Page 1: User Manual
CREATOR Electronics Digital Conference System Digital Conference System User Manual Please read this manual carefully before using this product... - Page 2 NOTICE The Professional Digital Conference System User Manual provides reference for the models of CR-M4101 / CR-ME4000/CR-M4102 / CR-M4104 / CR-M4103E3 /CR-TP4102/ CR-IR2000-12 / CR-IR1001-15/ CR-IR2001-12 / CR-IR2002-12 / CR-V101 ﹡ / CR-T1000.It is only an instruction for operators, not for any maintenance usage.
- Page 3 Safety Operation Guide In order to ensure the credibility use of the product and the user’s safety, please comply with the following items during installation and maintenance: The system must be earthed properly. Please do not use two blades plugs and ensure the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
Index 1. Digital Conference System Introduction ..............1 About this system ........................1 Features of DCS........................1 2. DCS controller......................2 Product Instruction ......................... 2 Front Panel ............................... 2 Volume ——Adjust the master volume from 1, the minimum, to 6, the maximum........2 Rear Panel .............................. - Page 5 Features ..............................15 CR-M4102/4F ...........................16 Features ..............................16 Diagram ..............................17 Features ..............................17 CR-M4102/4D2 ........................18 Features ..............................18 Diagram ..............................19 Features ..............................19 CR-TP4102D ..........................20 Features ..............................20 Features ..............................23 Diagram ...........................24 Technical Parameter .......................25 4. DCS Simultaneous Interpretation ................27 CR-M4103E3 ........................
- Page 6 MVC-4200 Camera auto-tracking Controller .................37 Features: ..............................37 Technical parameter..........................38 CR-V1011/V1012 High-speed autodome................39 Features: ..............................39 Technical parameters: ..........................39 System diagram ........................40 7. DCS Telephone conference module............... 41 Instruction ..........................41 Features: ..........................41 Panel diagram .........................41 Technical parameters: ......................42 System diagram ........................42 8.
-
Page 7: Digital Conference System Introduction
About this system DCS (Digital Conference System), central control system and matrix switcher system are 3 most important product lines of CREATOR Electronics. It consists of the function modules as contribution, simultaneous interpretation, IR language distribution, telephone conference, voting and video tracking. -
Page 8: Dcs Controller
The modular system can be easily expanded by putting in the proper functional module. When adding in a voting unit, it becomes a voting conference system; when adding in the camera tracking module, it becomes a simultaneous A/V conference system. DCS controller Product Instruction CR-M4101 controller CR-ME4000 extender CR-M4101... -
Page 9: Rear Panel
Rear Panel ① IN ——It is the audio-in connector to input the audio signal like background music ② OUT 1——It is the audio-out connector to output the audio signal to amplifier or audio recorder. OUT 2——It is the audio connector to output the audio signal to telephone conference. ③... - Page 10 FIFO mode can automatically control the active microphones. Working with the telephone coupler, it can open a telephone conference with remote user 10 Cooperating with the central control system, it becomes a powerful conference controller and achieves the super function of camera auto-tracking. 11 Support voting and data managing。...
