- Page 1 GEO-FL-100W-IP65-007 100W LED Flood Light User Manual Beam Angle 15°x 15° 30°x 30° 40°x 40° 60°x 60° 60°x 135°(Symmetric) 85°x 135° (Asymmetric) IP Rate IP65...
- Page 2 I ntroduction Materials Patented fin aluminum heat-sink structure; High quality aluminum processing technique; Special surface treatment process; High brightness LED light source, high efficiency and long life power supply. Applications Suitable for Warehouses, Production and logistics workshops, Retail stores, Theme restaurants, Amusement parks, Indoor stadiums and public places, and other industrial and commercial lighting purposes.
-
Page 3: Specification
2. Specification 100W LED Flood light Parameter: Input Voltage 90-305 VAC, 50/60 Hz Philips Lumileds/Cree/LG/OSRAM LED Light Source LED Qty 50 pcs LED Power 100W Total System Power 110W Led Luminous Efficiency 110~130lm /W Light Lighting efficiency ≥85lm /W Led Initial Luminous Flux 10000 Lm Illuminance Uniformity ＞0.8... - Page 4 Product Dimension & Photometric Distribution: 1、Dimension 2、Photometric Distribution Beam Angle:15°x 15° 30°x 30° Beam Angle: 40°x40° Beam Angle: 3/6 页...
- Page 5 60°x60° Beam Angle: 60°x135° Beam Angle: 85°x135° Beam Angle:...
- Page 6 Accessories: Projection Lens Type Light Pattern Item Item Photo Schematic 15°x 15° lens Round Type 30°x 30° lens round 40°x 40° lens 60°x 60° lens symmetric Aspherical Type 60°x 135° lens (symmetric) 85°x 135° lens (asymmetric) asymmetric 4. Installation Guideline 1.
- Page 7 Maintenance / Repairing Instructions: 1、 Make sure the power has been turned off before maintenance or repairing. 2、Clean the glass cover regularly to maintain high transmission of light. 3 、 Clean up the dust from the glass cover and heat-sink regularly to keep sound heat dispersion.
