IS-ZW-TSTAT-300
Advanced Thermostat
Operation Guide
Content
Contact information
For contact information, see www.interlogix.com.
© 2013 UTC Fire & Security Americas Corporation, Inc.
Interlogix is part of UTC Climate Controls & Security,
a unit of United Technologies Corporation.
All rights reserved.
P/N 1069511 • REV B • ISS 12FEB13
1
Advertisement
Table of Contents
Related Manuals for Interlogix IS-ZW-TSTAT-300
Summary of Contents for Interlogix IS-ZW-TSTAT-300
-
Page 1: Table Of Contents
Contact information For contact information, see www.interlogix.com. © 2013 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. P/N 1069511 • REV B • ISS 12FEB13... -
Page 2: Description
Description The IS-ZW-TSTAT-300 programmable communicating thermostat operates via a high-quality, easy-to-use touch screen. To program or adjust your thermostat, simply touch your finger firmly to the screen. The screen will automatically light up and you will hear a “beep”. The screen will respond differently to different types of touches, so you may want to experiment by touching it different ways, finger, fingernail, etc. -
Page 3: Home Screen
Home screen The Home screen is displayed when the unit is operating. This screen shows you the current settings and conditions. Figure 2: Home screen Fan status Time slot Time of day RADIO Lock status Radio indicator Chirp indicator LINK Target temperature Thermostat mode TARGET TEMP... - Page 4 The thermostat has two lock modes. Touch the Unlock icon for 3 seconds; Unlock/Lock icon the unit will go into the Partial Lock mode (Lock icon with one bar). You can temporarily override the thermostat target temperature with the +/- buttons. IS-ZW-TSTAT-300 Advanced Thermostat Operation Guide...
-
Page 5: Program Screen
For full lock, touch the Lock icon again for 5 seconds to go to Full Lock mode (Lock icon with two bars). No changes can be made. Once locked, the thermostat will respond just to mode and menu. To unlock, press the Menu button. Touch and hold the Lock icon for 5 seconds for two bars (if not there already). -
Page 6: Manual Screen
(HEAT 70°F all day and 62°F at night; COOL 78°F all day and 82°F at night). To modify this program, touch the PROG button and then touch the Day area until HOLIDAY appears (after SAT). IS-ZW-TSTAT-300 Advanced Thermostat Operation Guide... -
Page 7: Initial Settings
If you set your thermostat for HEAT PUMP with auxiliary heat, the EMER EMER function is available on the Manual screen. If you touch EMER, it displays (heat pump only) EMER|ON. You heat pump is disabled and auxiliary heat is your sole source of heat. -
Page 8: Other Functions
The Save Energy feature on the thermostat provides a simple, easy-to-use way to help you manage your energy use. This feature automatically adjusts your target temperature up in COOL or down in HEAT by 4 F. To use the Save Energy IS-ZW-TSTAT-300 Advanced Thermostat Operation Guide... -
Page 9: Communicating Thermostat
feature, press the Save Energy button in the upper left corner of the unit. The screen will now read “Save Energy”. To return to normal operation, press the Save Energy button again. This is useful to save energy if your are going to be gone for a short time. -
Page 10: Specifications
Dimensions (W x H x D) 5.5 x 3.5 x 1.5 in. (140 x 89 x 38 mm) Operating environment Indoor use only Temperature 32 to 104°F (0 to 40°C) Relative humidity 10 to 90% noncondensing IS-ZW-TSTAT-300 Advanced Thermostat Operation Guide... - Page 11 Statement of use: 100% compatible with all popular residential HVAC systems; 24 VAC single, two- stage conventional heating systems (gas/oil/electric), heat pumps, single stage or auxiliary heat (electric or fossil), zoned forced air and zoned hot water (two or three wire), millivolt systems (with a 12-24 AC or DC source), one or two stage cooling, and hybrid systems.
- Page 12 IS-ZW-TSTAT-300 Advanced Thermostat Operation Guide...