-
Page 11: Cr-Me4000
CR-ME4000 Front Panel: POWER and power indicator ① ACTIVE indicator ② NETWORK indicator ③ COMMUNICATION indicator ④ Rear panel: ID ——ID Setting ① DELEGATES——It is the interface to the contribution units. There are 3 channels to access the ② system, and each can link to not more than 64 contribution units in hand in hand daisy-chain. There is no limitation for the chairman unit. -
Page 12: Technical Parameter
Technical Parameter Technical Parameter CR-M4101 CR-ME4000 Power supply 100-240V 100-240V Static consumption Nominal power consumption 350W 350W Output power ≤110W/24V ≤110W/24V Impedance:100 Impedance:100 Audio output mode:unbalanced mode:unbalanced Impedance:100k Impedance:100k Electriclevel:-60dB Electriclevel:-60dB MIC input mode:unbalanced mode:unbalanced Frequency response 60－8kHz 60－8kHz (S/N) >... -
Page 13: Dcs Speaking Unit
3. DCS Speaking Unit Product Instruction Model Name Externality MIC Key Voting Channels Switch CR-M4104A1 Delegate Unit Fold-away √ × × × CR-M4102A2 Chairman Unit Fold-away √ √ × √ CR-M4104A2 Delegate Unit Fold-away √ √ × × CR-M4102B Chairman Unit Table-Top √... -
Page 14: Cr-M4104A1
CR-M4104A1 Features ① Microphone: Pluggable, easy to transport and maintain ② MIC button: Press it to open the microphone and repress it to close the microphone. ③ Build-in flat panel loudspeaker: It will automatically mute while the microphone opens. ④ Earphone jack: Install and connect the earphone for DCS here. ⑤... -
Page 15: Diagram
Diagram CR-M4102/4A2 Features: CR-M4102A2 Front View CR-M4104A2 Front View Side View ① Microphone: Pluggable, easy to transport and maintain Multi voting buttons ② ——For/against: buttons 2/3/4 stand for For/Abstain/Against, respectively. ——Multiple election: buttons 1/2/3/4/5 can stand for different candidates, respectively. ——Evaluation Poll: buttons 1/2/3/4/5 stand for 5 level ――/－/0/＋/＋＋, from low to high. -
Page 16: Features
Then, the delegates should press the button 1 to confirm and start voting. Their last choice on the buttons will be considered as their final decision and will be indicated by the button indicator. When the conference holder press the STOP button on the chairman unit, the voting is finished and all the contribution units will sound “Du”... -
Page 17: Cr-M4102/4B
CR-M4102/4B Features CR-M4102B Front View CR-M4104B Front View Rear View ① MIC jack ② PRIOVITYKey ③ POWER ④ MIC ON/OFF ⑤ MIC indicator light ⑥ Build-in loudspeaker ⑦ Volume adjustment ⑧ Earphone jack ⑨ Link jack ⑩ Cable Features 1, voting function integrated. 2, 8-pin aviation connector 3. -
Page 18: Diagram
Diagram CR-M4102/4E Features Side View Front View Side View D I G I TA L C O N F E R E N C E S Y S TE M D I G I TA L C O N F E R E N C E S Y S TE M D I G I TA L C O N F E R E N C E S Y S TE M D I G I TA L C O N F E R E N C E S Y S TE M Rear View... -
Page 19: Features
⑥ Volume adjustment ⑦ Cable ⑧ Link connector Features 1, voting function integrated. 2, 8-pin aviation connector 3. Pluggable unidirectional microphone with red ring indicator. 4, 2M cable for each unit 5, Knob pin MIC pole 6, Build-in flat panel loudspeaker and earphone jack with excellent audio quality and adjustable volume control. -
Page 20: Embedded Unit
Embedded Unit Features CR-M4102C1Front View CR-M4104C1Front View 1 29 mm 12 9 mm C REATOR CREATOR MIC /BREA K CR-M4102C4Front View CR-M4104C4Front View 1 29mm 129 mm CREATOR CREATOR CR-MC4032B/CR-MC4034B 1 21 .0 mm 2 4 .5 m m ① MIC jack ②... -
Page 21: Diagram
“Du” in a same time. Pressing button 4 for 2 seconds, to return the normal discussion status. ⑤ NEXT——connect to next audio box ⑥ LINK——connect to CR-M4101/NEXT ⑦ MIC——connect to CR-M4102/4C1 VOTE——connect to CR-M4102/4C4 ⑧... -
Page 22: Cr-M4102/4F
