Summary of Contents for DVTEL 7701EA
- Page 1 7700 Series User Manual...
- Page 2 © 2004 DVTel, Inc. All rights reserved. By providing this document, DVTel, Inc. is not making any representations regarding the correctness or completeness of its contents and reserves the right to alter this document at any time without notice. Published by: DVTel Inc.
-
Page 3: Table Of Contents
Table of Contents Preface 5 About this User Guide 5 Symbols and Notation 5 Intended use 5 Support 5 Safety Information 6 Electrical shock hazard 6 Installation and operation 6 Maintenance and repair 6 Product Description 7 Supplied Components 7 System Requirements for Unit Setup 7 Overview of functions 7 Installation 10... - Page 4 Video Viewer configuration 34 Software update 35 Function test 36 Configuring the Receiver 37 Basics 37 Unit identification 37 Password settings 37 Language selection 38 Date and time 38 Time server 38 Monitor settings 39 Audio configuration 39 Alarm sources 39 Alarm connections 40 Relay action / Relay operation 41 COM1 serial data port / COM1 interface settings 42...
-
Page 5: Preface
This manual contains instructions for installing, configuring and using the DVTel 7700 Series of video servers. The series contains an encoder (7701EA) and a decoder (7701DA). Throughout this manual, these units may also be referred to, respectively, as transmitters and receivers, or, generically, as 7700 Series units. -
Page 6: Safety Information
– the unit has been stored in improper conditions – the unit has been exposed to a high level of stress during transport In such cases, contact DVTel Technical Support. Installation and operation • Always comply with relevant electrical guidelines. -
Page 7: Product Description
Product Description Supplied Components • A network video server, model 7701EA or 7701DA, with a terminal block for connecting power and external devices. • A 12V DC external power supply (North America only), unless one of the following optional power supplies are ordered: –... - Page 8 Firmware updates can be delivered the same way. Recording and Playback You can save the video streams encoded by the 7701EA as MPEG-4 files on any hard drive connected to your computer. The video sequences can be replayed using the provided software.
- Page 9 7700 Series Unit Casing Description 1 BNC jack: Video In (transmitter) or Video Out (receiver), for connecting a video source or an analog video monitor 2 RS232/485 5-pin terminal block: for communication with external devices and configuration via terminal software 3 2-pin terminal block: for powering the unit, particularly with a power brick and a wiring harness.
-
Page 10: Installation
Connections Camera/monitor The 7701EA encoder connects to a video camera while the 7701DA connects to an analog monitor. All NTSC or PAL devices are supported. – Connect the camera or another video source using a video cable (75 Ohms, BNC plug) to the Video In BNC jack of the transmitter. -
Page 11: Switching On/Off
Network You can connect the 7700 Series unit directly to a 10/100 Base-T network or via a hub. Use a standard UTP Category 5 cable with RJ45 connectors. – Connect the unit to the network using the Ethernet jack. Alarm inputs The 7700 Series unit has two alarm inputs on the orange terminal block. -
Page 12: Setup Using Terminal Software
Warning! Do not connect the 7700 Series unit to a power source until all the other connections have been made. Once the video server is connected to a power source, its status LED light will flash red for a few seconds. The unit is ready for operation as soon as the light turns steady yellow. - Page 13 – Start up a terminal program such as HyperTerminal. – Enter the user name service. The main menu will be displayed. – Enter I to open the IP menu. – Enter i. The current IP address will be displayed, and you will be requested to enter a new IP address. –...
-
Page 14: Configuration Using A Web Browser
MPEG decoder installation If no video images are displayed when you click the MPEG-4 link, it may be necessary to install a current MPEG decoder. This software is available for download from DVTel’s website. Establishing the connection The 7700 Series unit must be assigned a valid IP address for your network before it can be operated in the network environment. - Page 15 If the unit is a transmitter, the home page will be the Video Viewer (which shows the live video image, if a camera is connected to the encoder). The Connection page will be displayed as the home page for a receiver. It shows a snapshot from the video source for the transmitter currently connected, and the unit searches the network automatically for available transmitters.
