Safety, Installation And Operating Instructions
ProXtra I, ProXtra II, ProXtra 3
IMPORTANT NOTICE:
Please save and read these safety, operating and installation instructions
before installing or applying AC power to your Charging Systems International
charger. Contact Charging Systems International with any product, installation,
or service questions at 1-800-742-2740.
For The Following Models:
Charging Systems International
Nashville, TN • 1-800-742-2740
#ProXtra Series
Advertisement
Table of Contents
Summary of Contents for Dual Pro ProXtra I
- Page 1 Safety, Installation And Operating Instructions For The Following Models: ProXtra I, ProXtra II, ProXtra 3 IMPORTANT NOTICE: Please save and read these safety, operating and installation instructions before installing or applying AC power to your Charging Systems International charger. Contact Charging Systems International with any product, installation, or service questions at 1-800-742-2740.
- Page 2 Installation And Operating Instructions For The Following Battery Charging Systems: MODELS NO. OF BANKS BATTERY SYSTEM PROXTRA I PROXTRA II 12, 24 PROXTRA 3 12, 24, 36 * Each charger cable assembly attached to one 12 Volt battery. IMPORTANT NOTICE...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS -This manual contains important safety and SAVE THESE INSTRUCTIONS operating instructions for the ProXtra 1,ProXtra 2, and ProXtra 3. Use of attachments not recommended or sold by Charging Systems International may result in a risk of fire, electrical shock, or injury to persons. -
Page 4: Product Summary
Someone should be within range of your voice or close enough to come to your aid when you work near a lead-acid battery. Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes. Wear complete eye protection and clothing protection. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Do not make any electrical connections to the main engine battery or additional batteries until the mounting process has been completed. The ProXtra may be counted at any angle. For best results, place the ProXtra at the desired location and mark the screw locations using the mounting bracket as a template. - Page 6 Post installation testing: After completing the total installation process for the ProXtra, it is possible to test the unit for proper operation without having to operate the main engine. 1. Attach a battery charger designed for a 12 volt system to the starting battery.
-
Page 7: Troubleshooting
Troubleshooting: CHARGING CHARGING TROLLING CRANKING BATTERIES BATTERY LED Indicator Lights PROBLEM: No indicators lights are illuminated on the ProXtra during engine operation. SOLUTION SEQUENCE: • Check battery connections for tightness and proper polarity. • Check in line fuses on Red and Black wires on starting battery cable. •... -
Page 8: Limited Warranty
LIMITED WARRANTY Charging Systems International makes this Limited Warranty only to the original retail purchaser. Charging Systems International warrants this battery charger for three years from the date of retail purchase against defective materials and/or workmanship. If such should occur, this unit will either be repaired or replaced at the discretion of the manufacturer.
