Summary of Contents for Reiner cyberJack RFID universal
-
Page 1: Cyberjack Rfid Universal
® cyberJack RFID universal User manual... -
Page 2: Table Of Contents
Mac OS X ................................. 19 Safety notes Support Technical references 7.1 LED functions ....................24 7.2 Technical operating environment ....................25 7.3 Security functions ....................25 7.4 Regulatory Notes ....................27 Declaration of Conformity 8.1 cyberJack RFID universal ....................28 Index... -
Page 3: Foreword
RFID. This state-of-the-art technology simplifies chip-card handling and enables them to be used in many new applications. We wish you great success with your new device REINER SCT Reiner Kartengeräte GmbH & Co. KG Goethestraße 14 78120 Furtwangen Germany www.reiner-sct.com... -
Page 4: Device Description
cyberJack® RFID universal manual Device description How to unpack and install the reader Unpacking The packaging contains ® cyberJack RFID universal Stand Base USB cable Brief instructions on how to install the device Driver CD Depending on the version and the source of supply, the contents may vary or there are additional components in the packaging. -
Page 5: The Functions Of Your Chip Card Reader
After the restart please start the cyberJack Device Manager program, function test in the Start menu under Start > Programs > REINER SCT cyberJack. When the Device Manager starts a registration dialog is displayed to you. We recommend that you make use of the opportunity to register because you will then always be informed about new developments which offer you even more benefit from your ®... - Page 6 . By activating the link Check for new versions your Internet browser is started and a connection to the REINER SCT Download server established. If your browser is not conveniently linked to an RDT connection, please start it manually before checking for new versions. If there are new versions, you can update your system directly.
- Page 7 ® Jack installation data and some important information regarding your PC configuration are determined and sent to REINER SCT by e-mail. A member of our Support team will then contact you by e-mail or telephone. PIN Dialog tab The PIN dialog contains special functions which can be activated and certain special configurations made.
- Page 8 cyberJack® RFID universal manual Acoustic settings (1) Here you can choose whether pressing the key for the PIN input should generate a sound. (2) Tick here and the request for the PIN is given acoustically by a friendly voice. (3) Here you can adjust the display contrast of the chip card reader and hence obtain the optimal setting for reading out the chip card reader display.
-
Page 9: The Function Of Secure Pin Input
Here you can find the registration information you have given as well as a direct link to the home page of REINER SCT where you can find information about new products. If you have not yet registered, you can do it here whenever you like. - Page 10 cyberJack® RFID universal manual Request Secure PIN Request Signature PIN Secure changing of the PIN In order to change the PIN in secure mode the current PIN must first be input. Thereafter the new PIN is input twice. Each PIN input is acknowledged by pressing the [OK key]. The following display screens appear.
-
Page 11: How To Display Revision
The functions of your chip card reader Security function for secure PIN input Secure PIN input is one of the most important security functions of a chip card reader from security class 2 upwards. Secure PIN input is feasible with both a contact-type and a contactless chip card. To ensure that the PIN is not stored in the chip card reader the hardware and the software of the chip card reader have been subjected to strict security-related evaluations. - Page 12 cyberJack® RFID universal manual Sequence of display screens with uploaded application Version screen Chip card reader ID screen (screen show n only if the @ key is pressed) Screen for the uploaded application (screen show n only if the @ key is pressed) Screen for the revision of the uploaded application...
-
Page 13: Module Management
The functions of your chip card reader Module Management It is possible to add new modules to the chip card reader with the aid of the Device Manager (refer to Device Manager chapter). These different modules are grouped together in the Module Store. The Module Store is to be found in the Module Management. - Page 14 The chip card reader only accepts firmware which is electronically signed by REINER SCT by means of the RSA method. Each time before uploading new firmware the chip card reader always performs a signature check.
-
Page 15: How To Switch Off The Rfid Field
Software packages for the application of the electronic signature frequently use the PC/SC interface. The drivers are already incorporated in the operating system. Cash Card Information on potential uses of the cash card are to be found on the Internet at www.reiner-sct.com/ geldkarte-shops. -
Page 16: How To Install The Hardware On The Pc
cyberJack® RFID universal manual How to install the hardware on the PC How to install drivers under Windows This RFID chip card reader is currently supported by the following operating systems: Windows 2000 / Windows XP 32 bits, Windows Vista 32/64 bits / Windows 7 32/64 bits, and Windows Server 2003 –... - Page 17 How to install the hardware on the PC ® ® The installation cyberJack Base Components is absolutely necessary for operating the cyberJack RFID universal chip card reader. They contain the system drivers. Moreover the Device Manager is installed with the device test, driver update and Online support functions. Press the button, [Start installation] in order to begin with the installtion of selected components.