CR-M4102/4F Features CR-M4102 Front View CR-M4104F Front View ① MIC jack ② LCD displayer ③ Earphone jack ④ MIC on/off ⑤ Multi voting buttons “1，2，3，4，5” ——For/against: buttons 2/3/4 stand for For/Abstain/Against, respectively. ——Multiple election: buttons 1/2/3/4/5 can stand for different candidates, respectively. ——Evaluation Poll: buttons 1/2/3/4/5 stand for 5 level ――/－/0/＋/＋＋, from low to high. -
Page 23: Diagram
Diagram Features 1, 8-pin aviation connector 2, Pluggable unidirectional microphone with red ring indicator. 3, 2M cable for each unit 4, Knod pin MIC pole 5, Earphone jack 6, IC card registration 7, voting function integrated. 8, Chairman Unit can cut the microphone of delegate units at any time to manage and control the whole conference conveniently 9, Chairman Unit has the function to approve or deny the talking request from delegate units. -
Page 24: Cr-M4102/4D2
CR-M4102/4D2 Features CR-M4102D2 Front View CR-M4104D2 Front View SideView ① MIC jack ② Multi-function voting key ——Conference vote, three buttons denote approve, disclaim and oppose ——election: 5 buttons means different candidates ——conference evaluate 5 buttons means “――、－、0、＋、＋＋” level Long press the number 1 button of chairman unit to start vote, there would be a sound to NOTICE: confirm. -
Page 25: Diagram
Content of LCD MODEL M4102D M4104D MODE Number of Voting man Conference Reveal DCS Delegate Max number of speaking man Tips when voting Process voting voting Result when finish voting Show the result Diagram Features 1, There are 5 multi-function buttons to process voting. 2, Chairman Unit’s LCD can show all the information about result of voting and sign in, number of voting man etc. -
Page 26: Cr-Tp4102D
CR-TP4102D Features Microphone: pluggable, easy to transport and maintain 3.5” LCD screen MIC button: press it to open the microphone and repress it to close the microphone ——Cut off the delegate’s speaking temporarily， ——Cut off the delegate’s speaking Priority： NOTICE Screen——Press ，screen the delegates speaking temporarily, release it to return normal. - Page 27 Touch Panel Instruction: Meeting mode Meeting mode: Image adjust and Information Double click the video window; it will turn to full screen. Single click to return. PIP： ： ： ： Go with camera to achieve auto tracking, the picture in LCD is the same as that of cameras. Also it can display the video signal from other devices connected to the CR-MV200.
- Page 28 Information Note： ： ： ： Show the max attendees set in the conference host and the number of speakers F3-3 Voting mode Voting mode: In this mode, user can choose “Approve, Abstain, and Oppose”, start voting and end it, then see the result. When the voting begins, all delegate units will beep which means they are ready for voting.
-
Page 29: Features
For example, now we set the language of the operation interface to English, shutdown, and then start up, the displaying operation interface will be English. ID Setting Switch the ID set “ON” behind CR-M4101 controller, page 3-7 will be displayed. After setting, switch it off then the system turns to “Meeting mode”，... -
Page 30: Diagram
12, clearly earphone output and digital attunement technology and professional DSP chips and timbre improve circuit, 13, EQ technology adopted ensures quality voice output. Diagram... -
Page 31: Technical Parameter
Technical Parameter parameter CR-M4102/4A CR-M4102/4B1 Power supply DC24V( host power) DC24V( host power) Prot DIN 13P/8P DIN 8P Power consumption Earphone output 9dBu，8－32 ，3.5mm 9dBu，8－32 ，3.5mm Loudspeaker power Transducer type Electrets condenser Electrets condenser Directional pattern Cardioids Cardioids (S/N) > 80dB >... - Page 32 parameter CR-M4102/4C1 CR-M4102/4C4 CR-M4102/4D2 CR-TP4102D DC24V Power (host power) DC24V(host power) Prot RJ45 DIN 13P/8P Power consumption Earphone 9dBu，8－32 ， output 3.5mm × 9dBu，8－32 ，3.5mm Loudspeake power × × Transducer type × × Electrets condenser Directional pattern Cardioids × Cardioids (S/N) >...
