Summary of Contents for Technoprint Techno-HA-06
- Page 1 Forced Air Convection Oven USER MANUAL Version 2.01...
-
Page 2: Important Safety Rules Forced Air Convection Oven
IMPORTANT SAFETY RULES FORCED AIR CONVECTION OVEN Prevention of fire: When the reflow-oven is in production it’s illegal to leave the reflow oven unattended , high temperature and long producing times can be overheat the reflow-oven what can lead to fire. This reflow-oven is developed to install it on a flat foundation and not for build in a cupboard or box. - Page 3 Prevention of an electric shake; The casing may never be opened or removed, take care that there are never be liquids or other materials in the door latching or ventilation grate. Switch off the reflow-oven immediately, pull the plug out of the wall socket and ask the supplier what to do. Don’t put the plug and the line cord not in water or other liquids Don’t leave the line cord over the edge of a table, don’t leave the line cord on a warm foundation and don’t leave the line cord at the backside of the reflow-oven.
-
Page 4: Connection And Power
1. CONNECTION AND POWER: The oven is to be installed on a heat resistant floor/background. To power oven, fit main plug of minimum 10 Amp. When power is switch on, (switch A on the front of the control panel) the oven will be start of preheat temperature. - Page 6 TECHNO- HA-06 REFLOW SOLDER OVEN WITH INERT GAS CONNECTION When you want to run the solderoven HA-06 with inert gas, be sure that you are working with non toxic or non explosive gas! The flowmeter on the solder oven has a scale for air/nitrogen, working with other gases will only indicate a flow but not read out accurate data.
- Page 10 Tel. : 0341 563026 Fax.: 0341 563027 E-mail: info@technoprint-smt.nl www.technoprint-smt.nl Technoprint as stated above, herewith declares that: FORCED AIR CONVECTION REFLOW OVEN MODEL: HA-06, HA-08 are in compliance with the machinery directive (89/392/EEC, as amended, 91/368/EEC,93/44/EEC, 93/68/EEC); are in conformity with the provisions of the following other EEC directives;...
- Page 11 SPAREPART LIST HA-06 Art. nr. Article 100168 Base print, complete 100169 Display-print complete 100170 Doorswitch SS-5 GL11 100171 Glass HA-06 100173 Halogen lamp R7S/1000W. 100175 Rail, set of 2, HA-06 Thermocouple, ± 300 mm. 100177 100207 Motor + fan HA-06 100346 Heating element...
