Blumax Speech 002 User Manual

En
Bluetooth Hands-Free Speakerphone
Speech 002

User Manual

Introduction:
Thank you for your interest at our Bluetooth car kit.
This car kit is a wireless Bluetooth kit based on the
Bluetooth technology that allows you to making and
talking calls without touching your mobile phone.
Read this user guide carefully before using the car
kit. Read also the user guide for your phone, which
provides important safety and maintenance informa-
tion. Keep the car kit out of reach of small children.
Bluetooth wireless technology.
Bluetooth wireless technology makes it possible to
connect compatible communication devices without
using cables.
A Bluetooth connection does not require the devices
to be in line of sight, but both devices should be with-
in 10 meters (30feet) of each other. Connections can
be subject to interference from obstructions.
The car kit is compliant with Bluetooth Specifi cation 2.0.
There may be restrictions on using Bluetooth tech-
nology in some locations. Check with your local au-
thorities or service provider.
Get started
Overview
1 - MUTE
2 - LED display
3 - MIC input
4 - Multi-function Button (MFB)
5 - Volume+ button
6 - Volume – button
7 - Mini USB 5 PIN for the charging socket
8 - Speaker
2
1
4
5
6
7
8
Before you start using the car kit, you must charge
the battery and pair the car kit with a compatible mo-
bile phone.
Charger
This car kit is intended to use with the car charger
that is included in the package.
Charge the battery
This device has a Rechargeable Lithium Polymer
battery 3.7 V, 820 mAh battery.
1. Connect the car kit to the car charger. The red
indicator light is displayed during charging. If
charging does not start, disconnect the charger,
pug it again, and retry. Charging the battery fully
may take up to 2-3 hours.
2. When the battery is fully charged, the red indica-
tor light turns off. Disconnect the car kit from the
charger.
The fully charged battery has power for up to 4 hours
of talking time or up to 30 days of standby time. How-
ever, the talking and standby time may vary when
used with different mobile phones, products that use
a Bluetooth connection, usage settings, usage styles,
and environments.
Switch on and off the car kit
To switch on, Press and hold the „MFB" multi-function
button until there is a tone prompt and the blue LED
fl ashes 5 times. The car kit is now on.
To switch off, press and hold the „MFB" for 4 seconds
until the red LED fl ashes 5 times.
Pair the car kit with a compatible phone
1. Make sure your car kit is switched off.
2. Press and hold the „MFB" until the blue and red
light fl ashes alternately and there is a tone prompt.
The car kit is now in pairing state.
3. Activate the Bluetooth feature on the phone, and
set the phone to search for Bluetooth devices. See
3
the user guide of your phone for instructions.
4. Select the car kit (Speech 002) from the list of
found devices.
5. Enter the pass code 0000 to pair and connect the
car kit to your phone. In some phones you may
need to make the connection separately after pair-
ing. See the user guide of your phone for details.
You only need to pair the car kit with your phone
once.
If the pairing is successful, the car kit's blue light will
fl ash 3 times briefl y. The car kit's name appears in
the phone menu where you can view the currently
paired Bluetooth devices.
Basic use
Call handling
To make a call, use your phone in the normal way
when the car kit is connected to your phone. And the
blue LED will fl ash during the call.
To answer a call, press the "MFB" and the blue LED
will fl ash during the call.
To reject a call, press the "MFB" for 2 second and
there is a tone prompt when there is incoming call.
To end a call, press the "MFB" one time.
In standby state, press the volume+ key for 2 sec-
onds to redial last dialed telephone No. This function
requires your phone supports redialing.
In standby state, press the "MFB" to start voice dial-
ing. This function requires your mobile support voice
dialing. Check the user manual of your mobile for
details.
Adjust the volume
Press volume+ or volume- key to increase or to de-
crease the volume during a call.
Mute
During a call, press and hold mute button for about
2 second to mute the MIC, the same operation to
withdraw from the MIC mute state.
Main specifi cations:
• Bluetooth V2.0+EDR, Class II
• Operating Frequency Band: 2.4 GHz ~ 2.48 GHz
unlicensed ISM band
• Working distance: up to 10 meters
• Integrated with echo cancellation and Noise sup-
pressor
• Built in speaker and microphone
• Rechargeable Lithium Polymer Battery
3.7 V, 820 mAh
• Charging time: about 2-3 hours
• Talk time: about 4 hours
• Standby time: about 30 days
• Dimensions: 128 x 59 x 20 mm
• Pack included: Car Charger, User Manual, Li-ion
Batterie
LED indicator status:
Switch on: The blue LED fl ash fi ve times
Blue LED fl ashes once every
Standby state:
3 sec.
Blue LED fl ashes once every
Connecting status:
3 sec.
Making & answering a Call: Blue LED fl ashes
Call: Blue lights fl ashing fast
Low battery warning: Red LED always on
Switch off: Red LED fl ashes fi ve times
Red LED always on and
Charging state: it will be off after charging
completed
Bluetooth Hands-Free Speakerphone