-
Page 33: Dcs Simultaneous Interpretation
4. DCS Simultaneous Interpretation CR-M4103E3 Features CR-M4103E3Front View Side View ① Volume adjust ② Earphone volume adjust ③ Build-in loudspeaker ④ IN——Input channel select ⑤ OUT——Output channel select ⑥ FLOOR-RELAY——floor and relay switch ⑦ MIC ON/OFF ⑧ COUGH——Cough prevention ⑨ A、B——Channels shortcut keys,Long press 3s to be confirmed. ⑩... -
Page 34: Setting Menu
00:00 TIME: English English 04: chi ① Input channel ② Output channel ③ Channel A and its lanuage ④ Channel B and its lanuage ⑤ Channel a and its lanuage ⑥ Channel b and its lanuage ⑦ Input language ⑧ Output language ⑨... - Page 35 2.1、CH MAP setting See F4.4,circumgyrate “OUT SELECT”to“CH MAP”，press “ENTER” OUT SET CH MAP P a s s W o r d EXTT F4.4 Circumgyrate “OUT SELECT”to set CH TOTAL, MAX12 channels. CH MAP Total: F4.5 Choose“ENTER”to set channel and languages, 63 different languages can be choosed, see F4.6 CH MAP English F4.6...
-
Page 36: Monitor Unit
Total Call Room Spanish F 4.16 Features Earphone and monitor integrated 8-pin aviation connector Capacitance MICwith twin color indicator. 2M cable itself Knob pole Build-in loudspeaker, earphone jack, volume adjust. CR-M4101 controller supports 36 interpreter units and 12 languages simultaneously... -
Page 37: Techinical Parameter
interpretation at a same time including the floor one. Direct or indirect interpretation available. Interpretation units can be made of interpretation system.Interlock channels ensures that each output channel can carry only one language at one time. 10. Help press 11, Cough prevention 12 Can change the interpreter unit to monitoring unit. -
Page 38: Dcs Ir Language Distribution System
5. DCS IR Language Distribution System Product Description CR-IR2000-12 IR Language Distribution System transmitter controller CR-IR2001-12 IR Language Distribution System Radiator unit CR-IR2002-12 IR Language Distribution System Receiver unit CR-IR2000-12 IR Language Distribution System Transmitter Controller Destription: ① POWER ② Input channel indicators: Indicates the working channel from 1 to 6 in red and from 7 to 12 in green. -
Page 39: Cr-Ir2001-12 Ir Radiator Board
CR-IR2001-12 IR Radiator board Function: ① LOW/HIGH ——power magnitude selector for IR radiation ② IN ——the interface to connect the SINGAL OUTPUTS of the transmitter host or the ’OUT’ of the radiator board. ③ OUT ——connect with next ‘IN’. ④ POWER INPUT——support with AC100V~240V input. ⑤... -
Page 40: Cr-Ir2002-8/12 Ir Receiver Unit
CR-IR2002-8/12 IR Receiver unit Function: ① Volume knob for adjustment ② Earphone (3.5mm), connect with the monitor earphone. ③ IR receiver window. ④ Power switch button. ⑤ Display monitor, display language channel. ⑥ POWER——Power indicator. The indicate light is green and always on when starting up, but it will wink red when the battery is low. -
Page 41: Parameters
Parameters: IR language distribution system Model CR-IR1002-6 Model CR-IR1000-6 Power supply 100-240V Power supply AAA NIMH rechargeable battery Power Receiving 2M-20MHz ， 40KHz channel consumption 25W （selectable） frequency separated Intermediate Crystal Crystal control frequency 10.7MHz Modulation PPL, narrow band Modulation Nominal Carrier wave... -
Page 42: System Diagram
Frequency response 20~10KHz Am restraint > 45dB 50mV-1.5V Maximum sound Input Sensitivity pressure level 110dB Frequency RF output 2 BNC, 100mV RMS response 20~10KHz output impedance Distortion <1.5% Dimension 483L *344W* 88H (mm) Dimension 105L *50W * 19H (mm) Weight Weight 0.15KG Color... -
