Charging Battery; Led Indicator; Pairing With Bluetooth Xl Sound Box; Answering Calls - Itek I58011 Instruction Manual

INSTRUCTIONS FOR USE

CHARGING BATTERY

For best results, fully charge the unit before first use.
Connect the USB cable (included) to the charging port of the speaker and insert the other end
into a USB port on your computer or other suitable USB outlet.
The LED indicator will turn on, indicating that the battery is charging. It will take 3-4 hours for
the battery to fully charge.

LED INDICATOR

There is an LED light located in the middle of the front speaker.
LED Off - Power OFF
Flashing BLUE - Power ON
Flashing BLUE/RED - Pairing mode (searching Bluetooth devices)
RED (While in use) - Low Battery Level
BLUE - Battery almost drained
RED (While Charging) - Battery is recharging
Turn the speaker to Bluetooth pairing mode -
1.Turn the main power switch on the back of Bluetooth XL Sound Box to "ON" position.
2.Wait 2~3 seconds until the LED indicator starts blinking red and blue.
This indicates that it is in pairing mode.
3. If the unit doesn't get into "Pairing" mode by itself, press the "Play / Pause / Answer / Hang
Up" button, for 2-3 seconds. This will put the unit in "Pairing" mode.
Note:
Bluetooth XL Sound Box will stay in "Pairing" mode for 1 minute. If the source device (like cell phones,
tablets, MP3 players etc.) are not synced to the unit within 1 minute, simply turn the unit "OFF" and then turn
it back "ON", and repeat step 2 or 3.
PAIRING YOUR DEVICE with Bluetooth XL Sound Box –
Your Bluetooth XL Sound Box can wirelessly stream audio from any Bluetooth enabled device
within 33 Feet. Simply follow the below steps.
1.Turn on the Bluetooth on your Mobile Phone or Tablet or Computer etc.
2.It will search for various devices
3.Bluetooth XL SOUND BOX will show up as "SPEAKER"
4.Select "SPEAKER"
5.Once paired, the LED light will turn to BLUE Color.

ANSWERING CALLS

While Connected Through Bluetooth Technology
When you receive an incoming call, Bluetooth XL Sound Box will make an alerting sound.
If you are listening to music from your phone, the music will automatically pause.
There're 2 ways to answer a call:
(a)as you usually do, using your phone
(b)press the "Play / Pause / Answer / Hang Up" button located at the top of the unit.
•Speak normally, in to the unit (as unit has a microphone built-in).
Note:
Answering calls will only function while the unit is connected through Bluetooth technology.
OTHER CONTROLS (When Connected Through Bluetooth Technology)
• Volume Increase: Press and hold the "Increase Volume / Skip-Forward" button to increase
the volume.
• Volume Decrease: Press and hold the "Decrease Volume / Skip-Backward" button
to decrease volume.
• Skip Forward Track: Press the "Volume Increase/Skip-Forward" button once to skip a track
forward.
• Skip Backward Track: Press the "Volume Decrease/Skip-Backward" button once to skip a
track backward.
• Pause – Press the "Play / Pause / Answer / Hang Up" button once to pause the music. Press
again once to resume the music.
• Answer Call – Press "Play / Pause / Answer / Hang Up" button once to answer the call when
you get the incoming call.
• End Call – Press "Play / Pause / Answer / Hang Up" button once to end the call. If you were
listening to music prior to receiving the call, then the music would resume once you
end the call.
Note:
Answering calls will only function while the unit is connected through Bluetooth technology.
Auxiliary Mode
•You can play music using the 3.5mm Audio Connection Cable (Auxiliary Cable). Plug one end of
the cable to the source device (Laptop, Tablet, Mobile phone, MP3 Player etc.) and the other end
to the Bluetooth XL Sound Box.
Note: While using unit in this mode, all the media controls (Skip Backward / Skip Forward etc.)
will remain with the source device.
Microphone function doesn't work in Auxiliary mode.
DO'S AND DON'TS
Do not play music at excessive levels as damage to hearing and/or equipment may result.
Do not use outdoors in wet or in damp surroundings.
Problem Possible Cause
Unable to detect the Speaker Battery too low.
source through Source device's Bluetooth function
Bluetooth not turned ON.
Low sound level Source (Tablet, Phone,.) volume too low.
Speaker volume too low.
Battery dead
Sound distorted Battery nearly dead
Source (Tablet, Phone, Laptop.) turned off.
Speaker turned off.
No sound at all. Volume turned down on speaker / source.
Media paused on source.
Solution
Charge speaker battery.
Turn Source device's Bluetooth
function ON.
Adjust source volume.
Adjust speaker volume.
Charge Battery.
Charge Battery.
Turn the source on.
Turn the speaker on.
Adjust volume on speaker /source.
Play media from source.
