TOUCH LIGHT™ Thermostatic On/Off Remote Control
INSTALLATION AND OPERATING INSTRUCTIONS
This wireless thermostatic on/off/ remote control – system provides a safe, reliable, and user-friendly remote control
for millivolt valve gas appliances. The system can be thermostatically or manually turned on and off with the
transmitter. Always check the appliance home owner's manual for additional information, or warnings regarding
accessory installation before connecting this remote control system.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the
dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good
condition. Please keep this booklet for future reference.
Touch Light Transmitter
Battery Alkaline AA (for Transmitter and receiver)
Receiver (Assembly) consists of :
Receiver Box
Slide Button-Black (On/RS/Off)
L-Bracket (Floor Mount)
Wall Cover Plate-Black
Wall Cover Plate-White
Slide Button-White (On/RS/Off)
Screws (for Wall Cover Plate)
Plug-In Wiring Assembly – 18" Inches
Velcro (Loop and Hook)
Wall Anchor Screws
Wall Anchor
Installation Instructions
Screws (for fireplace system control covers)
Wall Bracket
Contemporary Ergonomic Table Top or Wall Mount Transmitter with Large LCD Display
Easy Access Thermostatic Control
Battery Powered Transmitter and Receiver
Easy Access Battery Door
Pre-Programmed for Quick Installation
Low battery Indication
Child Proof Lock-out
16 Security Codes
2 hour Shut Down (Optional)
Thermal Safety Shutdown (Transmitter Only)
Quick Disconnect Wiring Assembly
Reset Button
50D0093 Rev 3 May 2005
TLT
CONTENTS OF KIT
Description
FEATURES/SPECIFICATIONS
WARNING
Page 1 of 11
Qty
1
6
1
1
1
1
2
1
1
2
2
1
2
1
Ambient Technologies
A Division Of

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUCH LIGHT and is the answer not in the manual?

Questions and answers

Summary of Contents for Ambient TOUCH LIGHT

  • Page 1 TOUCH LIGHT™ Thermostatic On/Off Remote Control INSTALLATION AND OPERATING INSTRUCTIONS This wireless thermostatic on/off/ remote control – system provides a safe, reliable, and user-friendly remote control for millivolt valve gas appliances. The system can be thermostatically or manually turned on and off with the transmitter.
  • Page 2: Installations

    Turn appliance OFF (at the appliance or remote receiver) if you are away from your house for a long period of time. Never leave anything on top of the surface on the touch light transmitter.
  • Page 3: Remote Receiver

    Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 105C (250ºF) may cause the receiver to malfunction or fire hazard. Touch Light Transmitter: 50D0093 Rev 3 May 2005 Page 3 of 11...
  • Page 4 Installing Batteries: The Touch Light transmitter uses two (2) “AA”- size batteries. To install batteries, Press down the battery door tab and lift up and remove the battery door. Install the battery. Close the battery door by snapping in place.
  • Page 5 The Touch Light transmitter comes preset from the factory with a 2 hour shutdown from its last ON operation. This is done to prevent the appliance from continuing to run if unattended. You may disable this feature if you wish. To disable, change the Touch Light transmitter privacy (DIP) switch #1 ONLY to the OFF position (by sliding the switch towards the battery door.) Make sure the...
  • Page 6 Manual Mode- On or Off Operation: Since Touch Light transmitter is touch sensitive equipment, we recommend to use only your index finger to touch. Do not use any metal object to contact or touch the surface. The transmitter will recognize a valid...
  • Page 7 Press the Auto button to exit the thermostatic mode (beep once). The “TSTAT” and SET temp icon will disappear on the lower LCD display. The transmitter will be in the manual on/off mode Child-proof protection: 50D0093 Rev 3 May 2005 Page 7 of 11 Ambient Technologies A Division Of...
  • Page 8 Once the object is removed from the groove surfaces, the transmitter will remain in the off state until your next valid touch. Never leave anything on top of the surface of the touch light transmitter to prevent undesirable operation.
  • Page 9 Change the battery every six months before the battery is too weak for normal operation. TURN THE UNIT OFF BEFORE REPLACING BATTERIES. Touch Light Transmitter Thermal Shutdown: If transmitter measures a room temperature exceeding 99 degrees Fahrenheit, the LCD will display “HI”, emit three (3) beeps and send an...
  • Page 10: Troubleshooting

    • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 50D0093 Rev 3 May 2005 Page 10 of 11 Ambient Technologies A Division Of...
  • Page 11: Warranty

    Ambient Technologies warrants each new Ambient Technologies remote control against any defects that are due to faulty material or workmanship to the original owner, for a period of five years after the original date of purchase.