Page 43: Dcs Camera Auto-Tracking Controller
6. DCS Camera auto-tracking Controller Instruction MVC- 4200 Camera auto-tracking System CR-V1011/V1012 high-speed preposition autodome MVC-4200 Camera auto-tracking Controller Function: CREATOR S YST EM M ON ITOR PO WER ACT IVE /SAVE /R E CAL L CAMER A AUTOMATIC FOLL OW SYS TEM ①... -
Page 44: Technical Parameter
Technical parameter Model MVC-4200 Specifications VIDEO Plus 0 dB 150MHz (-3dB),loaded Bandwidth 0 -10MHz:≤+/- 0.1dB 0 -30MHz:≤+/- 0.5dB Sum Disturb -50dB @ 5 MHz, -45dB @ 10 MHz I/0S <1.28，3.58MHz I/OS lost 0.1%, 3.58-4.43MHz I/OS plus lost 0.1, 3.58-4.43MHz MAX transfer delay 5nS(±1nS) Switch speed 200 ns(MAX TIME) -
Page 45: Cr-V1011/V1012 High-Speed Autodome
CR-V1011/V1012 High-speed autodome Features: There are 2 kinds of autodome video camera designed for ACS，They have same functions and performance but different outline and installation design. One is ceiling camera installed on the ceiling and the other is wall mounted camera installed by the wall. -
Page 46: System Diagram
Focus Auto/menu Horizontal 0～300°/s movement Vertical movement 0～60°/s Pan/tilt Preposition 128 at most performance Patrol observation Up to 6 patrol tracks Line scan speed 0.5～30°/s Track self-study 40 seconds System diagram... -
Page 47: Dcs Telephone Conference Module
7. DCS Telephone conference module Instruction CR-T1000 Telephone coupler Features: ■Connecting to the conference discusses system and the simultaneously interpretation system to hold the telephone meeting. ■Connecting to the telephone line can immediately convene a telephone meeting ■Spread conference audio to far away place telephone. ■Audio input port, connect to the conference system and let more people intend the telephone meeting. -
Page 48: Technical Parameters
Technical parameters: Model CR-T1000 Power supply 100-240V Power consumption Impedance of telephone line-in Impedance: 100 Input audio Level: ＋4dB Unbalanced Impedance: 600 Output audio Level: ＋4dB Unbalanced Frequency response 60－8KHz Distortion <0.1% > 80dB Color Gray System diagram... -
Page 49: Accessaries
8. Accessaries CR-P2 Headphone No Microphone Features: Listening in the conference. Working with interpreter units or CR-IR1002-6 IR receiver units. Build-in 1.5 meter cable. Hi-fi audio quality. Technical parameters: Model CR-P2 Interface 3.5mm stereo connector Frequency response 80Hz – 2KHz Sensitivity 90dB >... -
Page 50: Cable
Cable Instruction: CR-HL 005 5M 8-pin Aviation cable CR-HL 010 10M 8-pin Aviation cable CR-HL 020 20M 8-pin Aviation cable CR-HL 050 50M 8-pin Aviation cable CR-HL 100 100M 8-pin Aviation cable Features: CR-HL* is used as the expand connection between the conference host and the expand host or the conference delegate unit. -
Page 51: Cr-Ct20 Socket
CR-CT20 socket Features one front UNIT input ■ two output::UNIT A UNIT B connect to ■ speaking unit Be fit for desk and wall-installed. ■ CR-CT30 socket Features One front UNIT input ■ Two output::UNIT A UNIT B connect to ■... - Page 52 Digital Conference System CREATOR Form: A0 [XX] 10 00 07 [YY] FF FF FF AF [ZZ] Specification: [XX]、 [YY] and [ZZ] are all hexadecimal, and [YY] stands for ID code.[ZZ]=FFFF-([XX] +10+00+07+ [YY] +FF+FF+FF) Arithmetic: [ZZ] =FFFF-([XX] +10+00+07+ [YY] +FF+FF+FF), get the low bit from the result. Delegate unit set number form number 2, ID code form number 1, and progressive increase.