-
Page 16: Choosing The Configuration Mode
– Enter the user name and password in the appropriate fields. – Click OK. If the password is correct, the 7700 Series unit home page will open. Choosing the configuration mode There are two options for configuring a 7700 Series unit or checking its current setup: •... -
Page 17: Configuration With The Configurator
General procedure The screens for the Installation Wizard will be shown in sequence, allowing you to work quickly and easily. The upper part of the window always contains information about the settings options. The current settings are shown in the lower part of the window. You can change settings by entering the desired value in a text field or choosing it from a list. - Page 18 The basic use of the configuration pages is described below. Separate descriptions of the individual configuration pages and customizable parameters for transmitters and receivers can be found in Kapitel 6 and Kapitel 7 of this user guide. Navigation You can switch to the Configurator from the Settings page. –...
-
Page 19: Configuring The Transmitter
Configuring the Transmitter Basics Below is a detailed overview of the various 7700 Series encoder settings that can be configured with the web- based Configurator. Other configuration options are described in chapter 5 of this user guide. The configurations described in this chapter should not be performed if you will be using the 7700 Series units with Latitude NVMS, as it will override them. -
Page 20: Language Selection
Language selection Use this section to change the interface language. Date and time If a number of 7700 Series units are part of a larger system, it is important that the internal clocks of all units be synchronized. Date format: Choose the desired date format: (Europe: DD.MM.YYYY;... -
Page 21: Camera Name
Camera name The camera name simplifies identification of the remote camera location, for example in the event of an alarm call. It can be shown in the video image if this feature is enabled and configured (see page 21). Display stamping Various overlays and stamps can be added to the video to provide important supplemental information. -
Page 22: Mpeg-4 Encoder Configuration
MPEG-4 Encoder configuration The 7700 Series transmitter has two MPEG encoders that can be configured separately. This allows for the transmission of two different video streams, which can be used for different applications (e.g. live viewing and recording). There are several pre-programmed profiles, optimized for different application scenarios, available for each MPEG encoder. - Page 23 • low delay (2CIF) for high bandwidth connections, 704 × 288 pixel resolution • low res. (CIF) for moderate bandwidth connections, resolution 352 × 288 pixels • DSL for DSL connections with 500 kbit/s • ISDN (2B) for ISDN connections via two B channels •...
-
Page 24: Video Input Settings
Video input settings The 75 Ohm termination of the 7700 Series unit can be set here. If the video signal is to be looped through, the termination must be set off. The default setting for the video input termination is On. Video input termination: To loop the video signal through choose Off. -
Page 25: Alarm Connections
Unified picture detection: The 7700 Series unit can trigger an alarm if the camera image shows too little contrast, possibly indicating that the lens has been sprayed with paint or covered in some way. Select On to enable this function. Motion alarm: Select On if the unit is to respond to a motion alarm. -
Page 26: Motion Detector
Alarm IP address: Enter the IP address of the device with which a connection is to be established in the event of an alarm. Remote password: Enter the password for the remote device (if it has one) that is to be contacted in response to an alarm. Live video auto-connect: Select On here if an active connection should be established after each reboot, for example following a connection failure or power failure. - Page 27 Motion detector Select On to activate the video sensor. Select sensor field You can select the areas of the image to be monitored by the video sensor. The video frame is subdivided into 396 square cells. Each of these cells can be activated or deactivated individually. If it is necessary to exclude particular regions of the camera field of view from the monitoring process due to continuous movement (a tree moving in the wind, etc.), the relevant cells can be deactivated.
-
Page 28: Relay Action / Relay Operation
Motion tracking In some situations you may want an alarm triggered only if the movement detected is in a particular direction. In such cases, enable motion detection and select the direction of movement required to trigger an alarm. – Select On to enable the motion tracking feature of the video sensor. Tracker The Tracker field shows an arrow indicating the current motion vector in the video image. -
Page 29: Com1 Serial Data Port / Com1 Interface Settings
• Off No relay triggering by events • Connection Triggering caused bby connection establishment • Video alarm Triggering caused by loss of the video signal • Motion alarm Triggering caused by the motion alarm • Local input 1 Triggering caused by alarm input 1 •... -
Page 30: Network Settings
Baud rate: Select the value for the data communication rate in Bit/s. Data bits: The number of data bits per character cannot be changed. Stop bits: Select the number of stop bits per character. Parity check: Select the type of parity check. Interface mode: Select the desired protocol for the serial interface. - Page 31 Gateway IP address: Enter the corresponding IP address here if the unit is to establish a connection outside the local network independently. Otherwise, this field can remain empty (0.0.0.0). Video/Audio transmission: If the device is used in front of a firewall, TCP (Port 80) should be selected as the transmission protocol. For use in a local network, choose UDP.
