Summary of Contents for Zavio V111T

  • Page 1 V111T User Manual...

  • Page 2: Table Of Contents

    V111T User Manual V111T Video Server Hardware User Manual -Contents- CHAPTER 1. SAFETY INSTRUCTION ........................2 CHAPTER 2. INTRODUCTION............................ 4 CHAPTER 3. PACKAGE CONTENTS ......................... 5 CHAPTER 4. PHYSICAL DESCRIPTION........................6 4.1 F ................................6 RONT 4.2 B ................................7 CHAPTER 5.

  • Page 3: Chapter 1. Safety Instruction

    V111T User Manual Hardware User Manual Chapter 1. Safety Instruction  Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to heed the following.
  • Page 4 V111T User Manual  In case of a breakdown In case of system breakdown, discontinue use and contact your authorized dealer.  In case of abnormal operation  If the unit emits smoke or an unusual smell,  If water or other foreign objects enter the cabinet, or ...

  • Page 5: Chapter 2. Introduction

    V111T User Manual Chapter 2. Introduction The V111T is a full-function 1-channel video server offering Power over Ethernet (PoE), RS-485 for PTZ control, digital inputs / outputs for external alarm or sensor and its incredibly stable and powerful firmware Key Features: ...

  • Page 6: Chapter 3. Package Contents

    V111T User Manual Chapter 3. Package Contents Video Server- V111T Video Server Quick Installation Guide - To provide brief product information and quick installation and wireless setting Software CD - To provide IP Surveillance Software, Intelligence IP Installer, User Manuals, and...

  • Page 7: Chapter 4. Physical Description

    V111T User Manual Chapter 4. Physical Description 4.1 Front View  Video In-To support one channel video input for easy use  Video Out -To support one channel video output for easy use  I / O Terminal Connector (1~4 Pin) –1 Input / 1 Output to support External Alarm and Sensor used for motion detection, event triggering and alarm notification…etc.

  • Page 8: Back View

    V111T User Manual 4.2 Back View  PWR- Power LED will light up after the IP Camera completed the boot process  Power Connector - For connection of 12V DC input  Reset - When the device is empowered, press the Reset Button to reboot the device, or hold the Reset Button for 10 seconds to set the device settings back to factory default ...
  • Page 9 V111T User Manual Terminal connector diagram Please refer the following illustration below for connection method. RS+485 D- COM NO RS-485 Ground Switch Alarm out device Ground Max. 30W...

  • Page 10: Chapter 5. Basic Connection

    V111T User Manual Chapter 5. Basic Connection A video server makes it possible to move forward a network video system without having to discard existing analog equipment. It brings new functionality to analog equipment and eliminates the need for dedicated equipment such as coaxial cabling, monitor and DVRs. You can see the basic...