- Page 18 cyberJack® RFID universal manual Select the driver for your chip card reader by clicking on the relevant box. Click on [Continue]. Click on [Continue] if you want to install the program in the displayed folder. If you wish to install the files in a different folder, click on [Change] and select the desired path.
-
Page 19: How To Install Drivers Under Linux
How to install the hardware on the PC In the Windows Start menu a new REINER SCT cyberJack folder is created with the menu items: cyberJack Device Manager, function test, REINER SCT on the Internet, Support Query and Update ACS components. -
Page 20: Description For Debian
1. Please first install the PCSCD driver with the aid of the package management system of your distribution. 2. Then download the up-to-date driver to match your distribution and your processor at www.reiner-sct. com/treiber 3. Install the driver by means of the following command in the terminal input. -
Page 21: Driver Installation Under Mac
RFID universal you need an Internet connection. Do not plug in the chip card reader yet! ® Download the driver for the cyberJack RFID universal at www.reiner-sct.com/treiber and execute the driver file by double-clicking it. You will now be guided through the installation. - Page 22 cyberJack® RFID universal manual Click on the "Continue" button to start the driver installation. Click on the "Install" button". By inputting your user name and password you permit the driver to be installed. Please note that the user must possess the rights for this. Installation of the driver is now complete.
- Page 23 How to install the hardware on the PC ® Now you can plug the cyberJack RFID universal into a USB port on your computer and use it. Functions test: Place the logincard or the new electronic ID card on the connected chip card reader. If the installation is correct the green light-emitting diode (LED) on the chip card reader lights up.
-
Page 24: Safety Notes
cyberJack® RFID universal manual Safety notes Organisational safety measures: Make sure that unauthorised persons do not obtain access to the card reader. The reader must be operated such that abuse is excluded. Make sure that the PC possesses suitable protective measures (such as a virus scanner, firewall) and manipulation by unauthorised persons is prevented. -
Page 25: Support
Service You have purchased a high quality REINER SCT product which is subject to strict quality control. If problems should occur or you have questions regarding how to opeate the device you can always send a support query to our Service department at support@reiner-sct.com... -
Page 26: Technical References
If this is not the case, the device is defective. Please contact our Support at support@reiner-sct.com The light-emitting diodes (LED) can be in the following states:... -
Page 27: Technical Operating Environment
Modules can be uploaded and updated individually, or all together. Uploaded modules do not influence the functionality of the other modules. It is impossible to store a module in the chip card reader which has not been electronically signed by REINER SCT. REINER ®... - Page 28 cyberJack® RFID universal manual The interruption of communication with the PC is software-controlled by means of a lock which ensures that in the Secure PIN input mode no data are transmitted from the memory (PIN data). Only log information is transmitted to the PC which is always transferred directly to the hardware interface in the form of constants.
-
Page 29: Regulatory Notes
® memory) is implemented in the cyberJack RFID universal . This means that the chip card reader never accesses memory areas not permitted by Reiner SCT. Regulatory Notes Radiofrequency radiation exposure Information The radiated output power of the device is far below the FCC radio frequency exposure limits. -
Page 30: Declaration Of Conformity
RFID universal manual Declaration of Conformity cyberJack RFID universal... -
Page 31: Index
Index - D - Deactivate RFID Declaration of Conformity Device Manager Driver installation Debian Linux .rpm Ubuntu Windows - F - Firmware download - L - function - P - Product seal - S - Safety notes Seal Secure changing of the PIN Secure PIN input 7, 25 Support... - Page 32 REINER Kartengeräte GmbH & Co. KG Goethestrasse 14 78120 Furtwangen Germany Phone: +49 (7723) 5056-0 Telefax: +49 (7723) 5056-778 E-Mail: sales@reiner-sct.com Internet: www.reiner-sct.com...
