HD-IP CAMERA
HED BPW3100T
COLOR CAMERA
NOTE:Before using the camera,
please read this User Guide in detail!
CAUTION:Do not attempt to disas-
semble the camera by yourself. If the
camera can not work, please contact
our company or local franchisers.
Specification
Model
BPW3100T
Image Sensor
1/4" 1.0 Megapixel CMOS Image sensor
Resolution
1280×720
Minimum
0.5 Lux
Illumination
S/N Ratio
39db
Focus Mode
Manual Focus
Day/Night
IR cut filter with auto switch, IR sensor.
1 RJ45 Ethernet interface, 10/100M adapta-
Network
tion
Delay
Within The LAN0.3S
Frame Rate
25 FPS ( 1-25 FPS adjustable)
Video
H.264 compression ,dual stream ( 0.1M-
Compression
4Mbps adjustable)
Protocols: RTSP/FTP/PPPOE/DHCP/DDNS/
Protocol
NTP/UPnP
Onvif
Support Onvif 2.0
User
Multi-user Classification Management
Permission
Power/Current
DC 12V/1A
Consumption
3.0W
Lens
2.8-12mm Manual Zoom Lens
IR Status
IR LED: ¢5X42PCS IR range: 40M
Dimension
290W) x 92(H) x 80(D)mm
(mm)
Weight (g)
1850
Temperature
-10~55℃
Humidity
0%-90%RH,Without Condensation
Packing List
No
Name
Model
Quantity
IPC-
1.
HD-IP Camera
BPW3100T
IPC-
2.
CD
BPW3100T
Main Featuers
1.Support WEB Configuration, and IE
Surveillance
2.Support Dual Stream
3.Support OSD, Chroma, Brightness,
Saturation, Electric Zoom Configu-
ration
4.Support real-time transmission,
center warning and picture pop-up
(after motion detection and IO
alarm)
5.Support DDNS and UPNP remote
control;Support Onvif 2.0;Support
IR-Cut Switch;
6. Be sensitive to infrared
7.Provide complete SDK database
Connecting
RJ45 Ethernet
1
DC12V/1A
interface (VIDEO)
1
IPC-BPW3100D
