Save, Edit or Delete a Route

Save the current route: While you are navigating, the current route can be saved. From the
Navigation X-Press™ Menu, select Save Current Route and press the RIGHT Cursor key. Navigation
will continue.
Display the Routes submenu: From any view, press the MENU key twice to display the Main Menu
System, then use the RIGHT Cursor key to select the Navigation tab. Select Routes and press the
RIGHT Cursor key to display the Routes submenu.
Create a route: From the Routes submenu, select Create and press the RIGHT Cursor key. A Route
Edit screen will be displayed with an empty route. You can name the route, add waypoints to the
route from the list of all waypoints, and order the waypoints in the route using the Cursor keys.
Edit a saved route: From the Routes submenu, select Edit and press the RIGHT Cursor key. A Route
Edit screen will be displayed. Select the route you wish to edit and press the RIGHT Cursor key. Re-
name the route or change, delete or re-order the waypoints used in the route.
Delete a saved route: From the Routes submenu, select Delete and press the RIGHT Cursor key.
Select the route you wish to delete and press the RIGHT Cursor key. You will be asked to confirm
your choice by pressing the RIGHT Cursor key again before the route is deleted.
Travel a saved route: From the Routes submenu, select Travel and press the RIGHT Cursor key. A
list of saved routes will appear. Select the route you wish to travel and press the RIGHT Cursor key
to make this route the current route and begin navigation. You may also travel the route in either
forward or reverse order.
Route Info: From the Routes submenu, select Info and press the RIGHT Cursor key. A list of saved
routes will appear. Select the route for which you want information, and press the RIGHT Cursor
key. The list of waypoints in the route will be shown, with the distance and bearing from each
waypoint to the next, as well as the distance and bearing from the current position to the first
waypoint in the route.

Save or Clear a Current Track

Save the current track: From the Navigation X-Press™ Menu, select Save Current Track and press
the RIGHT Cursor key. The track will remain on the display, but will change from black to gray. To
remove the track completely from the display, see Edit, Delete or Hide Saved Tracks.
NOTE: When you save a track, a name is automatically assigned. The track name consists of a
date/time stamp, but can be re-named later (see Edit a Saved Track).
Clear the current track: From the Navigation X-Press™ Menu, select Clear Current Track and press
the RIGHT Cursor key. The track will be removed from the display and discarded.
24
3:28 PM Page 30

Edit, Delete or Hide Saved Tracks

Display the Tracks Submenu: From any view, press the MENU key twice to display the Main Menu
System, then use the RIGHT Cursor key to select the Navigation tab. Select Tracks and press the
RIGHT Cursor key to display the Tracks submenu.
Edit a saved track: From the Tracks submenu, select Edit and press the RIGHT Cursor key to display
the list of saved tracks. Select the track you want to edit and press the RIGHT Cursor key. When the
Edit Track dialog box appears, use the Cursor keys to move between fields. In the Track Name field,
the UP and DOWN Cursor keys change the letter or number. All upper and lower case letters are
available, as well as digits 0-9 and some punctuation characters. You can exit the Track Name field
with the LEFT and RIGHT Cursor keys or by pressing the EXIT key. Select Save and press the RIGHT
Cursor key to save your changes.
Delete a saved track: From the Tracks submenu, select Delete and press the RIGHT Cursor key to
display the list of saved tracks. Select the track you want to delete and press the RIGHT Cursor key.
You will be asked to confirm deletion before the track is actually deleted.
Hide or display a saved track: From the Tracks submenu, select Visibility and press the RIGHT
Cursor key to display the list of saved tracks. Select the track you want to hide or display and use
the Cursor keys to select Hidden or Visible. Press the EXIT key to return to the Tracks submenu.
25
