EasyStart
TRITON Extreme Main Features
•
Largest onboard sample memory in any Korg
workstation to-date: 160MB of 48 kHz wave
ROM
(including a new concert piano in addition to
the acclaimed 16MB stereo velocity-switching
piano). 32 MB of new acoustic samples, including
sounds captured with natural vibrato, new organs,
guitars, basses and much more. All the data from
Vintage Archives, Orchestral Collection and Trance
Attack EXB-PCM boards, plus the best from
Pianos/Classic Keyboards, Studio Essentials and
Dance Extreme. Expandable with the EXB-MOSS
DSP (Z1) synthesis board!
•
120 notes of polyphony
sustained passages; for developing complex
Combinations and when sequencing!
•
2889 preload sounds
/ 3266 sound and 194 drum
kit locations. MOSS adds another 128 DSP
programs!
•
Blazing fast TouchView graphic interface
makes navigation a breeze - the ultra-powerful
processor is 6x faster than TRITON "Classic"!
•
The most versatile effect system available:
inserts w/102 effects, 2 masters w/89 effects,
includes sync-able effects, 3-Band master EQ, send
external audio through effects!
•
Tube-driven Valve Force processing:
used as an insert or on final output to add warmth
and "snarl". You can even sample through the tube!
•
Dual polyphonic Arpeggiators:
locations w/507 user, sync-able to MIDI clock.
Making connections; Loading the preload data; Playing the Demo Songs
Selecting and playing Programs and Combinations
Sound Tour; Valve Force Technology
Arpeggiator mode
Sequence mode: Template Songs; One-Touch-Record; SysEx Recording, Tone-Adjust
Resampling; Sampling mode: Time Slicing; Creating a Multisample
In-Track Sampling; Resampling a Song as a WAV file
Creating Audio CDs; Media mode; USB Storage mode; EXB-MOSS Option
Important Owner's Manual References
•
•
- plenty for playing
•
•
5
•
Can be
•
512 memory
EasyStart CONTENTS
Open Sampling System provides sampling
and resampling in all modes:
RAM (expandable to 96 MB), 48 kHz sampling
rate, with Time Slicing / Stretching and more!
Sample direct to CompactFlash as longer samples
for ext. computer editing or audio CD burning via
USB! Sampling/Resampling through tube, all
insert and master effects! Load Korg, Akai®
S1000/3000 (advanced Program conversion!),
AIFF and WAV via CompactFlash® and external
USB devices!
In-Track sampling
allows sampling direct to
sequencer as MIDI events.
Same powerful TRITON sequencer:
200,000 events, Cue List and RPPR functions,
shortcuts like Template Songs, One-Touch Record,
preset rhythm patterns, independent track-
looping, Swing Quantize, Tone Adjust to tweak
sounds inside the sequencer, SysEx Record any
realtime parameter changes in a track!
Two USB ports:
Connect a CD-R/RW drive to
Port A for loading, saving data and for burning
audio CDs. Connect Port B to computer to access
media in CompactFlash slot for direct file sharing!
6 outputs
allow routing of any sound to any
output or stereo pair with any effects!
S/PDIF digital I/O:
48 kHz for connection to
DAT, MD or digital multitrack recorders.
16 MB Sample
16 Tracks,
2
2
3
3
4-5
6-8
9
10
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Music Keyboard and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Triton Music Keyboard

  • Page 1 Blazing fast TouchView graphic interface sounds inside the sequencer, SysEx Record any makes navigation a breeze - the ultra-powerful realtime parameter changes in a track! processor is 6x faster than TRITON “Classic”! • • Two USB ports: Connect a CD-R/RW drive to...

  • Page 2: Making Connections

    Connect AC power cable, and connect L/R audio outputs to a stereo monitor system (or use headphones) Press the rear panel POWER SWITCH to power-on the TRITON Extreme. Note that during power-up, the display will indicate the current Operating System as well as any installed SIMM modules and the EXB-MOSS option (if installed).
  • Page 3 Electribe EMX1 and ESX1? Vacuum tubes produce rich harmonics and smooth distortion, depending on how they are used. In the TRITON Extreme, the tube can be used as an insert effect or placed just before the final output – and you can connect an electric guitar, mic, another synth or keyboard, etc. to the Extreme’s audio inputs and process…even sample or In-Track sample external devices through the...

  • Page 4: Sequence Mode

    Press ”P6: User Arpeggio” Press the “Pattern Edit” tab, play a key to re-trigger the pattern, and view the arpeggiator grid. TRITON Extreme’s arpeggiator provides up to 12 tones and 48 steps per pattern. To learn more about editing and creating your own arpeggio patterns, see the Operation Guide, page 94, and the Parameter Guide, page 170.

  • Page 5: One Touch Recording

    “Save Template Song”). One-Touch Recording This great feature allows the TRITON Extreme to capture your inspired moments whenever they happen. The “One-Touch” record feature will instantly set the sequencer to create a new song that preserves all the nuances of your current playing in Program or Combination modes – Effects settings, Arpeggiator, etc.
  • Page 6 In the following exercise, you’ll use TRITON Extreme’s “Grid” function to view and effortlessly-set a perfect sample loop point…...
  • Page 7 Press the upper-right ▼ popup, and then scroll to the right and select “Time Slice”. The display will indicate “Set Sample Tempo”. And since you’ve set a perfect loop using the Grid function, the TRITON Extreme will analyse the sample waveform and display “Beat 4 Source BPM 089”...
  • Page 8 “Create”. Repeat the previous step 3x, to record three more samples, sampling “the”, “Triton”, and finally “Extreme” …That’s it! Now play the keyboard: play each note (half-step) from C2 to E2, and you’ll hear the sampled words, “This is the TRITON Extreme“.
  • Page 9 Operation Guide, page 117 for more information. In-Track Sampling The TRITON Extreme allows an external audio source (a guitar or mic for example) to be recorded (sampled) at the same time during song playback, to create event data in an empty sequence track. For...

  • Page 10: Creating Audio Cds

    Parameter Guide 190 USB Storage mode By connecting the TRITON Extreme’s USB B port to your computer’s USB port, data on the inserted CompactFlash card can be accessed from your computer for storage or external editing. Data can also be dragged from your computer onto the card, like sounds and samples downloaded from the Internet, or from your internal HD and CD drive.
  • Page 11 Restoring the Factory Settings Operation Guide 127 For more information… The TRITON Extreme Owner’s Manuals provide a wealth of information on sound programming, effects, sequencing, sampling, editing WAV files saved to media and much more. And make sure to visit www.korg.com...