-
Page 32: Multicast Settings
Multicast settings In addition to a "one on one" connection (unicast) between a transmitter and a receiver, the 7700 Series unit also supports multiple connections. With multicasting, several decoders receive the video signal from an encoder at the same time. There are two methods for multiple connection: multi-unicast and multicast. In multi-unicast mode, the unit's data stream is duplicated and passed on to multiple receivers. -
Page 33: Version Information
Multicast audio port: With MPEG-4, video and audio data is transmitted via separate ports. To transmit MPEG-4 with audio you must assign a dedicated audio port. Note Audio data is only transmitted if the corresponding function on the Audio configuration page is enabled (see page 24). -
Page 34: Video Viewer Configuration
Either GIF or JPEG file formats can be used. The file paths must correspond to the access mode (local paths such as C:\Images\Logo.gif for local files and URLs such as http://www.dvtel.com/images/logo.gif for files on the Internet). Please note that access to network files requires that the connection be maintained in order to continue displaying the image. -
Page 35: Software Update
Video from Encoder on live page: Select whether to use encoder 1 or 2 in the Video Viewer. Panorama (Sony camera only): Selecting this option enables the display of a panoramic image. The panoramic image is shown in the upper part of the browser window. -
Page 36: Function Test
This allows a 7700 Series unit unit to be serviced and updated remotely without intervention by a technician to make on-site changes to the unit installation. The latest firmware can be obtained from DVTel Technical Support or downloaded from the Internet at our Web site www.dvtel.com. -
Page 37: Configuring The Receiver
Configuring the Receiver Basics Below is a detailed overview of the various 7700 Series encoder settings that can be configured with the web- based Configurator. Other configuration options are described in chapter 5 of this user guide. The configurations described in this chapter should not be performed if you will be using the 7700 Series units with Latitude NVMS, as it will override them. -
Page 38: Date And Time
Language selection Use this section to change the interface language. Date and time If a number of 7700 Series units are part of a larger system, it is important that the internal clocks of all units be synchronized. Date format: Choose the desired date format: (Europe: DD.MM.YYYY;... -
Page 39: Monitor Settings
Monitor settings The monitor name is used for easier identification of the monitor. The video standard for the connected monitor can also be selected here. Warning! Be sure to choose the correct video standard to avoid damaging the monitor. Audio configuration In addition to video data, the unit can also receive audio signals. -
Page 40: Alarm Connections
Enter a designation for the alarm input in the Name field. This name will be shown on the transmitter's Livepage next to the associated alarm icon. Alarm connections The 7700 Series unit can be configured to connect to a specified remote location, such as a transmitter, when an alarm is triggered. -
Page 41: Relay Action / Relay Operation
Relay action / Relay operation You can configure the switching behavior of the relay output. Relay action can be specified either as open switch (normally closed contact) or closed switch (normally open contact). It is also possible to specify whether the output signal should be bistable or monostable. With bistable operation, the relay remains in the activated state. -
Page 42: Com1 Serial Data Port / Com1 Interface Settings
• Unified picture Triggering caused by a lack of contrast in the picture Relay name: A name can be assigned to the relay in this field. The name will be shown on the button under Trigger relay. The Video Viewer can also be configured to display the name next to the relay icon. Trigger relay: Click the button to switch the relay manually (for example, for test purposes or to operate a door opener). -
Page 43: Network Settings
Interface mode: Select the desired protocol for the serial interface. Half-duplex mode: Choose the setting appropriate for your application. Network settings Click this link to reboot unit The settings on this page are used to integrate the unit into an existing network. Note Although the modified network settings are copied to the 7700 Series unit when the Set button is clicked, they become effective only after the unit has been restarted. -
Page 44: Version Information
