Summary of Contents for Q3 Innovations AlcoHAWK Precision
- Page 1 Owner’s Manual © 2010 Q3 Innovations v022510...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Intended Use Overview Effects of Alcohol PREPARATION Installing the Battery Inserting a Mouthpiece COMPONENTS DIAGRAM OPERATION READ THE RESULTS ERROR MESSAGES PRECAUTIONS SPECIFICATIONS ACCESSORIES CALIBRATION WARRANTY DISCLAIMER... -
Page 3: Introduction
INTRODUCTION Intended Use This breath alcohol tester is intended to measure alcohol in human breath. Readings from this device are used to determine alcohol intoxi- cation. The accuracy of this device has been proven at a Blood Alcohol Concentration (BAC) of 0.008 and 0.032. Accuracy at a BAC greater than .032 has not been established. - Page 4 Dose-Specific Effects Generally no loss of coordination. Slight joy or loss of shyness. 0.020-0.039% Depressant effects are not clear. General feelings of well-being, relaxation, shyness is reduced and 0.040-0.069% sensation of warmth. Joy. Some minor impairment of reasoning and memory. Lowering of caution. Driving skills may be impaired. Slight impairment of balance, speech, vision, reaction time, and hearing.
-
Page 5: Preparation
PREPARATION Installing the Battery Apply a small amount of pressure on the battery cover located on the back of the unit and push down and away from the unit to release the cover. Use only 9 volt alkaline batteries. See the following diagram. BATTERY COVER 9 VOLT... -
Page 6: Inserting A Mouthpiece
Inserting a Mouthpiece Insert the mouthpiece firmly into the hole located on the top of the left side of the unit. A gap of approximately 1/2 cm will remain between the larger portion of the mouthpiece and the side of the unit. See diagram below. -
Page 7: Operation
OPERATION Operating Instructions Wait 20 minutes after the subject smokes, eats or drinks before testing. Failure to wait 20 minutes can give inaccurate BAC read- ings and harm the sensor. Step 1) Insert a NEW MOUTHPIECE each time you perform a test. Step 2) If it has been more than 24 hours since the device was last used, PRIME THE SENSOR by blowing into the mouthpiece for 4 to 5 seconds before turning on the device. -
Page 8: Read The Results
Step 6) For more testing, wait one (1) minute and repeat steps 1 – 5. READ THE RESULTS The result is an estimate of the subject’s BAC. A breath alcohol tester cannot determine the exact BAC in the blood of the subject. Correlation between BrAC and BAC depends on many factors, such as temperature and health conditions. -
Page 9: Precautions
The sensor has been damaged and will need to be returned for servicing. If this error message occurs more than two consecutive times, please contact Q3 Innovations for instructions to have your unit serviced. PRECAUTIONS 1. Wait at least 20 minutes after drinking, smoking or eating before testing. -
Page 10: Specifications
7. Avoid testing in the presence of any liquids that contain any kind of alcohol or acetone. They may interfere with the results of the test. 8. Conditions that increase the amount of ketones on the breath, such as diabetes and low caloric intake, may cause a false positive test. (i.e., showing a non-zero reading despite not drinking alcohol) 9. -
Page 11: Accessories
Please visit www.q3i.com or call 888-399-1687 for calibration or support. ONE-YEAR LIMITED WARRANTY Q3 Innovations (Q3I) warrants this unit to be free from defects in workmanship or material (excluding calibration) under normal use for ONE (1) YEAR from the date of retail purchase by the original buyer... -
Page 12: Disclaimer
The warranty covers parts and labor on covered repairs and ground freight back to the customer (USA only). Except as pro- vided above, Q3I provides this product “as is.” If a defect arises and Q3I receives a valid claim within the War- ranty Period, at its option, Q3I will either (1) repair the product, (2) exchange the product with a product that is new or which has been built from new or serviceable used parts and functionally... - Page 13 alcohol including whether the test subject is intoxicated, under any definition of that word. Q3I expressly disclaims any liability for incidental, special, or consequential damages of any nature under any legal theory. Any act or failure to act based upon a reading from this product is at the test subject’s or user’s own risk.
- Page 14 TO THE REPAIR OR REPLACEMENT SERVICE AS DETERMINED BY Q3I IN ITS SOLE DISCRETION. Q3I does not authorize any Q3I reseller, agent, or employee to make any modification, extension, or addition to this warranty. If anyone deter- mines any terms to be illegal or unenforceable, the legality or enforce- ability of the remaining terms shall not be affected or impaired.
- Page 15 DO NOT DRINK ALCOHOL AND DRIVE ALWAYS USE A DESIGNATED DRIVER AFTER DRINKING ALCOHOL BE SAFE AND DRINK RESPONSIBLY...
- Page 16 Q3 INNOVATIONS Personal Safety and Monitoring Devices 2349 Jamestown Ave., Suite #4 • Independence, IA 50644 Tel: 888-399-1687 • Fax: 319-334-3421 Sales Email: sales@q3i.com • Service Email: service@q3i.com www. .com © 2010 Q3 Innovations v022510...
