features ......................1 B. Specification....................1 C. Structure of Product ..................3 D. Dimension......................4 E. Installation Guide..................... 5 F. Led Indicator Instruction................... 8 G. Software Player Instruction ................9 H. Formatting Memory Card ................14 I. -
Page 3: Features
B a t t e r y 10. Professional file formats, without built-in lithium battery, no needs to afraid of heat and bursting concerns, it is the real black box. 11. Using professional-grade compression engine with data files can’t be modified to construct the best recorder. - Page 4 (b) Red Light: recording. (c) Green light: Power Note: The system is divided into NTSC / PAL both. A. EDR interpreter and cable configured: DV900: AT0428H (support 25 protocols/ 500 car models) and CB0428_12V cable. DV939:AT1939H and CB1939/CB0428_24V cable Accessories...
-
Page 5: Structure Of Product
C. Structure of Product Front View Back view Record Power LED Micro SD card Side view Connect to EDR AV out... -
Page 6: Dimension
D. Dimension Unit mm... -
Page 7: Installation Guide
E. Installation Guide Make the bracket facing upward. Assemble the sucking disc and Micro SD card. Set up the machine in proper Adjust the viewing angle. position. - Page 8 The interpreter and cable must be in accordance with car model configuration, but the DV900 / DV939 DVR is configured the same. DV900 : for passenger car, OBD2 cable & AT0428H DV939 : for J1939 heavy duty vehicle, configured with CB1939 or CB0428 ( OBD2...
- Page 9 NOTE: To press RESET button over 1 second that will clear protocol memory. 6.3 After interpreter learning was successful, the DV900/DV939/DV708 red light flashes mean the video and traffic information are recorded. 6.4 Interpreter cable:...
-
Page 10: Led Indicator Instruction
F. Led Indicator Instruction Record Power LED Power On / Recording Power on and wait for about a minute and then boot the machine completely. In the boot process, the green indicator will light on about one minute; the red indicator will flash, that is on recording. LED light indicator: RED light will be flashing during recording. -
Page 11: Software Player Instruction
Play botton, Select the CarBox2.exe Screen as shown below, press memory card; or select Open Document Select the memory card or the files stored on the hard disk to play; during file playback, if we want to pause the playback, we could directly tap the pause button to pause playback N ote: It is recommended to copy the product CD IBoxPlayer folder to the ★... - Page 12 2. Play & Settings Icon Instruction: play previous file play previous frame play backward Pause Stop Play Play next frame Play next file Disk back up, transfer video and traffic information setting Open file Snapshot tools format memory card Disk backup Save the recorded files to your PC.
- Page 13 Select the origin from the SD card Setp2: Select the recorded file which you want to backup Step3: Choose the backup file format Offer SD Card Backup (*.sd) , AVI File Backup (*.avi) (1) SD card backup format SD File type (*.sd) (2)AVI File Backup(*.avi) (*.srt) When using AVI format, it will produce an AVI file, a file for subtitle display (*.srt) ,and traffic information Excel file.
- Page 14 Step5: Backup : Start backup the file to your specified destination Setting Before using the machine, please insert the micro SDHC card to the card reader and connect to the PC to set up the machine. When finished, you can insert the card back to the machine and start recording password This function can encrypt the data and prevent others from accessing.
-
Page 15: Volume Control
Time setting Use computer system for setting the time. Unit of speed : Select vehicle speed unit. Un i t of T em per a t ur e : S el ec t en g i ne t em per a tur e u n it . G - S e ns or s e ns it i v i t y: O f f : tur n of f G - s ens or l ig h t: G - s e ns or ac ti v e wh e n G f or c e... -
Page 16: Formatting Memory Card
H. Formatting Memory Card 1. When You Should Format SDHC CARD? When you use the SDHC card for the first time or just purchase a new card, you should format it in order to use it correctly. (The bundled SDHC card has been formatted and tested by the manufacturer already.) Click on Format to start formatting the SD card. -
Page 17: Caution
2. Restoring Memory Card When you have backup the recorded files into PC and want to use the SDHC card for other purposes, you have to restore it first so it can be used correctly. How to restore it? Steps: 1.) Insert the CD in your PC and click on Format to start formatting the SD card.