Ethernet link type: Adjust here the ethernet link to the network. In most applications Auto is the correct choice. For some routers and switches it may be necessary to set the Ethernet link to a fixed value. In that case select the appropriate value: •... -
Page 45: Software Update
This allows a 7700 Series unit unit to be serviced and updated remotely without intervention by a technician to make on-site changes to the unit installation. The latest firmware can be obtained from DVTel Technical Support or downloaded from the Internet at our Web site www.dvtel.com. -
Page 46: Function Test
This message will appear: Configuration upload finished. State: Configuration upload ok (the system must be rebooted), and the countdown for reconnection will be displayed. – Restart the unit. The next time the software update page is opened, the message Configuration upload ok should appear, confirming the successful completion of the upload. -
Page 47: Transmitter Operation
Transmitter Operation The Video Viewer Once a connection witht he encoder is established, the Video Viewer will be displayed, showing a live video feed in the middle of the browser window. Depending upon the configuration, various text overlays may also be visible. -
Page 48: Panoramic View
– Click the relay symbol next to the video image to activate the relay output. The symbol will turn red when the relay is activated. Event messages The Event display field is where event and alarm status messages are listed. These messages can be saved (see page 35). -
Page 49: Recording Video Sequences
– Click the icon once more to stop the recording. Note Use the DVTel MPEG viewer to play the recorded video. The latest version of the software is available for download from DVTel’s website: http://www.dvtel.com. Image resolution The sequences will be recorded at the resolution specified in the settings for the corresponding encoder (see... -
Page 50: Receiver Operation
Receiver Operation The Decoder connection page After the connection has been established, the Decoder connection page will be displayed. Preview This area displays a snapshot of the video image from a selected transmitter currently online. In addition to the unit name, the snapshot provides other means of identifying the encoder. Monitor The video feed currently seen on the connected monitor is shown here. -
Page 51: Maintenance And Upgrades
– Configure the unit to meet your requirements. Repairs Warning! Never open the casing of a 7700 Series unit. The unit does not contain any parts that you can repair or replace. Contact DVTel Technical Support is any repairs are necessary. -
Page 52: Appendix
Appendix Troubleshooting If a problem cannot be resolved, please contact DVTel’s Technical Support Department. The version numbers of the internal processors can be viewed on a special page. Please note this information before contacting Technical Support. – In the address field of the browser, append /version.htm to the IP address of the unit (e.g. -
Page 53: Leds
The unit stops working after a Power failure during the firmware Replace the unit and have it checked by DVTel. firmware upload. upgrade. LEDs The 7700 Series unit is equipped with several LEDs that indicate its operating status:... -
Page 54: Glossary
Connection jacks The connection jacks of the 10-block terminal block are used to connect to power, alarm switches, relays, and audio. Terminal allocation Terminal Function audio input (line level) audio output (line level) Alarm 1 input alarm output power supply, 9 to 24 V electrical ground electrical ground Alarm 2 input... -
Page 55: Series Unit Specifications
JPEG An encoding process for still images (Joint Photographic Experts Group) Kbps Kilobits per second, the actual data rate See Local area network Local area network A communications network serving users within a limited geographical area, such as a building or a university campus. It is controlled by a network operating system and uses a transfer protocol. - Page 56 Video input 1 × BNC jack 0.7 to 1.2 V 75 Ohm switchable, PAL/NTSC Video output 1 × BNC jack 1.0 V 75 Ohm, PAL/NTSC Audio input 1 × push-in terminal 3.0 V , 50 kOhm, mono Audio output 1 × push-in terminal 2.5 V , 60 mW, min.
-
Page 57: Index
Index ActiveX 14 Live video images 14 Actuator 11 Live video sequence 47 Alarm 47 Livepage 34 Alarm input 11 Loudspeaker 11 Alarm IP address 26 Audio connection 11 Audio signals 24 Main functions 8 Maintenance 6 Motion alarm 25 Browser window 47 MPEG recording 49 Multicast 32... - Page 58 Time server 20 Time signal 20 Time zone 20 Transmission rate 30 Trigger relay 29 TTL 33 UDP 31 Unicast 32 Unified picture detection 25 Update 35 Upload file 36 URL 14 User name 19 Version 33 Video loss alarm 24 Video quality 23 Video resolution 23 Video sensor 26...
