Summary of Contents for KeeLog KeyGrabber TimeKeeper
- Page 1 KeyGrabber TimeKeeper User’s Guide KeyGrabber TimeKeeper USB 2 GB PS/2 2 GB inc. Mac Compatibility Pack (MCP) Check http://www.keelog.com/ for the latest version of this document. Copyright © 2013 KeeLog...
-
Page 2: Table Of Contents
Learn about keystroke recording first: section Recording keystrokes Then learn to retrieve the recorded data: section Viewing recorded data Finally, configure the internal clock: section Clock configuration Questions or problems? Go through the Troubleshooting section. Copyright © 2013 KeeLog... -
Page 3: Introduction
PS/2, with an additional time-tracking module powered by an internal battery. The KeyGrabber TimeKeeper inherits all the powerful features of the USB and PS/2 series, adding the capability to create date and time-stamps in the log file. All TimeKeeper series devices have a huge 2 Gigabyte flash disk, ensuring years’... -
Page 4: Applications
Observe WWW, E-mail, and chat usage Save a copy of written documents Investigators: Monitor remote computers Retrieve unknown passwords, operating system independent Collect computer-related evidence Detect unauthorized use of computer equipment Copyright © 2013 KeeLog... -
Page 5: Quick Start
To view recorded data using the USB version, plug the device in-between the keyboard and USB port, and then press the 3-key combination simultaneously (by default K, B, S) The keylogger will pop-up as a removable drive, containing the file LOG.TXT. This file will contain all recorded keystroke data. Copyright © 2013 KeeLog... - Page 6 Alternatively, to gain instant access to the entire log, connect the keylogger to a USB port using the USB Download Accelerator. The keylogger will pop-up as a removable drive, containing the file LOG.TXT. This file will contain all recorded keystroke data. Copyright © 2013 KeeLog...
-
Page 7: Recording Keystrokes
KeyGrabber TimeKeeper Recording keystrokes Recording mode is the default mode of operation for the KeyGrabber TimeKeeper keylogger. In record mode, the device will silently monitor all keystrokes coming from the keyboard and store them on the internal Flash Drive in file LOG.TXT. -
Page 8: Viewing Recorded Data
The operating system will use the standard built-in mass storage driver (MS Windows 7 in the following examples). Note: During the first switch to Flash Drive mode, the operating system can ask for drivers. In such case choose automatic driver installation (usually default option). Copyright © 2013 KeeLog... - Page 9 Use the systems standard disk removal procedure. For MS Windows, left-click on the Safe Removal icon in the system tray and select the appropriate drive. For additional information, refer to the KeyGrabber USB User’s Guide and the KeyGrabber PS/2 User’s Guide. Copyright © 2013 KeeLog...
-
Page 10: Text Menu Mode (Ps/2 Version Only)
Use the digit keys to browse around the menu. Note: do not change the active application while in text-menu mode. For additional information, refer to the KeyGrabber PS/2 User’s Guide. Copyright © 2013 KeeLog... -
Page 11: Clock Configuration
For the PS/2 version, the USB Download Accelerator has to be used to switch to Flash Drive mode. After copying the file, safely remove the Flash Drive. The new clock configuration will be loaded during the next power-up. Copyright © 2013 KeeLog... - Page 12 If 24 is chosen, the 24-hour format is selected and the specified hour is treated as 24- hour format. Sample TIME.TXT for 12-hour time: Sample TIME.TXT for 24-hour time: Year=2010 Year=2010 Month=10 Month=10 Day=25 Day=25 Hour=5 Hour=17 Minute=51 Minute=51 Second=43 Second=43 Format=PM Format=24 Copyright © 2013 KeeLog...
-
Page 13: Configuration Files
KeyGrabber TimeKeeper Configuration files The KeyGrabber TimeKeeper is configured via two text files placed on the internal Flash Drive: CONFIG.TXT (configures key-logging parameters) TIME.TXT (configures the internal clock for time-stamping) These files should contain configuration parameters, placed in successive lines in the... -
Page 14: Config.txt
Modifier byte check flag (USB version CheckModifierByte CheckModifierByte=No only). Filter value (range 0…255, FrameFilter FrameFilter=226 Frame filter value (USB version only). default 98) Auto (default) Full USB keyboard speed setting (USB KeyboardSpeed KeyboardSpeed=Auto version only). Mixed Copyright © 2013 KeeLog... -
Page 15: Time.txt
If PM is chosen, the 12-hour format is Format PM (default) Format=24 selected and the specified hour is treated as after noon. If 24 is chosen, the 24- hour format is selected and the specified hour is treated as 24-hour format. Copyright © 2013 KeeLog... -
Page 16: Mac Compatibility Pack (Usb Version Only)
Low-Speed combos, creating a challenge for all types of USB keyloggers. The aluminum Apple A1243 and A1242 are typical examples: The KeyGrabber TimeKeeper with the Mac Compatibility Pack features a special Mac Mode (enabled by default), which will convert the keystroke data stream to USB Full-Speed, ensuring proper operation of the keyboard and logging of all keystrokes. -
Page 17: National Keyboard Layouts
Flash Drive mode. Layout files may be obtained from the CD-ROM attached with the device. USB version PS/2 version To enable the layout safely remove the flash disk. During the next power-up, the layout file will be loaded automatically. Copyright © 2013 KeeLog... -
Page 18: Using Kl Tools
KL Tools will ask for the device type, and assist in configuring the device and retrieving the log file. There is no special knowledge required to use KL Tools – simply follow the instructions displayed by the application. Copyright © 2013 KeeLog... -
Page 19: Specifications
(L x W x H) All KeyGrabber products come with 1 year warranty against manufacturer defects. Defect products must be shipped by the customer. All warranty repairs and delivery to the customer will be paid by the manufacturer. Copyright © 2013 KeeLog... -
Page 20: Troubleshooting
KeyGrabber TimeKeeper Troubleshooting The KeyGrabber TimeKeeper will not work with the following hardware configurations: 1. Internal laptop keyboards 2. Bluetooth keyboards 3. USB-PS/2 and PS/2-USB adapters 4. Non-conformant USB or PS/2 keyboards The keyboard is not responding The keyboard connector or the keylogger connector is not inserted firmly. Please check the connection with the PS/2 or USB keyboard and port. - Page 21 2. Check if the problem appears on a different computer. 3. Contact the dealer you have purchased the device from. Please supply all necessary information (keyboard model and manufacturer, OS type and version, and a short description of the problem). Copyright © 2013 KeeLog...
-
Page 22: List Of Special Keys
6 / Right (num) [Win] [7N] 7 / Home (num) [Aps] Apps [8N] 8 / Up (num) [Cap] Caps Lock [9N] 9 / Page Up (num) [Ent] Enter [Pwr] Power [Bck] Backspace [Slp] Sleep [Tab] [Wke] Wake Copyright © 2013 KeeLog... -
Page 23: Legal Disclaimer
You should not use this device to intercept data you are not authorized to possess, especially passwords, banking data, confidential correspondence etc. Most countries recognize this as a crime. Please consult a legal representative for logging requirements in your country. Copyright © 2013 KeeLog... - Page 24 KeyGrabber TimeKeeper Notes: European Office U.S. Office KeeLog Aqua Electronics Lekcyjna 42 1550 Louis Ave. PL 51-169 Wroclaw Elk Grove Village, IL. 60007 Poland U.S.A http://www.keelog.com/ keelog@keelog.com RoHS Copyright © 2004-2013. All rights reserved. Copyright © 2013 KeeLog...
